Rear Spring & Shock Absorber ([08.1988 - ] (8808- )LN107,111,RN110) Diagram Toyota HILUX/4RUNNER TRUCK
- Year
- 1988 - 1997
- Sales region
- General
- Frame
- RN110
- grade
- SR5
- ENGINE
- 22R
- TRANSMISSION
- MTM
- DESTINATION
- ARL
- Model
- HILUX
- From
- 08.1988
- To
- 08.1997
- Body
- XTR
- Gear Shift Type
- 5F
- Vehicle Model
- Hilux
- Driver's Position
- RHD
- Fuel Induction
- CBR
- Body
- T1
- Building Condition
- CBU
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
48210
|
48210
48210-35681 Spring Assy, Rear RhREAR RH [08.1988 - 08.1997] LN111,RN110 4-LEAF |
48210-35681 |
US $707.62 |
||
|
48210C
|
48210C
90389-14004 Bush(For Rear Spring Leaf)[08.1988 - 06.2001] LN107,111,135,RN106,110,135,YN135 |
90389-14004 |
from US $15.88 |
||
|
48211
|
48211
48201-35680 Leaf, Rear Spring, No.1REAR SPRING, NO.1 [08.1988 - 08.1997] LN111,RN110 |
48201-35680 |
US $115.02 |
||
|
48212
|
48212
48212-35680 Leaf, Rear Spring, No.2REAR SPRING, NO.2 [08.1988 - 08.1997] LN111,RN110 |
48212-35680 |
US $92.89 |
||
|
48213
|
48213
48202-35680 Leaf, Rear Spring, No.3REAR SPRING, NO.3 [08.1988 - 08.1997] LN111,RN110 |
48202-35680 |
US $75.71 |
||
|
48214
|
48214
48203-35680 Leaf, Rear Spring, No.4REAR SPRING, NO.4 [08.1988 - 08.1997] LN111,RN110 |
48203-35680 |
US $161.62 |
||
|
48220
|
48220
48210-35681 Spring Assy, Rear RhREAR RH [08.1988 - 08.1997] LN111,RN110 4-LEAF |
48210-35681 |
US $707.62 |
||
|
48246
|
48246
48146-60070 Case(For Rear Spring Clip Bolt)[08.1988 - 08.1991] LN106,111,135,RN105,110,135,YN106,135 |
48146-60070 |
US $2.61 |
||
|
48247
|
48247
48247-25160 Bolt, Front Spring, Center[08.1991 - 08.1997] LN111,RN110 |
48247-25160 |
US $2.62 |
||
|
48247
|
48247
48247-26260 Bolt, Rear Spring, Center[08.1988 - 08.1991] LN111,RN110 |
48247-26260 |
US $6.27 |
||
|
48251
|
48251
48251-35350
Spacer, Rear Spring Leaf
[08.1988 - 06.2001] LN107..TW1..GEN;LN111,135,RN110,135,YN135 |
48251-35350 |
— | ||
|
48252
|
48252
48252-26070 Silencer, Front Spring[08.1988 - 06.2001] LN10#,111,135,RN10#,110,135,YN106,135 |
48252-26070 |
from US $2.13 |
||
|
48252E
|
48252E
48252-35470
Silencer, Rear Spring, No.2
[08.1988 - 06.2001] LN107..TW1..GEN;LN111,135,RN110,135,YN135 |
48252-35470 |
— | ||
|
48256
|
48256
48256-35360 Bolt, Hexagon(For Rear Spring Clip Set)[08.1988 - 08.1997] LN111,135,RN110,135,YN135 FR |
48256-35360 |
US $5.73 |
||
|
48256
|
48256
48256-36570 Bolt, Front Spring Clip[08.1988 - 08.1997] LN111,135,RN110,135,YN135 RR |
48256-36570 |
US $2.51 |
||
|
48375
|
48375
48375-35011 Damper, Leaf Spring Dynamic[08.1988 - 06.2001] LN107..TW1..GEN;LN111,135,RN110,135,YN135 |
48375-35011 |
US $10.93 |
||
|
9411050800
|
9411050800
94110-50800 Nut(For Repair Actuator Set) |
94110-50800 |
US $1.43 |
||
|
9411051000
|
9411051000
94110-51000 Nut(For Steering Center Arm) |
94110-51000 |
from US $0.76 |
||
|
9451100800
|
9451100800
94511-00800 WASHERSPRING |
94511-00800 |
US $1.79 |
