Side Member ([09.1987 - ] (8709- )) Diagram Toyota CROWN/ MAJESTA
- Year
- 1987 - 1991
- Sales region
- General
- Frame
- YS132
- grade
- STD
- body
- SED
- ENGINE
- 4Y
- TRANSMISSION
- MTM
- DESTINATION
- GEN
- Model
- CROWN
- From
- 09.1987
- To
- 10.1991
- Gear Shift Type
- 4F
- Driver's Position
- LHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
61815B
|
61815B
61815-30060 Cover, Roof Side, Inner Upper Rh[09.1987 - 10.1991] GS131,LS130,MS13#,YS132..SED |
61815-30060 |
US $19.22 |
||
|
61816B
|
61816B
61816-30060 Cover, Roof Side, Inner Upper Lh[09.1987 - 10.1991] GS131,LS130,MS13#,YS132..SED |
61816-30060 |
US $19.22 |
||
|
61817B
|
61817B
61817-30030 Cover, Roof Side, Inner Lower Rh[09.1987 - 10.1991] GS131,LS130,MS13#,YS132..HT,SED |
61817-30030 |
US $5.68 |
||
|
61818B
|
61818B
61817-30030 Cover, Roof Side, Inner Lower Rh[09.1987 - 10.1991] GS131,LS130,MS13#,YS132..HT,SED |
61817-30030 |
US $5.68 |
||
|
61824
|
61824
61824-30010 Plate, Noise Control, No.1[09.1987 - 10.1991] GS131,LS130,MS13#,YS132..SED |
61824-30010 |
US $9.17 |
||
|
61825A
|
61825A
61825-30020 Plate, Noise Control, No.1[09.1987 - 08.1989] GS131,LS130,MS13#,YS132..HT,SED |
61825-30020 |
US $6.41 |
||
|
61826A
|
61826A
61826-30030 Plate, Noise Control, No.3[09.1987 - 10.1991] GS131,LS130,MS13#,YS132..HT,SED |
61826-30030 |
US $9.90 |
||
|
62554B
|
62554B
62554-30010 Pad, Pillar, No.4[09.1987 - 10.1991] GS131,LS130,MS13#,YS132..SED 65 X 65 |
62554-30010 |
US $3.20 |
||
|
62939A
|
62939A
62939-22040 Silencer, Quarter Vent[09.1987 - 05.1989] MS135..GCC;GS131,LS130,MS133,YS132;MS132..SED..(DLX,SAL,STD) |
62939-22040 |
US $9.03 |
||
| replacement | |||||
|
62939A
|
62939A
61824-12110 Plate, Noise Control, No.1[09.1987 - 05.1989] MS135..GCC;GS131,LS130,MS133,YS132;MS132..SED..(DLX,SAL,STD) |
61824-12110 |
US $15.58 |
||
|
9354014012
|
9354014012
93540-14012 Screw |
93540-14012 |
from US $1.92 |
||
