Slide Roller & Rail ([01.1986 - ] (8601- )) Diagram Toyota DYNA/ TOYOACE
- Year
- 1986 - 1995
- Sales region
- Japan
- Frame
- BU60
- grade
- N
- ENGINE
- B
- Model
- DYNA/ TOYOACE QUICK
- From
- 01.1986
- To
- 05.1995
- Gear Shift Type
- 5H
- No.of Doors
- 3D
- Vehicle Model
- DYN
- Building Condition
- CBU
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
68043
|
68043
68043-90D03 Arm Sub-Assy, Front Slide Door Upper Roller, Rh[01.1986 - 05.1988] BU60 |
68043-90D03 |
US $96.10 |
||
|
68045
|
68045
68045-90D02 Bracket Sub-Assy, Front Slide Door Catch[01.1986 - 08.1987] BU60 |
68045-90D02 |
US $25.77 |
||
|
68307
|
68307
68307-95702 Hinge Sub-Assy, Slide Door Center Male[08.1990 - 05.1995] BU60..CBU |
68307-95702 |
US $38.58 |
||
|
68334A
|
68334A
68334-95700 Roller, Slide Door Center, No.2[08.1990 - 05.1995] BU60..CBU |
68334-95700 |
from US $4.50 |
||
|
68370A
|
68370A
68701-26010 Roller Assy, Slide Door, Center[01.1991 - 05.1995] BU60..CBU |
68701-26010 |
US $80.08 |
||
| replacements | |||||
|
68370A
|
68370A
68333-90D00 Roller, Slide Door Center, No.1[01.1991 - 05.1995] BU60..CBU |
68333-90D00 |
US $6.27 |
||
|
68370A
|
68370A
68701-25010 Hinge Assy, Front Slide Door, Center Rh[01.1991 - 05.1995] BU60..CBU |
68701-25010 |
US $81.54 |
||
|
68370A
|
68370A
68701-90D01 Roller Assy, Slide Door, Center[08.1990 - 01.1991] BU60..CBU |
68701-90D01 |
US $81.54 |
||
| replacements | |||||
|
68370A
|
68370A
68333-90D00 Roller, Slide Door Center, No.1[08.1990 - 01.1991] BU60..CBU |
68333-90D00 |
US $6.27 |
||
|
68370A
|
68370A
68701-25010 Hinge Assy, Front Slide Door, Center Rh[08.1990 - 01.1991] BU60..CBU |
68701-25010 |
US $81.54 |
||
|
68370A
|
68370A
68710-90D00 Hinge Assy, Front Slide Door, Center Rh[01.1986 - 08.1990] BU60 |
68710-90D00 |
US $90.27 |
||
| replacements | |||||
|
68370A
|
68370A
68333-90D00 Roller, Slide Door Center, No.1[01.1986 - 08.1990] BU60 |
68333-90D00 |
US $6.27 |
||
|
68370A
|
68370A
68307-95702 Hinge Sub-Assy, Slide Door Center Male[01.1986 - 08.1990] BU60 |
68307-95702 |
US $38.58 |
||
|
68370A
|
68370A
90245-08013 New Genuine Part[01.1986 - 08.1990] BU60 |
90245-08013 |
US $5.56 |
||
|
68370A
|
68370A
96160-00600 Ring, E(For Clutch Pedal Pawl)[01.1986 - 08.1990] BU60 |
96160-00600 |
from US $0.82 |
||
|
68370A
|
68370A
68701-25010 Hinge Assy, Front Slide Door, Center Rh[01.1986 - 08.1990] BU60 |
68701-25010 |
US $81.54 |
||
|
68403A
|
68403A
68403-90D02 Rail Sub-Assy, Front Slide Door, Center Rh[01.1986 - 03.1989] BU60 |
68403-90D02 |
US $183.46 |
||
| replacement | |||||
|
68403A
|
68403A
68403-90D03 Rail Sub-Assy, Front Slide Door, Center Rh[01.1986 - 03.1989] BU60 |
68403-90D03 |
US $186.37 |
||
|
68403A
|
68403A
68403-90D03 Rail Sub-Assy, Front Slide Door, Center Rh[03.1989 - 08.1990] BU60 |
68403-90D03 |
US $186.37 |
||
|
68403A
|
68403A
68403-90F00 Rail Sub-Assy, Front Slide Door, Center Rh[10.1987 - 02.1988] BU60..N..3D ﾔﾏﾄｳﾝﾕ ｼﾖｳ |
68403-90F00 |
US $183.46 |
||
|
68403A
|
68403A
68403-90F01 Rail Sub-Assy, Front Slide Door, Center Rh[02.1988 - 04.1989] BU60..N..3D ﾔﾏﾄｳﾝﾕ ｼﾖｳ |
68403-90F01 |
US $183.46 |
||
| replacement | |||||
|
68403A
|
68403A
