Air Cleaner ([07.2011 - ] (1107- )2KDFTV..KUN15..SMT..SR ; (1107- )2 KDFTV..KUN15,35..DLX..HDCR..TH) Diagram Toyota HILUX/4RUNNER TRUCK
- Year
- 2012 - 2015
- Sales region
- General
- Frame
- KUN15
- grade
- DLX
- ENGINE
- 2KDFTV
- DESTINATION
- TH
- DECK
- SD
- CAB
- SCB
- Model
- HILUX
- From
- 08.2012
- To
- 04.2015
- Gear Shift Type
- 5F
- Vehicle Model
- Hilux
- Driver's Position
- RHD
- Fuel Induction
- HDCR
- Building Condition
- CBU
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
17116
|
17116
17116-0L010
Gasket, Intake Flange
[08.2012 - 11.2013] 2KDFTV..KUN15..SMT..SR;1KDFTV..KUN26,36..5F..TH;2KDFTV..KUN15,35..DLX..TH THAI SPEC(EURO 3 REGULATION); 2KDFTV..KUN15..SCB..TH;2KDFTV..KUN15..SMT..SR THAI SPEC(EURO 3 REGULATION)&ENGINE-2KD-FTV |
17116-0L010 |
— | ||
|
17341G
|
17341G
90460-80006 Clamp, Hose[08.2012 - 11.2013] 2KDFTV..KUN15..SMT..SR;1KDFTV..KUN26,36..5F..TH;2KDFTV..KUN15,35..DLX..TH THAI SPEC(EURO 3 REGULATION); 2KDFTV..KUN15..SCB..TH;2KDFTV..KUN15..SMT..SR THAI SPEC(EURO 3 REGULATION)&ENGINE-2KD-FTV |
90460-80006 |
from US $8.33 |
||
|
17341K
|
17341K
17341-30060 Hose, Air, No.1AIR, NO.1 [08.2012 - 11.2013] 2KDFTV..KUN15..SMT..SR;1KDFTV..KUN26,36..5F..TH;2KDFTV..KUN15,35..DLX..TH THAI SPEC(EURO 3 REGULATION); 2KDFTV..KUN15..SCB..TH;2KDFTV..KUN15..SMT..SR THAI SPEC(EURO 3 REGULATION)&ENGINE-2KD-FTV |
17341-30060 |
from US $17.53 |
||
|
17342F
|
17342F
17342-30010 Hose, Air, No.2[08.2012 - 08.2014] 2KDFTV..KUN15..SCB..TH;2KDFTV..KUN15..SMT..SR THAI SPEC(EURO 3 REGULATION)&ENGINE-2KD-FTV |
17342-30010 |
from US $24.02 |
||
|
17342F
|
17342F
17342-30050 Hose, Air, No.2[08.2012 - 11.2013] 2KDFTV..KUN15..SMT..SR;2KDFTV..KUN15,35..DLX..TH THAI SPEC(EURO 3 REGULATION) |
17342-30050 |
from US $17.56 |
||
|
17861
|
17861
17860-0L020
Connector, Intake Air
[02.2013 - 08.2014] 2KDFTV..KUN15..SCB..TH;2KDFTV..KUN15..SMT..SR THAI SPEC(EURO 3 REGULATION)&ENGINE-2KD-FTV |
17860-0L020 |
— | ||
|
17861
|
17861
17860-0L030
Connector, Intake Air
[10.2012 - 11.2013] 2KDFTV..KUN15..SMT..SR;2KDFTV..KUN15,35..DLX..TH THAI SPEC(EURO 3 REGULATION) |
17860-0L030 |
— | ||
|
17861
|
17861
17860-30030
Connector, Intake Air
[08.2012 - 01.2013] 2KDFTV..KUN35..PHL; 1KDFTV..KUN26,36..5F..TH THAI SPEC(EURO 3 REGULATION); 2KDFTV..KUN15..SCB..TH;2KDFTV..KUN15..SMT..SR THAI SPEC(EURO 3 REGULATION)&ENGINE-2KD-FTV |
17860-30030 |
— | ||
| replacement | |||||
|
17861
|
17861
17860-0L020
Connector, Intake Air
[08.2012 - 01.2013] 2KDFTV..KUN35..PHL; 1KDFTV..KUN26,36..5F..TH THAI SPEC(EURO 3 REGULATION); 2KDFTV..KUN15..SCB..TH;2KDFTV..KUN15..SMT..SR THAI SPEC(EURO 3 REGULATION)&ENGINE-2KD-FTV |
17860-0L020 |
— | ||
|
17861
|
17861
17860-30040 Connector, Intake AirINTAKE AIR [08.2012 - 09.2012] 2KDFTV..KUN15..SMT..SR;2KDFTV..KUN15,35..DLX..TH THAI SPEC(EURO 3 REGULATION) |
17860-30040 |
US $101.92 |
||
|
17940D
|
17940D
17940-0L010
Intercooler Assy
[08.2012 - 08.2014] 2KDFTV..KUN15..SMT..SR;1KDFTV..KUN26,36..5F..TH;2KDFTV..KUN15,35..DLX..TH THAI SPEC(EURO 3 REGULATION) |
17940-0L010 |
— | ||
|
17940D
|
17940D
17940-0L060
Intercooler Assy
