Front Spring & Shock Absorber ([10.2006 - ] 3-LEAF (0610- )XZU334,344..35T,40T) Diagram Toyota DYNA/ TOYOACE
- Year
- 2006 - 2011
- Sales region
- Japan
- Frame
- XZU334
- ENGINE
- N04C
- TRANSMISSION
- MTM
- DECK
- T3
- CAB
- SCB
- Model
- DYNA/TOYOACE
- From
- 10.2006
- To
- 06.2011
- Gear Shift Type
- 5F
- Body Shape
- 1NO
- Loading Capacity
- 40T
- Fuel Induction
- DCRTK
- Building Condition
- IV3
- Rear Tire
- WT
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
48110
|
48110
48110-3V540 Spring Assy, Front, Rh[10.2006 -] XZU334,344..35T,40T ３枚リーフ |
48110-3V540 |
US $548.91 |
||
|
48110F
|
48110F
90389-16025 Bush, Front Spring No.2 Shackle[10.2006 -] XZU304,314,334,354,554;BZU300,340,TRU300,XZU324,344,504,524..SCB..(DM6,DM7,T3,T4) フロント |
90389-16025 |
US $24.36 |
||
|
48110F
|
48110F
90389-16026 Bush, Front Spring No.2 Shackle[10.2006 -] XZU304,314,334,354,554;BZU300,340,TRU300,XZU324,344,504,524..SCB..(DM6,DM7,T3,T4) リヤ |
90389-16026 |
from US $15.95 |
||
|
48111
|
48111
48101-3V540 Leaf, Front Spring, No.1[10.2006 -] XZU334,344..35T,40T 運転席側 |
48101-3V540 |
US $214.03 |
||
|
48111
|
48111
48101-3V550
Leaf, Front Spring, No.1
[10.2006 -] XZU334,344..35T,40T 助手席側 |
48101-3V550 |
— | ||
|
48112
|
48112
48112-3V540 Leaf, Front Spring, No.2[10.2006 -] XZU334,344..35T,40T 運転席側 |
48112-3V540 |
US $157.25 |
||
|
48112
|
48112
48112-3V550 Leaf, Front Spring, No.2[10.2006 -] XZU334,344..35T,40T 助手席側 |
48112-3V550 |
US $157.25 |
||
|
48113
|
48113
48102-3V540 Leaf, Front Spring, No.3[10.2006 -] XZU334,344..35T,40T 運転席側 |
48102-3V540 |
US $179.09 |
||
|
48113
|
48113
48102-3V550 Leaf, Front Spring, No.3[10.2006 -] XZU334,344..35T,40T 助手席側 |
48102-3V550 |
US $179.09 |
||
|
48120
|
48120
48110-3V550 Spring Assy, Front, Lh[10.2006 -] XZU334,344..35T,40T ３枚リーフ |
48110-3V550 |
US $548.91 |
||
|
48147
|
48147
48147-37470 Bolt, Front Spring, Center[10.2006 -] XZU334,344..35T,40T |
48147-37470 |
US $6.12 |
||
|
48147A
|
48147A
48155-3B470 Nut, Front Spring Center Bolt[10.2006 -] XZU334,344,354..35T,40T |
48155-3B470 |
US $1.43 |
||
|
48153
|
48153
48152-37270 Seat, Front Spring[10.2006 -] XZU334,344..35T,40T |
48152-37270 |
US $7.28 |
||
|
48153A
|
48153A
48153-37270 Silencer, Front Spring, No.1[10.2006 -] XZU334,344..35T,40T |
48153-37270 |
US $7.28 |
||
|
48253C
|
48253C
48115-37510 Spacer, Front Leaf Spring, No.2[10.2006 -] XZU334,344..35T,40T |
48115-37510 |
US $56.06 |
