Heating & Air Conditioning - Control & Air Duct ([12.1982 - 01.1984] (8212-8401)LH50,60,70..COM,WG..MTM) Diagram Toyota HIACE
- Year
- 1982 - 1984
- Sales region
- Japan
- Frame
- LH60B
- grade
- DLX
- body
- COM
- Roof
- SRF
- ENGINE
- L
- TRANSMISSION
- MTM
- Model
- HIACE VAN/WAGON/COMMUTER BUS
- From
- 12.1982
- To
- 01.1984
- Gear Shift Type
- 5H
- Seating Capacity
- 15S
- Vehicle Model
- Hiace Van,Wagon
- Fuel Induction
- DSL
- Rear Tire
- ST
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
82650D
|
82650D
82650-20010 Breaker Assy, Wiring Circuit, No.1[12.1982 - 01.1984] LH50,60,70..(COM,WG)..MTM |
82650-20010 |
US $17.18 |
||
| replacement | |||||
|
82650D
|
82650D
82650-20011 Breaker Assy, Wiring Circuit, No.1[12.1982 - 01.1984] LH50,60,70..(COM,WG)..MTM |
82650-20011 |
US $15.77 |
||
|
87346A
|
87346A
87346-90B02
Relay, Combustion Heater, No.1
[12.1982 - 01.1984] LH50,60,70..(COM,WG)..MTM |
87346-90B02 |
— | ||
|
87346B
|
87346B
88630-36080
Relay, Combustion Heater, No.2
[12.1982 - 01.1984] LH50,60,70..(COM,WG)..MTM |
88630-36080 |
— | ||
|
87346E
|
87346E
87480-90B00
Amplifier Assy, Conbustion Heater
[12.1982 - 01.1984] LH50,60,70..(COM,WG)..MTM |
87480-90B00 |
— | ||
|
87348C
|
87348C
87348-90B00
Block, Fuse
[12.1982 - 01.1984] LH50,60,70..(COM,WG)..MTM |
87348-90B00 |
— | ||
|
87446A
|
87446A
87446-95J00
Stay, Heater Control Panel
[12.1982 - 01.1984] LH50,60,70..(COM,WG)..MTM |
87446-95J00 |
— | ||
|
87460A
|
87460A
55173-95J01
Bracket, Electrical Parts
[12.1982 - 01.1984] LH50,60,70..(COM,WG)..MTM |
55173-95J01 |
— | ||
|
87490
|
87490
87491-95J00
Panel Assy, Heater Control
[12.1982 - 01.1984] LH50,60,70..(COM,WG)..MTM |
87491-95J00 |
— | ||
|
9015960038
|
9015960038
90159-60038 SCREWTAPPING |
90159-60038 |
US $3.40 |
||
|
9018905019
|
9018905019
90189-05019 New Genuine Part |
90189-05019 |
US $1.97 |
||
|
9165140616
|
9165140616
91651-40616 BOLT |
91651-40616 |
from US $0.74 |
||
| replacement | |||||
|
9165140616
|
9165140616
91621-60614 Bolt(For Transaxle & Engine Setting) |
91621-60614 |
from US $1.46 |
||
|
9324955008
|
9324955008
93249-55008 New Genuine Part |
93249-55008 |
US $0.73 |
||
