Ignition Coil & Spark Plug ([08.1995 - ] (9508- )2LTE) Diagram Toyota CROWN/ MAJESTA
- Year
- 1995 - 1999
- Sales region
- Japan
- Frame
- LS151
- grade
- SPDLX
- body
- SED
- ENGINE
- 2LTE
- TRANSMISSION
- ATM
- Model
- CROWN/ CROWN MAJESTA
- From
- 12.1995
- To
- 09.1999
- Gear Shift Type
- 4FC
- Body Shape
- NOB
- Fuel Induction
- TDE
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
19850
|
19850
19850-54110 Plug Assy, Glow[08.1995 - 09.1996] 2LTE..LS151 ＊ＢＶ−ＧＶ＝１２Ｖ−１１Ｖ |
19850-54110 |
US $90.27 |
||
| replacement | |||||
|
19850
|
19850
19850-54130 Plug Assy, Glow[08.1995 - 09.1996] 2LTE..LS151 ＊ＢＶ−ＧＶ＝１２Ｖ−１１Ｖ |
19850-54130 |
US $57.37 |
||
|
19850
|
19850
19850-54130 Plug Assy, Glow[09.1996 -] 2LTE..LS151 ＊ＢＶ−ＧＶ＝１２Ｖ−１１Ｖ |
19850-54130 |
US $57.37 |
||
|
19856
|
19856
90179-04030 Nut, Connecting(For Glow Plug)[08.1995 -] 2LTE..LS151 |
90179-04030 |
US $0.96 |
||
|
19856A
|
19856A
90189-04024 Grommet, Screw(For Glow Plug)[08.1995 -] 2LTE..LS151 |
90189-04024 |
from US $0.72 |
||
|
19871
|
19871
19871-54040 Connector, Glow Plug No.1[08.1995 -] 2LTE..LS151 |
19871-54040 |
US $28.39 |
||
|
19871A
|
19871A
90116-06095 Bolt, Stud(For Head To Cylinder Head Cover)[08.1995 -] 2LTE..LS151 |
90116-06095 |
US $1.44 |
||
|
28622
|
28622
28622-57010 Insulator, Glow Plug Resistor, No.1[08.1995 -] 2LTE..LS151 |
28622-57010 |
from US $1.40 |
||
|
28623
|
28623
28623-54010 Insulator, Glow Plug Resistor, No.2[08.1995 -] 2LTE..LS151 |
28623-54010 |
from US $1.40 |
||
|
9017906158
|
9017906158
90179-06158 Nut, Rear Wiper Link Pivot, No.2 |
90179-06158 |
from US $0.99 |
||
|
9461410600
|
9461410600
94614-10600
Washer (For Primary Regulator Valve)
|
94614-10600 |
— | ||
| replacement | |||||
|
9461410600
|
9461410600
94613-10601 Washer (For Primary Regulator Valve) |
94613-10601 |
US $1.12 |
||
