Clutch Pedal & Flexible Hose ([08.1983 - ] (8308- )MTM..DSL,EFI) Diagram Toyota CROWN/ MAJESTA
- Year
- 1985 - 1987
- Sales region
- Japan
- Frame
- LS120
- grade
- SDX
- body
- SED
- ENGINE
- 2L
- TRANSMISSION
- MTM
- Model
- CROWN
- From
- 09.1985
- To
- 08.1987
- Gear Shift Type
- 5F
- Fuel Induction
- DSL
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
31301
|
31301
31301-30170 Pedal Sub-Assy, Clutch[08.1983 - 08.1987] GS120,126,LS12#..MTM..(DSL,EFI) |
31301-30170 |
US $30.28 |
||
|
31301A
|
31301A
90506-12026 Spring(For Clutch Pedal)[08.1983 - 08.1987] GS120,126,LS12#..MTM..(DSL,EFI) |
90506-12026 |
US $3.20 |
||
|
31301B
|
31301B
90541-07010
Cushion, No.1(For Clutch Pedal)
[08.1983 - 08.1987] GS12#,LS12#,MS120,YS120..MTM |
90541-07010 |
— | ||
|
31301C
|
31301C
90386-13015 Bush(For Clutch Pedal)[05.1986 - 08.1987] GS12#,LS12#,MS120,YS120..MTM |
90386-13015 |
from US $0.64 |
||
|
31301C
|
31301C
90386-13192 Bush(For Over Center Plate)[08.1983 - 05.1986] GS12#,LS12#,MS120,YS120..MTM |
90386-13192 |
from US $1.64 |
||
|
31301F
|
31301F
90101-10369 Bolt(For Clutch Pedal Stopper)[08.1983 - 08.1987] GS12#,LS12#,MS120,YS120..MTM |
90101-10369 |
from US $1.31 |
||
|
31305D
|
31305D
55107-30130 Support Sub-Assy, Clutch Pedal[08.1983 - 08.1987] GS120,126,LS12#..MTM..(DSL,EFI) |
55107-30130 |
US $27.66 |
||
|
31321
|
31321
31321-30040 Pad, Clutch Pedal[08.1983 - 08.1987] GS12#,LS12#,MS120,YS120..MTM |
31321-30040 |
from US $4.33 |
||
|
31324
|
31324
90101-10039 Shaft, Clutch Pedal[08.1983 - 08.1987] GS12#,LS12#,MS120,YS120..MTM |
90101-10039 |
US $2.87 |
||
|
31324A
|
31324A
90387-10003 Collar, Clutch Pedal Shaft[08.1983 - 08.1987] GS12#,LS12#,MS120,YS120..MTM |
90387-10003 |
from US $3.94 |
||
|
31453A
|
31453A
90249-08018 Pin, W/hole(For Clutch Master Cylinder Push Rod Clevis)[08.1983 - 08.1987] GS12#,LS12#,MS120,YS120..MTM 長さ＝２９．５ |
90249-08018 |
from US $2.20 |
||
|
31453B
|
31453B
90386-08002 Bush(For Clutch Pedal Over Center Spring Pin)[08.1983 - 08.1987] GS12#,LS12#,MS120,YS120..MTM |
90386-08002 |
from US $3.22 |
||
|
9046816142
|
9046816142
90468-16142 Clip(For Push Rod Clevis Pin) |
90468-16142 |
from US $0.82 |
||
|
9165160816
|
9165160816
91651-60816 BOLT |
91651-60816 |
from US $1.01 |
||
| replacement | |||||
|
9165160816
|
9165160816
90080-11396 BOLT |
90080-11396 |
US $3.32 |
||
|
9411051000
|
9411051000
94110-51000 Nut(For Steering Center Arm) |
94110-51000 |
from US $0.86 |
||
|
9412041000
|
9412041000
94120-41000 Nut(For Clutch Pedal Stopper) |
94120-41000 |
from US $0.76 |
||
| replacement | |||||
|
9412041000
|
9412041000
90170-A0002 Nut |
90170-A0002 |
US $2.33 |
||
|
9451201000
|
9451201000
94512-01000 Washer, No.1 (For Propeller Shaft & Differential Setting) |
94512-01000 |
from US $0.80 |
||
