Oil Cooler & Tube (Atm) ([12.1982 - 08.1985] (8212-8508)LH5#,61..ATM) Diagram Toyota HIACE
- Year
- 1984 - 1985
- Sales region
- Japan
- Frame
- LH51G
- grade
- SCM
- body
- WG
- Roof
- SRF
- ENGINE
- 2L
- TRANSMISSION
- ATM
- Model
- HIACE VAN/WAGON/COMMUTER BUS
- From
- 01.1984
- To
- 08.1985
- Gear Shift Type
- 4FC
- Seating Capacity
- 08S
- Vehicle Model
- Hiace Van,Wagon
- Fuel Induction
- DSL
- Rear Tire
- ST
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
32906
|
32906
32906-26020 Tube Sub-Assy, Oil Cooler[12.1982 - 08.1985] LH5#,61,YH51,61..ATM |
32906-26020 |
US $104.83 |
||
|
32906
|
32906
32906-26030 Tube Sub-Assy, Oil Cooler[08.1985 - 08.1987] YH51,61..ATM; LH51,61..ATM..DSL |
32906-26030 |
US $59.40 |
||
|
32906A
|
32906A
90445-14091 Hose, Oil Cooler Tube(For Inlet)[12.1982 - 08.1985] LH5#,61,YH51,61..ATM |
90445-14091 |
US $5.10 |
||
| replacement | |||||
|
32906A
|
32906A
90445-14092 Hose(For Oil Cooler Inlet)[12.1982 - 08.1985] LH5#,61,YH51,61..ATM |
90445-14092 |
US $24.17 |
||
|
32906A
|
32906A
90445-16029 Hose, Oil Cooler Tube(For Inlet)[08.1985 - 08.1987] LH51,61,YH51,61..ATM |
90445-16029 |
US $7.13 |
||
|
32906B
|
32906B
90445-14091 Hose, Oil Cooler Tube(For Inlet)[12.1982 - 08.1985] LH5#,61,YH51,61..ATM |
90445-14091 |
US $5.10 |
||
| replacement | |||||
|
32906B
|
32906B
90445-14092 Hose(For Oil Cooler Inlet)[12.1982 - 08.1985] LH5#,61,YH51,61..ATM |
90445-14092 |
US $24.17 |
||
|
32906B
|
32906B
90445-16029 Hose, Oil Cooler Tube(For Inlet)[08.1985 - 08.1987] LH51,61,YH51,61..ATM |
90445-16029 |
US $7.13 |
||
|
32921
|
32921
32921-26030 Tube, Oil Cooler Inlet, No.1[12.1982 - 08.1985] LH5#,61..ATM |
32921-26030 |
US $27.08 |
||
|
32921C
|
32921C
90404-14007 Union(For Oil Cooler Tube)[12.1982 - 08.1985] LH5#,61,YH51,61..ATM |
90404-14007 |
US $5.23 |
||
|
32921C
|
32921C
90404-16021 Union(For Oil Cooler Tube)[08.1985 - 08.1987] LH51..4FC..TD FR; YH51,61..ATM FR; LH51,61..ATM..DSL FR |
90404-16021 |
US $7.34 |
||
|
32921D
|
32921D
90445-14092 Hose(For Oil Cooler Inlet)[12.1982 - 08.1985] LH5#,61..ATM |
90445-14092 |
US $24.17 |
||
|
32921D
|
32921D
90445-16035 Hose(For Oil Cooler Inlet)[08.1985 - 08.1987] LH51,61..ATM..DSL |
90445-16035 |
US $22.86 |
||
|
32921E
|
32921E
90460-14085
Clamp, Hose(For Oil Cooler)
[12.1982 - 08.1985] LH5#,61,YH51,61..ATM |
90460-14085 |
— | ||
| replacement | |||||
|
32921E
|
32921E
90460-20004 Clamp, Hose(For Oil Cooler)[12.1982 - 08.1985] LH5#,61,YH51,61..ATM |
90460-20004 |
US $3.14 |
||
|
32921E
|
32921E
90460-18002 Clamp, Hose(For Oil Cooler)[08.1985 - 08.1987] LH51,61,YH51,61..ATM |
90460-18002 |
US $4.22 |
||
|
32921G
|
32921G
90301-10189 Ring, O(For Oil Cooler Tube Union)[12.1982 - 08.1987] LH50,51,61,YH51,61..ATM |
