Manifold ([08.1997 - 08.2001] (9708-0108)2LT) Diagram Toyota HILUX/4RUNNER TRUCK
- Year
- 1998 - 2001
- Sales region
- Europe
- Frame
- LN165
- grade
- DLX
- ENGINE
- 2LT
- TRANSMISSION
- MTM
- CAB
- DCB
- Model
- HILUX
- From
- 05.1998
- To
- 08.2001
- Vehicle Model
- Hilux
- Driver's Position
- LHD
- Building Condition
- IV3
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
04175
|
04175
04175-54030 Gasket Kit, Turbocharger[05.1998 - 08.2001] 2LT..LN165,170,190 |
04175-54030 |
US $68.14 |
||
|
16347
|
16347
16347-42020 Gasket, Water By-Pass[08.1997 - 08.2001] 2LT..LN165,170,190 |
16347-42020 |
from US $2.71 |
||
|
17021A
|
17021A
90116-08158 Bolt, Stud(For Bearing Housing)[08.1997 - 08.2001] 2LT..LN165,170,190 |
90116-08158 |
US $5.56 |
||
|
17025A
|
17025A
90116-08384 Bolt, Stud(For Turbine Housing)[05.1998 - 08.2001] 2LT..LN165,170,190 |
90116-08384 |
US $6.12 |
||
|
17201
|
17201
17201-54090 Turbocharger Sub-Assy[05.1998 - 08.2001] 2LT..LN165,170,190 |
17201-54090 |
from US $2,746.02 |
||
|
17230A
|
17230A
17230-59145 Repair Actuaor Assy, W/bracket[05.1998 - 08.2001] 2LT..LN165,170,190 |
17230-59145 |
US $324.69 |
||
|
17230B
|
17230B
90201-08081 Washer, Plate(For Repair Actuator Set)[08.1997 - 08.2001] 2LT..LN165,170,190 T=0.5 |
90201-08081 |
US $2.51 |
||
|
17230B
|
17230B
90201-08082 Washer, Plate(For Repair Actuator Set)[08.1997 - 08.2001] 2LT..LN165,170,190 T=1.0 |
90201-08082 |
US $1.79 |
||
|
17230B
|
17230B
90201-08086 Washer, Plate(For Repair Actuator Set)[08.1997 - 08.2001] 2LT..LN165,170,190 T=2.0 |
90201-08086 |
US $1.46 |
||
|
17230B
|
17230B
90201-08087 Washer, Plate(For Repair Actuator Set)[08.1997 - 08.2001] 2LT..LN165,170,190 T=3.0 |
90201-08087 |
US $1.89 |
||
|
17230C
|
17230C
91621-60822 Bolt, W/washer(For Repair Actuator Set)[08.1997 - 08.2001] 2LT..LN165,170,190 |
91621-60822 |
US $1.61 |
||
|
17294
|
17294
90445-12111
Hose(For Repair Actuator Set)
[08.1997 - 08.2001] 2LT..LN165,170,190 |
90445-12111 |
— | ||
|
17294A
|
17294A
96132-41100
Clamp Or Clip(For Radiator Reserve Tank Hose)
[08.1997 - 08.2001] 2LT..LN165,170,190 |
96132-41100 |
— | ||
| replacement | |||||
|
17294A
|
17294A
96132-51100 Clip (For Hose)[08.1997 - 08.2001] 2LT..LN165,170,190 |
96132-51100 |
from US $1.42 |
||
|
17296
|
17296
17296-28010 Plate, Bearing Housing, Side[08.1997 - 08.2001] 2LT..LN165,170,190 |
17296-28010 |
US $10.57 |
||
|
9011606048
|
9011606048
90116-06048 Bolt, Stud(For Oil Pan) |
90116-06048 |
from US $0.66 |
||
|
9017906018
|
9017906018
90179-06018 New Genuine Part |
90179-06018 |
US $0.83 |
||
|
9052304002
|
9052304002
90523-04002 RING |
90523-04002 |
US $1.43 |
||
|
9163560618
|
9163560618
91635-60618 New Genuine Part |
91635-60618 |
US $2.62 |
||
| replacement | |||||
|
9163560618
|
9163560618
91631-B0614 BOLT WWASHER |
91631-B0614 |
from US $0.86 |
||
