Switch & Relay & Computer ([11.2016 - ] ENGINE & TRANSMISSION (1611- )ASU50) Diagram Toyota HIGHLANDER/ KLUGER
- Year
- 2013 - 2018
- Sales region
- General
- Frame
- ASU50
- grade
- LIMD
- ENGINE
- 1ARFE
- TRANSMISSION
- ATM
- DESTINATION
- RUS
- Model
- HIGHLANDER
- From
- 12.2013
- Gear Shift Type
- 6FC
- Vehicle Model
- Highlander
- Driver's Position
- LHD
- Fuel Induction
- HTWC
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
83530
|
83530
83530-0E010 Switch Assy, Oil Pressure (For Engine)[12.2013 - 11.2016] ASU50,GSU5# DENSO USA |
83530-0E010 |
from US $51.25 |
||
|
83530
|
83530
83530-28020 Switch Assy, Oil Pressure (For Engine)[12.2013 - 11.2016] ASU50,GSU5# DENSO JAPAN |
83530-28020 |
from US $29.33 |
||
| replacements | |||||
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [12.2013 - 11.2016] ASU50,GSU5# DENSO JAPAN |
83530-60020 |
from US $25.21 |
||
|
83530
|
83530
83530-0E010 Switch Assy, Oil Pressure (For Engine)[12.2013 - 11.2016] ASU50,GSU5# DENSO JAPAN |
83530-0E010 |
from US $51.25 |
||
|
84540
|
84540
84540-07010
Switch Assy, Neutral Start
[12.2013 - 11.2016] ASU50 |
84540-07010 |
— | ||
|
84540
|
84540
84540-33010 Switch Assy, Neutral Start[11.2016 -] ASU50 (J) |
84540-33010 |
from US $112.48 |
||
|
89465
|
89465
89465-0E110
Sensor, Oxygen
[12.2013 - 11.2016] ASU50 |
89465-0E110 |
— | ||
|
89467B
|
89467B
89467-06120
Sensor, Air Fuel Ratio
[12.2013 - 11.2016] ASU50 |
89467-06120 |
— | ||
|
89615
|
89615
89615-06010
Sensor, Knock Control
[12.2013 - 11.2016] ASU50 DENSO USA |
89615-06010 |
— | ||
|
89615
|
89615
89615-20090 Sensor, Knock Control[12.2013 - 11.2016] ASU50 DENSO JAPAN |
89615-20090 |
from US $36.02 |
||
|
90105A0120
|
90105A0120
90105-A0120
Bolt (For Front Oil Pump Setting)
|
90105-A0120 |
— | ||
|
90119A0182
|
90119A0182
90119-A0182 New Genuine Part |
90119-A0182 |
US $2.48 |
||
|
8271548A20
|
8271548A20
82715-48A20 Bracket,wiring Harness Clamp |
82715-48A20 |
US $12.23 |
||
|
8271506220
|
8271506220
82715-06220
Bracket,wiring Harness Clamp
|
82715-06220 |
— | ||
|
8761607010
|
8761607010
87616-07010
Clamp, Cooling Unit Case
|
87616-07010 |
— | ||
|
9008011227
|
9008011227
90080-11227
New Genuine Part
|
90080-11227 |
— | ||
|
9008011699
|
9008011699
90080-11699
Bolt, W/washer
|
90080-11699 |
— | ||
|
9155180835
|
9155180835
91551-80835 Bolt (For Front Oil Pump Setting) |
91551-80835 |
from US $1.28 |
||
|
9165140620
|
9165140620
91651-40620 BOLT |
91651-40620 |
US $1.12 |
||