90301-10189 |
from US $2.63 |
||
|
32921H
|
32921H
90402-14004 Nut, Union(For Oil Cooler Tube)[12.1982 - 08.1985] LH5#,61,YH51,61..ATM |
90402-14004 |
US $3.32 |
||
|
32922
|
32922
32922-26030 Tube, Oil Cooler Outlet, No.1[12.1982 - 08.1985] LH5#,61..ATM |
32922-26030 |
US $28.54 |
||
|
32922A
|
32922A
90445-14092 Hose(For Oil Cooler Inlet)[12.1982 - 08.1985] LH5#,61..ATM |
90445-14092 |
US $24.17 |
||
|
32922A
|
32922A
90445-16035 Hose(For Oil Cooler Inlet)[08.1985 - 08.1987] LH51,61..ATM..DSL |
90445-16035 |
US $22.86 |
||
|
32923
|
32923
32923-26040 Clamp, Automatic Transmission Oil Cooler Tube[08.1985 - 08.1987] LH51,61..ATM..DSL |
32923-26040 |
US $13.25 |
||
|
32923
|
32923
32923-30090 Clamp, Automatic Transmission Oil Cooler Tube[12.1982 - 08.1985] LH5#,61..ATM |
32923-30090 |
US $9.17 |
||
|
32923A
|
32923A
90462-12044 Clamp, Automatic Transmission Oil Cooler Tube[08.1985 - 08.1987] LH51,61,YH51,61..ATM |
90462-12044 |
US $2.91 |
||
|
32923A
|
32923A
90462-12085 Clamp, Automatic Transmission Oil Cooler Tube[12.1982 - 08.1985] LH5#,61,YH51,61..ATM |
90462-12085 |
US $2.91 |
||
|
32924
|
32924
32924-26011
Clamp, Oil Cooler Tube, No.2
[12.1982 - 07.1984] LH5#,61..ATM |
32924-26011 |
— | ||
|
32924
|
32924
32924-26012 Clamp, Oil Cooler Tube, No.2[07.1984 - 08.1985] LH51,61..ATM |
32924-26012 |
US $22.57 |
||
|
32924
|
32924
32924-26040 Clamp, Oil Cooler Tube, No.2[08.1985 - 08.1987] LH51,61..ATM..DSL |
32924-26040 |
US $21.99 |
||
|
32924A
|
32924A
90462-12044 Clamp, Automatic Transmission Oil Cooler Tube[08.1985 - 08.1987] LH51,61..ATM |
90462-12044 |
US $2.91 |
||
|
32924A
|
32924A
90462-12085 Clamp, Automatic Transmission Oil Cooler Tube[12.1982 - 08.1985] LH5#,61..ATM |
90462-12085 |
US $2.91 |
||
|
32926
|
32926
32926-30011 Cushion, Oil Cooler Tube(Atm)[12.1982 - 08.1985] LH5#,61,YH51,61..ATM 長さ＝２５，内径＝８ |
32926-30011 |
US $1.89 |
||
|
32926
|
32926
32926-30020 Cushion, Oil Cooler Tube(Atm)[08.1985 - 08.1987] LH51,61,YH51,61..ATM 長さ＝３５，内径＝１０ |
32926-30020 |
US $3.05 |
||
|
32928
|
32928
32928-26010 Clamp, Flexible Hose, No.1[08.1985 - 08.1987] LH51,61..ATM |
32928-26010 |
US $8.30 |
||
|
32928
|
32928
90462-06012 Clamp, Flexible Hose, No.1[12.1982 - 08.1985] LH5#,61,YH51,61..ATM |
90462-06012 |
US $9.03 |
||
|
9161140612
|
9161140612
91611-40612
Bolt(for Dust Cover To Steering Knuckle Arm Setting)
|
91611-40612 |
— | ||
| replacement | |||||
|
9161140612
|
9161140612
91611-G0612 Bolt(For Dust Cover To Steering Knuckle Arm Setting) |
91611-G0612 |
from US $0.78 |
||
|
9161140812
|
9161140812
91611-40812
Bolt(for Drive Plate & Torque Converter Setting)
|
91611-40812 |
— | ||
| replacement | |||||
|
9161140812
|
9161140812
91611-B0812 Bolt |
91611-B0812 |
from US $0.76 |
||
