Front Turn Signal Lamp ([08.1989 - ] (8908- )) Diagram Toyota HIACE
- Year
- 1993 - 1995
- Sales region
- Europe
- Frame
- RZH109
- grade
- DX
- body
- V
- ENGINE
- 2RZE
- DESTINATION
- EUR
- Model
- HIACE VAN/WAGON/COMMUTER BUS
- From
- 08.1993
- To
- 08.1995
- Gear Shift Type
- 5F
- No.of Doors
- 4D
- Seating Capacity
- 09S
- Vehicle Model
- Hiace Van, Commuter Bus
- Driver's Position
- LHD
- Side Window
- SG
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
81510
|
81510
81510-26040
Lamp Assy, Front Turn Signal, Rh
[05.1992 - 08.1995] LH10#,11#,RZH10#,11# |
81510-26040 |
— | ||
|
81510B
|
81510B
99132-11210 Bulb (12V 21W)[08.1989 - 08.1995] LH10#,11#,RZH10#,11# 12V 21W |
99132-11210 |
from US $2.81 |
||
|
81510B
|
81510B
99132-12050 Bulb (12V 5W)[08.1989 - 08.1995] LH10#,11#,RZH10#,11# 12V 5W |
99132-12050 |
from US $1.97 |
||
| replacement | |||||
|
81510B
|
81510B
90080-81053 Bulb(For Clearance Lamp)[08.1989 - 08.1995] LH10#,11#,RZH10#,11# 12V 5W |
90080-81053 |
US $1.01 |
||
|
81511
|
81511
81511-26040
Lens, Front Turn Signal Lamp, Rh
[05.1992 - 08.1995] LH10#,11#,RZH10#,11# |
81511-26040 |
— | ||
|
81515
|
81515
81515-95J17 Wire Sub-Assy, Front Turn Signal Lamp BodyFRONT TURN SIGNAL LAMP BODY [08.1989 - 08.1995] LH10#,11#,RZH10#,11# |
81515-95J17 |
US $19.80 |
||
|
81520
|
81520
81520-26040
Lamp Assy, Front Turn Signal, Lh
[05.1992 - 08.1995] LH10#,11#,RZH10#,11# |
81520-26040 |
— | ||
|
81521
|
81521
81521-26040
Lens, Front Turn Signal Lamp, Lh
[05.1992 - 08.1995] LH10#,11#,RZH10#,11# |
81521-26040 |
— | ||
|
8127995700
|
8127995700
81279-95700
Washer, Side Turn Signal Lamp
|
81279-95700 |
— | ||
|
9095006001
|
9095006001
90950-06001 Protector, Front Side Panel, No.3 |
90950-06001 |
US $3.05 |
||
|
9356855012
|
9356855012
93568-55012 SCREW |
93568-55012 |
US $1.08 |
||
