Front Spring & Shock Absorber ([10.2006 - ] 3-LEAF (0610- )ST) Diagram Toyota DYNA/ TOYOACE
- Year
- 2006 - 2011
- Sales region
- Japan
- Frame
- XZU504
- ENGINE
- N04C
- TRANSMISSION
- MTM
- DECK
- T5
- CAB
- SCB
- Model
- DYNA/TOYOACE
- From
- 10.2006
- To
- 06.2011
- Gear Shift Type
- 5F
- Body Shape
- 4NO
- Loading Capacity
- 20T
- Fuel Induction
- DCRTH
- Building Condition
- CBU
- Rear Tire
- ST
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
48110
|
48110
48110-37D30 Spring Assy, Front, Rh[10.2006 -] XZU504..ST ３枚リーフ |
48110-37D30 |
US $509.60 |
||
| replacement | |||||
|
48110
|
48110
48110-37D31 Spring Assy, Front, Rh[10.2006 -] XZU504..ST ３枚リーフ |
48110-37D31 |
US $463.01 |
||
|
48110F
|
48110F
90389-16026 Bush, Front Spring No.2 Shackle[10.2006 -] XZU504..ST;TRU300,340,500..20T |
90389-16026 |
from US $15.95 |
||
|
48111
|
48111
48101-37D30 Leaf, Front Spring, No.1[10.2006 -] XZU504..ST 運転席側 |
48101-37D30 |
US $203.84 |
||
| replacement | |||||
|
48111
|
48111
48101-37351 Leaf, Front Spring, No.1[10.2006 -] XZU504..ST 運転席側 |
48101-37351 |
US $203.84 |
||
|
48111
|
48111
48101-37D40 Leaf, Front Spring, No.1[10.2006 -] XZU504..ST 助手席側 |
48101-37D40 |
US $203.84 |
||
| replacement | |||||
|
48111
|
48111
48101-37361 Leaf, Front Spring, No.1[10.2006 -] XZU504..ST 助手席側 |
48101-37361 |
US $203.84 |
||
|
48112
|
48112
48112-37D30 Leaf, Front Spring, No.2[10.2006 -] XZU504..ST 運転席側 |
48112-37D30 |
US $148.51 |
||
| replacement | |||||
|
48112
|
48112
48112-37351 Leaf, Front Spring, No.2[10.2006 -] XZU504..ST 運転席側 |
48112-37351 |
US $148.51 |
||
|
48112
|
48112
48112-37D40 Leaf, Front Spring, No.2[10.2006 -] XZU504..ST 助手席側 |
48112-37D40 |
US $148.51 |
||
| replacement | |||||
|
48112
|
48112
48112-37361 Leaf, Front Spring, No.2[10.2006 -] XZU504..ST 助手席側 |
48112-37361 |
US $148.51 |
||
|
48113
|
48113
48102-37D30 Leaf, Front Spring, No.3[10.2006 -] XZU504..ST 運転席側 |
48102-37D30 |
US $163.07 |
||
| replacement | |||||
|
48113
|
48113
48102-37351
Leaf, Front Spring, No.3
[10.2006 -] XZU504..ST 運転席側 |
48102-37351 |
— | ||
|
48113
|
48113
48102-37D40 Leaf, Front Spring, No.3[10.2006 -] XZU504..ST 助手席側 |
48102-37D40 |
US $163.07 |
||
| replacement | |||||
|
48113
|
48113
48102-37361
Leaf, Front Spring, No.3
[10.2006 -] XZU504..ST 助手席側 |
48102-37361 |
— | ||
|
48120
|
48120
48110-37D40 Spring Assy, Front, Lh[10.2006 -] XZU504..ST ３枚リーフ |
48110-37D40 |
US $509.60 |
||
| replacement | |||||
|
48120
|
48120
48110-37D41 Spring Assy, Front, Lh[10.2006 -] XZU504..ST ３枚リーフ |
48110-37D41 |
US $463.01 |
||
|
48147
|
48147
48147-37410 Bolt, Front Spring, Center[10.2006 -] XZU504..ST;XZU304,324..(DM7,T5)..30T |
48147-37410 |
US $6.41 |
||
| replacement | |||||
|
48147
|
48147
48147-37A01 Bolt, Front Spring, Center[10.2006 -] XZU504..ST;XZU304,324..(DM7,T5)..30T |
48147-37A01 |
US $5.82 |
||
|
48147A
|
48147A
48284-37130 Nut, Front Spring Center Bolt[10.2006 -] BZU300,340,TRU300,340,500,XZU304,314,324,334,344,354,504,524,554..20T,30T |
48284-37130 |
from US $1.11 |
||
|
48152
|
48152
48152-37D30 Seat, Front Spring[10.2006 -] XZU504;XZU304..T4..20T;XZU344..6FC..20T |
48152-37D30 |
US $60.42 |
||
| replacement | |||||
|
48152
|
48152
48114-37D31 Seat, Front Spring[10.2006 -] XZU504;XZU304..T4..20T;XZU344..6FC..20T |
48114-37D31 |
US $54.89 |
||
|
48153
|
48153
48253-3B440 Spacer, Front Leaf Spring, No.1[10.2006 -] TRU300,340,500;XZU304..30T..4NO;XZU304..DM3,DM6,T3;BZU300,XZU504..DM6,T5;BZU300,34 0,XZU314,324,334,344..30T; BZU300,340,XZU304,344,504..(T3,T4,T5)..20T..WT 3-LEAF |
48253-3B440 |
US $6.70 |
||
| replacement | |||||
|
48153
|
48153
48152-37J42 Spacer, Front Leaf Spring, No.1[10.2006 -] TRU300,340,500;XZU304..30T..4NO;XZU304..DM3,DM6,T3;BZU300,XZU504..DM6,T5;BZU300,34 0,XZU314,324,334,344..30T; BZU300,340,XZU304,344,504..(T3,T4,T5)..20T..WT 3-LEAF |
48152-37J42 |
US $5.97 |
||
|
48252D
|
48252D
48252-37380 Silencer, Rear Spring[10.2006 -] BZU300,340,TRU300,340,500,XZU304,314,324,334,344,354,504,524,554..20T,30T |
48252-37380 |
US $9.68 |
||
|
48253C
|
48253C
48253-3B770 Leaf, Front Spring, No.6[10.2006 -] XZU504..ST;TRU300,340,500..SCB..(DM5,T4)..20T |
48253-3B770 |
US $9.17 |
||
