Manifold ([09.1999 - ] (9909- )1KZTE) Diagram Toyota HILUX/4RUNNER TRUCK
- Year
- 2002 - 2005
- Sales region
- General
- Frame
- KZN190
- grade
- SR
- ENGINE
- 1KZTE
- TRANSMISSION
- MTM
- DESTINATION
- SA
- CAB
- DCB
- Model
- HILUX
- From
- 03.2002
- To
- 04.2005
- Vehicle Model
- Hilux
- Driver's Position
- RHD
- Fuel Induction
- TDE
- Building Condition
- CBU
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
04175
|
04175
04175-67011 Gasket Kit, Turbocharger[09.2001 - 04.2005] 1KZTE..KZN165;1KZTE..KZN190..SR |
04175-67011 |
from US $59.75 |
||
|
17021A
|
17021A
90116-08158 Bolt, Stud(For Bearing Housing)[09.2001 - 04.2005] 1KZTE..KZN165,190..SR..SA |
90116-08158 |
US $5.56 |
||
|
17021B
|
17021B
90116-06048 Bolt, Stud(For Oil Pan)[09.2001 - 04.2005] 1KZTE..KZN165,190..SR..SA |
90116-06048 |
from US $0.66 |
||
|
17025A
|
17025A
90116-10175 Bolt, Stud(For Turbine Housing)[09.2001 - 04.2005] 1KZTE..KZN165,190..SR..SA NO.2 |
90116-10175 |
from US $1.21 |
||
|
17025A
|
17025A
90126-08009 Bolt, Stud(For Turbine Housing)[09.2001 - 04.2005] 1KZTE..KZN165,190..SR..SA NO.1 |
90126-08009 |
US $1.61 |
||
|
17201
|
17201
17201-67040 Turbocharger Sub-Assy[09.2001 - 04.2005] 1KZTE..KZN165,190..SR..SA |
17201-67040 |
US $3,049.30 |
||
|
17230A
|
17230A
17230-69145 Repair Actuaor Assy, W/bracket[09.2001 - 04.2005] 1KZTE..KZN165,190..SR..SA |
17230-69145 |
US $432.43 |
||
|
17230B
|
17230B
90201-08081 Washer, Plate(For Repair Actuator Set)[09.2001 - 04.2005] 1KZTE..KZN165,190..SR..SA T=0.5 |
90201-08081 |
US $2.51 |
||
|
17230B
|
17230B
90201-08082 Washer, Plate(For Repair Actuator Set)[09.2001 - 04.2005] 1KZTE..KZN165,190..SR..SA T=1.0 |
90201-08082 |
US $1.79 |
||
|
17230B
|
17230B
90201-08086 Washer, Plate(For Repair Actuator Set)[09.2001 - 04.2005] 1KZTE..KZN165,190..SR..SA T=2.0 |
90201-08086 |
US $1.46 |
||
|
17230B
|
17230B
90201-08087 Washer, Plate(For Repair Actuator Set)[09.2001 - 04.2005] 1KZTE..KZN165,190..SR..SA T=3.0 |
90201-08087 |
US $1.89 |
||
|
17230C
|
17230C
91621-60822 Bolt, W/washer(For Repair Actuator Set)[09.2001 - 04.2005] 1KZTE..KZN165,190..SR..SA |
91621-60822 |
US $1.61 |
||
|
17294
|
17294
90445-12265 Hose, Actuator[09.2001 - 04.2005] 1KZTE..KZN165,190..SR..SA |
90445-12265 |
US $3.99 |
||
|
17294A
|
17294A
96132-51100 Clip (For Hose)[09.2001 - 04.2005] 1KZTE..KZN165,190..SR..SA |
96132-51100 |
from US $1.42 |
||
|
91651B0820
|
91651B0820
91651-B0820 Bolt, Radiator Side Support Plate |
91651-B0820 |
from US $0.99 |
||
| replacement | |||||
|
91651B0820
|
91651B0820
90080-11347 New Genuine Part |
90080-11347 |
US $3.11 |
||
|
9052304002
|
9052304002
90523-04002 RING |
90523-04002 |
US $1.43 |
||
