Radio Receiver & Amplifier & Condenser ([01.1984 - ] (8401- )LH51,YH51..07S,08S) Diagram Toyota HIACE
- Year
- 1984 - 1985
- Sales region
- Japan
- Frame
- LH51G
- grade
- SCM
- body
- WG
- Roof
- SRF
- ENGINE
- 2L
- TRANSMISSION
- ATM
- Model
- HIACE VAN/WAGON/COMMUTER BUS
- From
- 01.1984
- To
- 08.1985
- Gear Shift Type
- 4FC
- Seating Capacity
- 08S
- Vehicle Model
- Hiace Van,Wagon
- Fuel Induction
- DSL
- Rear Tire
- ST
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
86280
|
86280
86280-95J03
Amplifier Assy, Stereo Component
[01.1984 - 08.1987] LH51,YH51..07S,08S NO.2,W/*SIS |
86280-95J03 |
— | ||
|
86280
|
86280
86280-95J05 Amplifier Assy, Stereo Component[01.1984 - 08.1987] LH51,YH51..07S,08S *SIS CONTROLLER |
86280-95J05 |
US $2,009.28 |
||
|
86280E
|
86280E
86280-29115
Amplifier Set, Stereo Component
[01.1984 - 08.1987] LH51,YH51..07S,08S W/*SIS |
86280-29115 |
— | ||
|
86297
|
86297
86297-95J00 Microphone, Wireless[01.1984 - 08.1987] LH51,YH51..07S,08S W/*SIS |
86297-95J00 |
US $422.24 |
||
|
7451195J01
|
7451195J01
74511-95J01 Plate, Heater Name, No.1 |
74511-95J01 |
US $4.08 |
||
|
9322915008
|
9322915008
93229-15008 SCREW |
93229-15008 |
US $1.43 |
||
|
9331915008
|
9331915008
93319-15008 SCREW |
93319-15008 |
US $3.05 |
