Gear Shift Fork & Lever Shaft (Mtm) ([02.2016 - ] TL70 (1602- )) Diagram Toyota GT86
- Year
- 2016 - 2016
- Sales region
- Japan
- Frame
- GRMN86
- ENGINE
- FA20
- TRANSMISSION
- MTM
- From
- 02.2016
- To
- 05.2016
- Vehicle Model
- FR-SPORT
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
33213H
|
33213H
SU003-03620 Plug, W/head Straight Screw, No.2[02.2016 -] GRMN86 ＮＯ．１ |
SU003-03620 |
US $10.39 |
||
|
33213H
|
33213H
SU003-03861 Plug, W/head Straight Screw, No.2[02.2016 -] GRMN86 ＮＯ．２ |
SU003-03861 |
US $24.02 |
||
|
33251P
|
33251P
SU003-03882 Spring (For Shift & Select Lever)[02.2016 -] GRMN86 ＮＯ．１ |
SU003-03882 |
US $7.29 |
||
|
33251P
|
33251P
SU003-03883 Spring (For Shift & Select Lever)[02.2016 -] GRMN86 ＮＯ．２ |
SU003-03883 |
US $7.43 |
||
|
33292A
|
33292A
SU003-03638 Pin, Lock Ball[02.2016 -] GRMN86 ＮＯ．１ |
SU003-03638 |
US $22.28 |
||
|
33292A
|
33292A
SU003-03639 Pin, Lock Ball[02.2016 -] GRMN86 ＮＯ．２ |
SU003-03639 |
US $22.28 |
