Switch & Relay & Computer ([03.2005 - ] ｴﾝｼﾞﾝ & ﾄﾗﾝｽﾐｯｼｮﾝ (0503- )) Diagram Toyota HARRIER
- Year
- 2005 - 2012
- Sales region
- Japan
- Frame
- MHU38
- body
- WG
- ENGINE
- 3MZFE
- Model
- HARRIER HYBRID
- From
- 03.2005
- To
- 06.2012
- Vehicle Model
- Harrier Hybrid
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
83530
|
83530
83530-28020 Switch Assy, Oil Pressure (For Engine)[03.2005 -] MHU38 ＤＥＮＳＯ |
83530-28020 |
from US $23.56 |
||
| replacement | |||||
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [03.2005 -] MHU38 ＤＥＮＳＯ |
83530-60020 |
from US $23.22 |
||
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [03.2005 -] MHU38 ＹＡＺＡＫＩ |
83530-60020 |
from US $23.22 |
||
|
89465
|
89465
89465-48200 Sensor, Oxygen[03.2005 -] MHU38 |
89465-48200 |
US $126.67 |
||
|
89465A
|
89465A
89465-48210 Sensor, Oxygen No.2[03.2005 -] MHU38 |
89465-48210 |
US $126.67 |
||
|
89467B
|
89467B
89467-48060 Sensor, Air Fuel Ratio[03.2005 -] MHU38 |
89467-48060 |
from US $165.77 |
||
|
89467C
|
89467C
89467-48080 Sensor, Air Fuel Ratio, No.2[03.2005 -] MHU38 |
89467-48080 |
US $177.63 |
||
|
89615
|
89615
89615-20090 Sensor, Knock Control[03.2005 -] MHU38 |
89615-20090 |
from US $39.82 |
||
|
8271548A20
|
8271548A20
82715-48A20 Bracket,wiring Harness Clamp |
82715-48A20 |
US $12.23 |
||
|
8271548760
|
8271548760
82715-48760 Bracket,wiring Harness Clamp |
82715-48760 |
US $3.49 |
||
|
8761642020
|
8761642020
87616-42020 Clamp, Cooling Unit Case |
87616-42020 |
US $4.66 |
||
|
9012608039
|
9012608039
90126-08039 Bolt, Stud(For Oil Pan) |
90126-08039 |
US $4.30 |
||
|
9017908153
|
9017908153
90179-08153 NUT |
90179-08153 |
from US $0.76 |
||
|
9155180812
|
9155180812
91551-80812 BOLT FLANGE |
91551-80812 |
US $1.43 |
||
|
9167180616
|
9167180616
91671-80616 BOLT FLANGE |
91671-80616 |
from US $0.63 |
||
