Front Bumper & Bumper Stay ([02.1977 - 12.1980] (7702-8012)LH20,30,RH20,22,3#,42) Diagram Toyota HIACE
- Year
- 1979 - 1982
- Sales region
- Europe
- Frame
- LH20
- body
- V
- ENGINE
- L
- DESTINATION
- GEN
- Model
- HIACE
- From
- 09.1979
- To
- 11.1982
- Gear Shift Type
- 4H
- Seating Capacity
- 03S
- Vehicle Model
- Hiace
- Driver's Position
- RHD
- Building Condition
- CBU
- Truck Or Van
- V4D
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
52105
|
52105
52141-95A02
Stay Sub-Assy, Front Bumper, Rh
[02.1977 - 12.1980] LH20,30,RH20,22,3#,42..GEN CHROME PLATED; RH20..LHD..12S..EUR;LH20,30,RH20,22,3#..RHD..(EUR,SA) CHROME PLATED |
52141-95A02 |
— | ||
|
52106
|
52106
52142-95A02
Stay Sub-Assy, Front Bumper, Lh
[02.1977 - 12.1980] LH20,30,RH20,22,3#,42..GEN CHROME PLATED; RH20..LHD..12S..EUR;LH20,30,RH20,22,3#..RHD..(EUR,SA) CHROME PLATED |
52142-95A02 |
— | ||
|
52111
|
52111
52101-29105 Bumper Assy, FrontFRONT [12.1980 - 11.1982] LH20,30,RH20,22,3#,42..BUS,V |
52101-29105 |
US $417.87 |
||
| replacement | |||||
|
52111
|
52111
52101-95A16 Bumper Assy, Front[12.1980 - 11.1982] LH20,30,RH20,22,3#,42..BUS,V |
52101-95A16 |
US $442.62 |
||
|
52111
|
52111
52101-95A91 Bumper Assy, FrontFRONT [02.1977 - 12.1979] LH20,30,RH2#,3#,42..BUS,V |
52101-95A91 |
US $320.32 |
||
|
52111
|
52111
52111-95A91
Bumper Assy, Front
[02.1977 - 12.1980] LH20,30,RH20,22,3#,42..GEN CHROME PLATED; RH20..LHD..12S..EUR;LH20,30,RH20,22,3#..RHD..(EUR,SA) CHROME PLATED |
52111-95A91 |
— | ||
|
52119
|
52119
52109-95A00
Stay, Front Bumper, Center
[02.1977 - 12.1980] LH20,30,RH20,22,3#,42..GEN CHROME PLATED; RH20..LHD..12S..EUR;LH20,30,RH20,22,3#..RHD..(EUR,SA) CHROME PLATED |
52109-95A00 |
— | ||
|
9011208025
|
9011208025
90112-08025
Bolt, Round Head Square Neck(For Rear Bumper)
|
90112-08025 |
— | ||
|
9017908123
|
9017908123
90179-08123 Nut (For Front Wiper Arm Setting) |
90179-08123 |
from US $0.80 |
||
|
9165140816
|
9165140816
91651-40816 BOLT |
91651-40816 |
from US $0.98 |
||
|
9166640822
|
9166640822
91666-40822 New Genuine Part |
91666-40822 |
US $1.89 |
||
| replacement | |||||
|
9166640822
|
9166640822
91661-B0820 Bolt |
91661-B0820 |
US $2.87 |
||