68403-90F02 Rail Sub-Assy, Front Slide Door, Center Rh[02.1988 - 04.1989] BU60..N..3D ﾔﾏﾄｳﾝﾕ ｼﾖｳ |
68403-90F02 |
US $182 |
||
|
68403A
|
68403A
68403-90F02 Rail Sub-Assy, Front Slide Door, Center Rh[04.1989 - 05.1995] BU60..N..3D ﾔﾏﾄｳﾝﾕ ｼﾖｳ |
68403-90F02 |
US $182 |
||
|
68405A
|
68405A
68405-90D01 Rail Sub-Assy, Front Slide Door, Upper Rh[01.1986 - 05.1995] BU60 |
68405-90D01 |
US $200.93 |
||
|
68433
|
68433
68433-90D00 Protector, Slide Door Center Rail[09.1988 - 03.1989] BU60 |
68433-90D00 |
US $3.64 |
||
|
68450
|
68450
68450-90D01 Roller Assy, Front Slide Door, Lower Rh[01.1986 - 05.1988] BU60 |
68450-90D01 |
US $31.89 |
||
|
68457
|
68457
68457-26010 Base, Front Slide Door Cushion[06.1992 - 05.1995] BU60..CBU |
68457-26010 |
US $4.66 |
||
|
68465
|
68465
68465-90D01 Bracket, Front Slide Door Lower Roller[01.1986 - 05.1988] BU60 |
68465-90D01 |
US $15.58 |
||
|
68478
|
68478
68478-90D00 Plate, Front Slide Door Arm Stopper[01.1986 - 05.1988] BU60 |
68478-90D00 |
US $5.10 |
||
|
68487
|
68487
68487-90D04
Guide, Front Slide Door Lower Roller, Rh
[01.1986 - 08.1987] BU60 |
68487-90D04 |
— | ||
|
68487
|
68487
68487-90D06 Guide, Front Slide Door Lower Roller, Rh[08.1987 - 10.1989] BU60 |
68487-90D06 |
US $50.09 |
||
| replacement | |||||
|
68487
|
68487
68487-90D07 Guide, Front Slide Door Lower Roller, Rh[08.1987 - 10.1989] BU60 |
68487-90D07 |
US $50.09 |
||
|
68487
|
68487
68487-90D07 Guide, Front Slide Door Lower Roller, Rh[10.1989 - 05.1995] BU60..CBU |
68487-90D07 |
US $50.09 |
||
|
68491
|
68491
68491-90D00 Packing, Front Slide Door Lower Roller[02.1986 - 05.1988] BU60 |
68491-90D00 |
US $1.46 |
||
|
68703A
|
68703A
68704-26010 Hinge Sub-Assy, Front Slide Door, Upper Rh[01.1991 - 05.1995] BU60..CBU |
68704-26010 |
US $33.49 |
||
|
68703A
|
68703A
68704-90D00 Hinge Sub-Assy, Front Slide Door, Upper Rh[01.1986 - 05.1988] BU60 |
68704-90D00 |
US $36.55 |
||
| replacement | |||||
|
68703A
|
68703A
68704-26010 Hinge Sub-Assy, Front Slide Door, Upper Rh[01.1986 - 05.1988] BU60 |
68704-26010 |
US $33.49 |
||
|
69405A
|
69405A
69405-90D03 Stop, Front Slide Door[01.1986 - 08.1987] BU60 LH |
69405-90D03 |
US $36.11 |
||
|
69405A
|
69405A
69405-90D04 Stop, Front Slide Door[01.1986 - 08.1987] BU60 RH |
69405-90D04 |
US $36.25 |
||
|
69405A
|
69405A
69405-90D05 Stop, Front Slide Door[08.1987 - 05.1988] BU60 RH |
69405-90D05 |
US $46.45 |
||
|
69405A
|
69405A
69406-90D00 Stop, Front Slide Door[08.1987 - 05.1988] BU60 LH |
69406-90D00 |
US $39.89 |
||
|
69413A
|
69413A
69406-95J00
Stop Sub-Assy, Slide Door Down Male
[01.1986 - 03.1988] BU60 |
69406-95J00 |
— | ||
| replacement | |||||
|
69413A
|
69413A
69416-95J00 Stop, Front Slide Door Down Male[01.1986 - 03.1988] BU60 |
69416-95J00 |
US $19.99 |
||
|
69413A
|
69413A
69406-95J01
Stop Sub-Assy, Slide Door Down Male
[03.1988 - 05.1988] BU60 |
69406-95J01 |
— | ||
| replacement | |||||
|
69413A
|
69413A
69416-95J00 Stop, Front Slide Door Down Male[03.1988 - 05.1988] BU60 |
69416-95J00 |
US $19.99 |
||
|
69415A
|
69415A
69415-95J00
Stopper, Slide Door Down Female
[01.1986 - 05.1988] BU60 |
69415-95J00 |
— | ||
| replacement | |||||
|
69415A
|
69415A
69415-95J01 Stopper, Slide Door Down Female[01.1986 - 05.1988] BU60 |
