Rear Floor Panel & Rear Floor Member ([02.1977 - ] (7702- )LH20,RH20,22) Diagram Toyota HIACE
- Year
- 1979 - 1982
- Sales region
- Europe
- Frame
- LH20
- body
- V
- ENGINE
- L
- DESTINATION
- GEN
- Model
- HIACE
- From
- 09.1979
- To
- 11.1982
- Gear Shift Type
- 4H
- Seating Capacity
- 03S
- Vehicle Model
- Hiace
- Driver's Position
- RHD
- Building Condition
- CBU
- Truck Or Van
- V4D
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
51710A
|
51710A
62313-95A01
Moulding, Side Door Step Opening
[02.1978 - 11.1982] LH20,30,RH20,22,3#..V |
62313-95A01 |
— | ||
|
51720
|
51720
51704-95A00
Cover Assy, Side Door Step Plate, Lh
[02.1978 - 11.1982] LH20,30,RH20,22,3#..RHD..V |
51704-95A00 |
— | ||
|
51790
|
51790
58304-95A00 Step Assy, Rear FloorREAR FLOOR [09.1977 - 12.1980] LH20,30,RH20,22,3#..RHD..V LH; LH20,30,RH20,22,3#..LHD..V5D LH |
58304-95A00 |
US $337.79 |
||
| replacement | |||||
|
51790
|
51790
58304-95A09 Step Assy, Rear FloorREAR FLOOR [09.1977 - 12.1980] LH20,30,RH20,22,3#..RHD..V LH; LH20,30,RH20,22,3#..LHD..V5D LH |
58304-95A09 |
US $305.76 |
||
|
51790
|
51790
58304-95A09 Step Assy, Rear FloorREAR FLOOR [12.1980 - 11.1982] LH20,30,RH20,22,3#..RHD..V LH; LH20,30,RH20,22,3#..LHD..V5D LH |
58304-95A09 |
US $305.76 |
||
|
57311
|
57311
57301-95A01
Outrigger, No.1 Rh
[02.1977 - 11.1982] LH20,30,RH20,22,3#..RHD..V4D |
57301-95A01 |
— | ||
|
57313
|
57313
57317-95A00
Outrigger, No.2 Rh
[02.1977 - 11.1982] LH20,30,RH20,22,3#..RHD..V4D; RH42 |
57317-95A00 |
— | ||
|
57315
|
57315
57315-95A01
Outrigger, No.3 Rh
[10.1977 - 11.1982] LH20,30,RH20,22,3#..RHD..V4D; LH20,RH20,22..RHD..BUS |
57315-95A01 |
— | ||
|
57321
|
57321
57303-95A00
Outrigger, No.3 Rh
[02.1977 - 11.1982] LH30,RH3#..V; LH20,RH20,22..RHD..V4D |
57303-95A00 |
— | ||
|
57337
|
57337
57305-95A05
Outrigger, Rear Rh
[12.1979 - 11.1982] RH22..SA; RH42; LH20,30,RH20,22,3#..V; RH3#..12S; RH20,22..09S..GEN |
57305-95A05 |
— | ||
|
57337
|
57337
57317-95A00
Outrigger, No.2 Rh
[02.1977 - 12.1979] RH42; LH20,30,RH2#,3#..V; RH3#..12S; RH2#..09S..GEN |
57317-95A00 |
— | ||
|
57338
|
57338
57306-95A04
Outrigger, Rear Lh
[12.1979 - 11.1982] RH22..SA; RH42; LH20,30,RH20,22,3#..V; RH3#..12S; RH20,22..09S..GEN |
57306-95A04 |
— | ||
|
57338
|
57338
57318-95A00
Outrigger, No.2 Lh
[02.1977 - 12.1979] RH42; LH20,30,RH2#,3#..V; RH3#..12S; RH2#..09S..GEN |
57318-95A00 |
— | ||
|
9046216027
|
9046216027
90462-16027 Clamp, Side Door Step Opening |
90462-16027 |
US $2.48 |
||
|
9048001050
|
9048001050
90480-01050
New Genuine Part
|
90480-01050 |
— | ||
|
9048050223
|
9048050223
90480-50223
New Genuine Part
|
90480-50223 |
— | ||
|
9048054002
|
9048054002
90480-54002
New Genuine Part
|
90480-54002 |
— | ||
|
9095001009
|
9095001009
90950-01009 New Genuine Part |
90950-01009 |
US $8.88 |
||
|
9095001056
|
9095001056
90950-01056
Plug, Hole(For Floor Panel)
|
90950-01056 |
— | ||
| replacement | |||||
|
9095001056
|
9095001056
90950-01826 Plug, Hole(For Floor Panel) |
90950-01826 |
from US $1.99 |
||
|
9095001204
|
9095001204
90950-01204 New Genuine Part |
90950-01204 |
US $7.13 |
||
|
9326056012
|
9326056012
93260-56012 SCREW |
93260-56012 |
US $0.52 |
||
