Throttle Link & Valve Lever (Atm) ([08.1988 - ] (8808- )VZN105,110,13#..4FC) Diagram Toyota HILUX/4RUNNER TRUCK
- Year
- 1988 - 1990
- Sales region
- Europe
- Frame
- VZN105
- grade
- DLX
- body
- T1
- ENGINE
- 3VZE
- TRANSMISSION
- ATM
- PRODUCT
- JPP
- DESTINATION
- USA
- CAB
- RCB
- Model
- 4RUNNER TRUCK
- From
- 08.1988
- To
- 08.1990
- Gear Shift Type
- 4FC
- Vehicle Model
- 4RUNNER
- Fuel Induction
- EFI
- Building Condition
- CBU
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
35520
|
35520
35520-35050 Cable Assy, ThrottleTHROTTLE [08.1988 - 01.1995] VZN105,110,13#..4FC |
35520-35050 |
US $49.51 |
||
|
35520B
|
35520B
90301-09012 Ring, O (For Automatic Transmission Case Plug)[08.1988 - 08.1994] RN10#,110,13#,VZN105,110,13#..4FC |
90301-09012 |
US $2.75 |
||
|
35523A
|
35523A
35523-35070 Clamp, Throttle CableTHROTTLE CABLE, NO.1 [08.1988 - 08.1991] VZN105,110,13#..4FC |
35523-35070 |
US $13.25 |
||
| replacement | |||||
|
35523A
|
35523A
35523-35150
Clamp, Throttle Cable, No.1
[08.1988 - 08.1991] VZN105,110,13#..4FC |
35523-35150 |
— | ||
|
35524
|
35524
35523-35060 Clamp, Throttle CableTHROTTLE CABLE, NO.2 [08.1988 - 11.1995] VZN105,110,13#..4FC |
35523-35060 |
US $7.54 |
||
|
91611F0814
|
91611F0814
91611-F0814 Bolt |
91611-F0814 |
US $1.10 |
||
|
9161160616
|
9161160616
91611-60616
Bolt(For Transaxle Case Receiver)
|
91611-60616 |
— | ||
| replacement | |||||
|
9161160616
|
9161160616
91611-B0616 Bolt(For Transaxle Case Receiver) |
91611-B0616 |
from US $0.70 |
||
|
9161161016
|
9161161016
91611-61016
Bolt(For Dust Cover To Steering Knuckle Arm Setting)
|
91611-61016 |
— | ||
| replacement | |||||
|
9161161016
|
9161161016
91612-61016 Bolt(For Dust Cover To Steering Knuckle Arm Setting) |
91612-61016 |
US $1.38 |
||