69415-95J01 |
US $11.11 |
||
|
69415A
|
69415A
69415-95J01 Stopper, Slide Door Down Female[06.1989 - 08.1991] BU60..CBU |
69415-95J01 |
US $11.11 |
||
|
69418A
|
69418A
69418-95700 Shim, Slide Door Down Stop Male[01.1986 - 05.1988] BU60 |
69418-95700 |
US $1.69 |
||
|
69428A
|
69428A
69428-90D00 Pad, Front Slide Door Down Stop, Male[01.1986 - 05.1988] BU60 |
69428-90D00 |
US $4.66 |
||
|
69429
|
69429
69429-90D00 Pad, Front Slide Door Down Stop, Femail[01.1986 - 05.1988] BU60 |
69429-90D00 |
US $4.66 |
||
|
75498B
|
75498B
75498-90F00
Seal, Outside Moulding, No.2
[10.1987 - 05.1995] BU60..N..3D ﾔﾏﾄｳﾝﾕ ｸ-ﾙﾎﾞﾂｸｽ ｼﾖｳ,30 X 20 |
75498-90F00 |
— | ||
|
75498B
|
75498B
75498-90F01 Seal, Outside Moulding, No.2[08.1990 - 11.1990] BU60..N |
75498-90F01 |
US $2.87 |
||
|
9011906428
|
9011906428
90119-06428 New Genuine Part |
90119-06428 |
US $1.43 |
||
|
9017608046
|
9017608046
90176-08046 New Genuine Part |
90176-08046 |
US $1.75 |
||
|
9017906194
|
9017906194
90179-06194
Nut (For Rear Wiper Arm Setting)
|
90179-06194 |
— | ||
| replacement | |||||
|
9017906194
|
9017906194
90179-06178 Nut (For Rear Wiper Arm Setting) |
90179-06178 |
from US $0.76 |
||
|
9017908041
|
9017908041
90179-08041
NUT
|
90179-08041 |
— | ||
| replacement | |||||
|
9017908041
|
9017908041
90179-08017 NUT |
90179-08017 |
from US $0.76 |
||
|
9017908046
|
9017908046
90179-08046 New Genuine Part |
90179-08046 |
US $3.58 |
||
|
9020208039
|
9020208039
90202-08039 WASHER |
90202-08039 |
US $3.76 |
||
|
9020910010
|
9020910010
90209-10010 New Genuine Part |
90209-10010 |
US $6.99 |
||
|
9024508013
|
9024508013
90245-08013 New Genuine Part |
90245-08013 |
US $5.56 |
||
|
9038908026
|
9038908026
90389-08026 New Genuine Part |
90389-08026 |
US $7.35 |
||
|
9056006020
|
9056006020
90560-06020 New Genuine Part |
90560-06020 |
US $1.46 |
||
|
9161160616
|
9161160616
91611-60616
Bolt(For Transaxle Case Receiver)
|
91611-60616 |
— | ||
| replacement | |||||
|
9161160616
|
9161160616
91611-B0616 Bolt(For Transaxle Case Receiver) |
91611-B0616 |
from US $0.84 |
||
|
9165160620
|
9165160620
91651-60620 BOLTWWASHER |
91651-60620 |
US $1.43 |
||
|
9165160820
|
9165160820
91651-60820
Bolt, Radiator Side Support Plate
|
91651-60820 |
— | ||
| replacement | |||||
|
9165160820
|
9165160820
91651-B0820 Bolt, Radiator Side Support Plate |
91651-B0820 |
from US $0.97 |
||
|
9165660618
|
9165660618
91656-60618 Bolt (For Rear Differential Breather Plug Oil Deflector) |
91656-60618 |
US $1.89 |
||
| replacement | |||||
|
9165660618
|
9165660618
91651-60614 Bolt |
91651-60614 |
from US $1.16 |
||
|
9166160616
|
9166160616
91661-60616 BOLT |
91661-60616 |
from US $0.68 |
||
|
9166160814
|
9166160814
91661-60814 New Genuine Part |
91661-60814 |
US $1.02 |
||
|
9166160825
|
9166160825
91661-60825 New Genuine Part |
91661-60825 |
US $2.69 |
||
|
9322066020
|
9322066020
93220-66020 New Genuine Part |
93220-66020 |
US $0.87 |
||
|
9461110800
|
9461110800
94611-10800 Washer, Plate (For Transmission Control Cable) |
94611-10800 |
from US $0.84 |
||
|
9616000600
|
9616000600
96160-00600 Ring, E(For Clutch Pedal Pawl) |
96160-00600 |
from US $0.82 |
||
