Front Clearance Lamp ([09.1979 - 08.1981] (7909-8108)HT) Diagram Toyota CROWN/ MAJESTA
- Year
- 1979 - 1981
- Sales region
- Japan
- Frame
- MS110
- grade
- SPE
- body
- HT
- ENGINE
- MEU
- TRANSMISSION
- ATM
- Model
- CROWN
- From
- 09.1979
- To
- 08.1981
- Gear Shift Type
- 4FC
- No.of Doors
- 2D
- Hard Top Type
- 2DH
- Fuel Induction
- EFI
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
81610
|
81610
81610-39315 Lamp Assy, Parking & Clearance, RhPARKING & CLEARANCE, RH [09.1979 - 08.1981] LS110,MS110,112..HT |
81610-39315 |
US $173.26 |
||
|
81610
|
81610
81610-39316 Lamp Assy, Parking & Clearance, RhPARKING & CLEARANCE, RH [08.1981 - 07.1983] GS110,LS110,111,MS110,112..HT |
81610-39316 |
US $173.26 |
||
|
81610B
|
81610B
90981-12007
Bulb(For Rear Combination Lamp)
[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110 12V 7/3.4W |
90981-12007 |
— | ||
| replacement | |||||
|
81610B
|
81610B
99132-12007
Bulb(For Rear Combination Lamp)
[09.1979 - 07.1983] GS11#,LS11#,MS11#,RS110 12V 7/3.4W |
99132-12007 |
— | ||
|
81610B
|
81610B
99132-11080 Bulb(For Parking & Clearance Lamp)[09.1979 - 08.1981] LS11#,MS11#,RS110 12V 8W |
99132-11080 |
US $2.18 |
||
| replacement | |||||
|
81610B
|
81610B
99132-11075 Bulb, Room Lamp, No.1[09.1979 - 08.1981] LS11#,MS11#,RS110 12V 8W |
99132-11075 |
from US $2.56 |
||
|
81610B
|
81610B
99132-12050 Bulb (12V 5W)[08.1981 - 07.1983] GS11#,LS11#,MS11#,RS110 １２Ｖ ５Ｗ,12V 5W |
99132-12050 |
from US $1.76 |
||
| replacement | |||||
|
81610B
|
81610B
90080-81053 Bulb(For Clearance Lamp)[08.1981 - 07.1983] GS11#,LS11#,MS11#,RS110 １２Ｖ ５Ｗ,12V 5W |
90080-81053 |
US $2.75 |
||
|
81611
|
81611
81611-30160 Lens, Parking & Clearance Lamp, RhPARKING & CLEARANCE LAMP, RH [09.1979 - 08.1981] LS110,MS110,112..HT |
81611-30160 |
US $152.88 |
||
|
81611
|
81611
81611-30161 Lens, Parking & Clearance Lamp, RhPARKING & CLEARANCE LAMP, RH [08.1981 - 07.1983] GS110,LS110,111,MS110,112..HT |
81611-30161 |
US $152.88 |
||
|
81614
|
81614
81614-30160 Gasket, Parking And Clearance Lamp Body, RhPARKING AND CLEARANCE LAMP BODY, RH [09.1979 - 08.1981] LS110,MS110,112..HT |
81614-30160 |
US $9.76 |
||
|
81616B
|
81616B
81612-30160
Tube, Parking And Clearance Lamp
[01.1980 - 08.1981] LS110,MS110,112..HT |
81612-30160 |
— | ||
|
81616B
|
81616B
81616-30160
Tube, Parking And Clearance Lamp
[09.1979 - 01.1980] LS110,MS110,112..HT |
81616-30160 |
— | ||
|
81616B
|
81616B
81616-30161 Tube, Parking And Clearance Lamp[08.1981 - 07.1983] GS11#,LS11#,MS11#,RS110 |
81616-30161 |
US $2.91 |
||
|
81620
|
81620
81620-39315 Lamp Assy, Parking & Clearance, LhPARKING & CLEARANCE, LH [09.1979 - 08.1981] LS110,MS110,112..HT |
81620-39315 |
US $173.26 |
||
|
81620
|
81620
81620-39316 Lamp Assy, Parking & Clearance, LhPARKING & CLEARANCE, LH [08.1981 - 07.1983] GS110,LS110,111,MS110,112..HT |
81620-39316 |
US $173.26 |
||
|
81621
|
81621
81621-30160 Lens, Parking & Clearance Lamp, LhPARKING & CLEARANCE LAMP, LH [09.1979 - 08.1981] LS110,MS110,112..HT |
81621-30160 |
US $152.88 |
||
|
81621
|
81621
81621-30161 Lens, Parking & Clearance Lamp, LhPARKING & CLEARANCE LAMP, LH [08.1981 - 07.1983] GS110,LS110,111,MS110,112..HT |
81621-30161 |
US $152.88 |
||
|
81624
|
81624
81624-30160 Gasket, Parking And Clearance Lamp Body, LhPARKING AND CLEARANCE LAMP BODY, LH [09.1979 - 08.1981] LS110,MS110,112..HT |
81624-30160 |
US $9.76 |
||
|
81625
|
81625
81615-30160
Socket And Wire, Parking And Clearance Lamp
[09.1979 - 08.1981] LS110,MS110,112..HT |
81615-30160 |
— | ||
|
81625
|
81625
81615-30161
Socket And Wire, Parking And Clearance Lamp
[08.1981 - 07.1983] GS11#,LS11#,MS11#,RS110 |
81615-30161 |
— | ||
|
9018904022
|
9018904022
90189-04022 CLIP |
90189-04022 |
from US $1.12 |
||
|
9354054020
|
9354054020
93540-54020 New Genuine Part |
93540-54020 |
US $1.12 |
||