[08.2012 - 11.2013] 2KDFTV..KUN15..SCB..TH;2KDFTV..KUN15..SMT..SR THAI SPEC(EURO 3 REGULATION)&ENGINE-2KD-FTV |
17940-0L060 |
— | ||
|
17943
|
17943
12601-0L040
Cover Sub-Assy, Engine, No.1
[08.2012 - 08.2014] 2KDFTV..KUN15..SMT..SR;1KDFTV..KUN26,36..5F..TH;2KDFTV..KUN15,35..DLX..TH THAI SPEC(EURO 3 REGULATION) |
12601-0L040 |
— | ||
|
17943
|
17943
12601-0L050
Protector, Intercooler
[08.2012 - 08.2014] 2KDFTV..KUN15..SCB..TH;2KDFTV..KUN15..SMT..SR THAI SPEC(EURO 3 REGULATION)&ENGINE-2KD-FTV |
12601-0L050 |
— | ||
| replacement | |||||
|
17943
|
17943
12601-0L051
Cover Sub-Assy, Engine, No.1
[08.2012 - 08.2014] 2KDFTV..KUN15..SCB..TH;2KDFTV..KUN15..SMT..SR THAI SPEC(EURO 3 REGULATION)&ENGINE-2KD-FTV |
12601-0L051 |
— | ||
|
17943
|
17943
12601-0L051
Cover Sub-Assy, Engine, No.1
[01.2015 - 01.2016] 1KDFTV..KUN26..5FC..GEN;1KDFTV..KUN26..(5F,5FC)..(ARL,TH);2KDFTV..KUN35..(4FC,5F). .(PHL,TH);2KDFTV..KUN15..(DCB,SCB,SMT)..HDCR;1KDFTV,2KDFTV..KUN16,25,36..ARL,IDN,M A,TH |
12601-0L051 |
— | ||
|
17945
|
17945
17945-0L010
Bracket, Intercooler Support
[08.2012 - 08.2014] 2KDFTV..KUN15..SMT..SR;1KDFTV..KUN26,36..5F..TH;2KDFTV..KUN15,35..DLX..TH THAI SPEC(EURO 3 REGULATION),*130 |
17945-0L010 |
— | ||
|
17945
|
17945
17945-0L020
Bracket, Intercooler Support
[08.2012 - 08.2014] 2KDFTV..KUN15..SCB..TH;2KDFTV..KUN15..SMT..SR THAI SPEC(EURO 3 REGULATION)&ENGINE-2KD-FTV,*130 |
17945-0L020 |
— | ||
|
17945
|
17945
17945-30070
Bracket, Intercooler Support
[08.2012 - 08.2014] 2KDFTV..KUN15..SMT..SR;1KDFTV..KUN26,36..5F..TH;2KDFTV..KUN15,35..DLX..TH THAI SPEC(EURO 3 REGULATION),*360 |
17945-30070 |
— | ||
|
17945
|
17945
17945-30080
Bracket, Intercooler Support
[08.2012 - 08.2014] 2KDFTV..KUN15..SCB..TH;2KDFTV..KUN15..SMT..SR THAI SPEC(EURO 3 REGULATION)&ENGINE-2KD-FTV,*360 |
17945-30080 |
— | ||
|
17946
|
17946
17946-0L020
Bracket, Intercooler Support, No.2
[08.2012 - 08.2014] 2KDFTV..KUN15..SCB..TH;2KDFTV..KUN15..SMT..SR THAI SPEC(EURO 3 REGULATION)&ENGINE-2KD-FTV,*130 |
17946-0L020 |
— | ||
|
17946
|
17946
17946-30030
Bracket, Intercooler Support, No.2
[08.2012 - 08.2014] 2KDFTV..KUN15..SMT..SR;1KDFTV..KUN26,36..5F..TH;2KDFTV..KUN15,35..DLX..TH THAI SPEC(EURO 3 REGULATION),*130,*360 |
17946-30030 |
— | ||
|
17946
|
17946
17946-30040
Bracket, Intercooler Support, No.2
[08.2012 - 08.2014] 2KDFTV..KUN15..SCB..TH;2KDFTV..KUN15..SMT..SR THAI SPEC(EURO 3 REGULATION)&ENGINE-2KD-FTV,*360 |
17946-30040 |
— | ||
|
90105T0054
|
90105T0054
90105-T0054
New Genuine Part
|
90105-T0054 |
— | ||
|
90105T0070
|
90105T0070
90105-T0070
New Genuine Part
|
90105-T0070 |
— | ||
|
90119T0064
|
90119T0064
90119-T0064
BOLTWWSH
|
90119-T0064 |
— | ||
|
90119T0331
|
90119T0331
90119-T0331
New Genuine Part
|
90119-T0331 |
— | ||
|
9011906830
|
9011906830
90119-06830 BOLT WWASHER |
90119-06830 |
US $1.43 |
||
|
9017606019
|
9017606019
90176-06019 Nut (For Rear Wiper Arm Setting) |
90176-06019 |
US $1.97 |
||
|
9046057005
|
9046057005
90460-57005 Clamp Or Clip(For Air Hose, No.2) |
90460-57005 |
US $5.56 |
||
|
9167100816
|
9167100816
91671-00816 New Genuine Part |
91671-00816 |
US $1.97 |
||
