Manifold ([10.1980 - ] (8010- )MTEU) Diagram Toyota CROWN/ MAJESTA
- Year
- 1980 - 1983
- Sales region
- Japan
- Frame
- MS110
- grade
- SAL
- body
- HT
- ENGINE
- MTEU
- TRANSMISSION
- ATM
- Model
- CROWN
- From
- 10.1980
- To
- 07.1983
- Gear Shift Type
- 4FC
- No.of Doors
- 2D
- Hard Top Type
- 2DH
- Fuel Induction
- TBO
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
15407
|
15407
15407-41010 Pipe Sub-Assy, Turbo Oil Inlet[10.1980 - 07.1983] MTEU..MS110 |
15407-41010 |
US $88.82 |
||
|
15407A
|
15407A
90401-12097 Bolt, Union(For Turbo Oil Inlet Pipe)[10.1980 - 07.1983] MTEU..MS110 |
90401-12097 |
from US $3.08 |
||
|
15407B
|
15407B
90430-12005 Gasket(For Water Hole)[10.1980 - 07.1983] MTEU..MS110 |
90430-12005 |
from US $0.76 |
||
|
15471
|
15471
15471-41010
Gasket, Turbo Oil Inlet
[10.1980 - 07.1983] MTEU..MS110 |
15471-41010 |
— | ||
|
15472
|
15472
15472-41010
Gasket, Turbo Oil Outlet, No.1
[10.1980 - 07.1983] MTEU..MS110 |
15472-41010 |
— | ||
|
15473
|
15473
15473-41010
Gasket, Oil Hole Cover Plate
[10.1980 - 07.1983] MTEU..MS110 |
15473-41010 |
— | ||
| replacement | |||||
|
15473
|
15473
15473-42010 Gasket, Turbo Oil Outlet, No.2[10.1980 - 07.1983] MTEU..MS110 |
15473-42010 |
US $8 |
||
|
15474
|
15474
15474-41010 Pipe, Turbo Oil Outlet[10.1980 - 07.1983] MTEU..MS110 |
15474-41010 |
US $152.88 |
||
|
15475
|
15475
15475-41010 Deflector, Oil[10.1980 - 10.1982] MTEU..MS110 |
15475-41010 |
US $21.26 |
||
| replacement | |||||
|
15475
|
15475
15475-41020 Deflector, Oil[10.1980 - 10.1982] MTEU..MS110 |
15475-41020 |
US $22.57 |
||
|
15475
|
15475
15475-41020 Deflector, Oil[10.1982 - 07.1983] MTEU..MS110 |
15475-41020 |
US $22.57 |
||
|
17141D
|
17141D
90116-08045 Bolt, Stud(For Oxygen Sensor)[09.1979 - 08.1982] 1GEU..GS110 L=28,S=14&8; MEU,MJ,5MEU,MTEU,MU..MS11# L=28,S=14&8 |
90116-08045 |
US $3.35 |
||
| replacement | |||||
|
17141D
|
17141D
90116-08128 Bolt, Stud(For Manifold Stay)[09.1979 - 08.1982] 1GEU..GS110 L=28,S=14&8; MEU,MJ,5MEU,MTEU,MU..MS11# L=28,S=14&8 |
90116-08128 |
US $4.16 |
||
|
17141D
|
17141D
90116-08168 Bolt, Stud(For Oxygen Sensor)[08.1982 - 07.1983] 5M#,MTEU,MU..MS11# L=28,S=14&8 |
90116-08168 |
US $2.56 |
||
|
17152
|
17152
90116-10017 Bolt, Stud(For Manifold To Exhaust Pipe)[09.1979 - 02.1981] 5RU..RS110 L=41,S=21&14; MEU,MJ,5MEU,MTEU,MU..MS11# L=41,S=21&14 |
90116-10017 |
from US $2.92 |
||
|
17152
|
17152
90116-10058 Bolt, Stud(For Manifold Extension)[02.1981 - 07.1983] 1GE#..GS11# L=46.5,S=14&20; MEU,MJ,5M#,MTEU,MU..MS11# L=46.5,S=14&20; 5RU..RS110 L=46.5,S=14&20 |
90116-10058 |
from US $2.44 |
||
|
17201
|
17201
17201-41010 Turbocharger Sub-Assy[10.1980 - 10.1982] MTEU..MS110 |
17201-41010 |
US $2,999.36 |
||
| replacements | |||||
|
17201
|
17201
15475-41020 Deflector, Oil[10.1980 - 10.1982] MTEU..MS110 |
15475-41020 |
US $22.57 |
||
|
17201
|
17201
17201-41011 Turbocharger Sub-Assy[10.1980 - 10.1982] MTEU..MS110 |
17201-41011 |
US $2,999.36 |
||
|
17201
|
17201
17201-41011 Turbocharger Sub-Assy[10.1982 - 07.1983] MTEU..MS110 |
17201-41011 |
US $2,999.36 |
||
|
17271
|
17271
17271-41010
Insulator, Turbo, No.1
[10.1980 - 07.1983] MTEU..MS110 |
17271-41010 |
— | ||
|
17272
|
17272
17202-41010
Insulator, Turbo, No.2
[10.1980 - 07.1983] MTEU..MS110 |
17202-41010 |
— | ||
|
17274
|
17274
17203-41010 Elbow, Compressor Inlet[10.1980 - 07.1983] MTEU..MS110 |
17203-41010 |
US $136.86 |
||
| replacement | |||||
|
17274
|
17274
17203-41030
Elbow, Compressor Inlet
[10.1980 - 07.1983] MTEU..MS110 |
17203-41030 |
— | ||
|
17275
|
17275
17275-41010 Elbow, Compressor Outlet[10.1980 - 07.1983] MTEU..MS110 |
17275-41010 |
US $107.74 |
||
|
17276
|
17276
17276-41010
Gasket, Compressor Inlet
[10.1980 - 12.1982] MTEU..MS110 |
17276-41010 |
— | ||
| replacement | |||||
|
17276
|
17276
17276-41020 Gasket, Compressor Inlet[10.1980 - 12.1982] MTEU..MS110 |
17276-41020 |
US $7.72 |
||
|
17276
|
17276
17276-41020 Gasket, Compressor Inlet[12.1982 - 07.1983] MTEU..MS110 |
17276-41020 |
US $7.72 |
||
|
17277
|
17277
17277-41010
Gasket, Compressor Outlet
[10.1980 - 07.1983] MTEU..MS110 |
17277-41010 |
— | ||
|
17278
|
17278
17278-41010
Gasket, Turbo To Exhaust Manifold
[10.1980 - 07.1983] MTEU..MS110 |
17278-41010 |
— | ||
|
1728941010
|
1728941010
17289-41010 Ring, Retaining |
17289-41010 |
US $8.01 |
||
|
9011608068
|
9011608068
90116-08068 Bolt, Stud |
90116-08068 |
US $4.48 |
||
|
9011608134
|
9011608134
90116-08134 New Genuine Part |
90116-08134 |
US $3.49 |
||
|
9011608136
|
9011608136
90116-08136 New Genuine Part |
90116-08136 |
US $3.35 |
||
|
9011608143
|
9011608143
90116-08143 New Genuine Part |
90116-08143 |
US $4.95 |
||
|
9011610054
|
9011610054
90116-10054 Bolt, Stud(For Turbocharger) |
90116-10054 |
US $5.39 |
||
| replacement | |||||
|
9011610054
|
9011610054
90116-10094 Bolt, Stud(For Turbine Housing) |
90116-10094 |
US $2.24 |
||
|
9017908012
|
9017908012
90179-08012 NUT |
90179-08012 |
US $3.68 |
||
|
9017908059
|
9017908059
90179-08059
Nut
|
90179-08059 |
— | ||
| replacement | |||||
|
9017908059
|
9017908059
90179-08101 NUT |
90179-08101 |
from US $0.84 |
||
|
9017910028
|
9017910028
90179-10028 Nut, Exhaust Pipe Set Stud Bolt |
90179-10028 |
from US $2.91 |
||
|
9020108084
|
9020108084
90201-08084 New Genuine Part |
90201-08084 |
US $2.88 |
||
|
9044511055
|
9044511055
90445-11055 New Genuine Part |
90445-11055 |
US $13.40 |
||
|
9046011001
|
9046011001
90460-11001 Clip, No.1(For Idle-Up Hose) |
90460-11001 |
US $1.89 |
||
| replacement | |||||
|
9046011001
|
9046011001
96132-41000 Clip, No.1(For Idle-Up Hose) |
96132-41000 |
from US $1.28 |
||
|
9046400282
|
9046400282
90464-00282 New Genuine Part |
90464-00282 |
US $8.15 |
||
|
9161140820
|
9161140820
91611-40820
Bolt(For Intake Manifold To Exhaust Manifold)
|
91611-40820 |
— | ||
|
9161140825
|
9161140825
91611-40825
Bolt(For Clutch Release Cylinder Setting)
|
91611-40825 |
— | ||
| replacement | |||||
|
9161140825
|
9161140825
91611-B0825 Bolt(For Clutch Release Cylinder Setting) |
91611-B0825 |
from US $1.93 |
||
|
9212240820
|
9212240820
92122-40820 Bolt, Stud(For Manifold To Carburetor) |
92122-40820 |
US $2.33 |
||
