Back Door Panel & Glass ([08.1987 - ] (8708- )SOB) Diagram Toyota LAND CRUISER
- Year
- 1987 - 1988
- Sales region
- General
- Frame
- BJ60
- grade
- STD
- Roof
- SRF
- ENGINE
- 3B
- TRANSMISSION
- MTM
- DESTINATION
- GEN
- Model
- LAND CRUISER 60
- From
- 08.1987
- To
- 08.1988
- Gear Shift Type
- 4F
- Vehicle Model
- Land Cruiser
- Back Door
- SOB
- Driver's Position
- LHD
- Fuel Induction
- DSL
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
64780C
|
64780C
64780-90A00-16
Panel Assy, Back Door Trim, Rh
[08.1987 - 01.1990] BJ60,FJ62,HJ60..STD SEPIA BROWN,TRIM4# |
64780-90A00-16 |
— | ||
|
64790C
|
64790C
64790-90A00-16
Panel Assy, Back Door Trim, Lh
[08.1987 - 01.1990] BJ60,FJ62,HJ60..STD SEPIA BROWN,TRIM4# |
64790-90A00-16 |
— | ||
|
67005
|
67005
67005-90A25 Panel Sub-Assy, Back Door[08.1987 - 02.1989] FJ62..SOB..GX..GEN;FJ62..5F..SRF..SOB..GX..ME W(*DEF),RH; BJ60,HJ60..SOB;FJ62..STD..(ARL,GEN) W(*DEF),RH |
67005-90A25 |
US $1,218.67 |
||
| replacement | |||||
|
67005
|
67005
67005-90A26 Panel Sub-Assy, Back Door[08.1987 - 02.1989] FJ62..SOB..GX..GEN;FJ62..5F..SRF..SOB..GX..ME W(*DEF),RH; BJ60,HJ60..SOB;FJ62..STD..(ARL,GEN) W(*DEF),RH |
67005-90A26 |
US $1,227.41 |
||
|
67005
|
67005
67005-90A26 Panel Sub-Assy, Back Door[08.1987 - 01.1990] FJ62..STD;BJ60,HJ60..SOB;FJ62..SOB..GX..GEN;FJ62..5F..SRF..SOB..GX..ME RH |
67005-90A26 |
US $1,227.41 |
||
|
67005
|
67005
67006-90A19 Panel Sub-Assy, Back DoorBACK DOOR [08.1987 - 01.1990] FJ62..STD;BJ60,HJ60..SOB;FJ62..SOB..GX..GEN;FJ62..5F..SRF..SOB..GX..ME LH |
67006-90A19 |
US $1,116.75 |
||
|
67005
|
67005
67006-90A20 Panel Sub-Assy, Back DoorBACK DOOR [08.1987 - 01.1990] FJ62..4FC..SOB;FJ62..5F..SOB..VX;FJ62..HRF..GX..ME LH; BJ60,HJ60..SOB;FJ62..SOB..(ARL,GEN);FJ62..5F..SRF..SOB..GX..ME W(*DEF),LH |
67006-90A20 |
US $1,116.75 |
||
| replacement | |||||
|
67005
|
67005
67006-90A19 Panel Sub-Assy, Back DoorBACK DOOR [08.1987 - 01.1990] FJ62..4FC..SOB;FJ62..5F..SOB..VX;FJ62..HRF..GX..ME LH; BJ60,HJ60..SOB;FJ62..SOB..(ARL,GEN);FJ62..5F..SRF..SOB..GX..ME W(*DEF),LH |
67006-90A19 |
US $1,116.75 |
||
|
67005
|
67005
67006-90A22
Panel Sub-Assy, Back Door
[08.1987 - 01.1990] FJ62..SOB..GX..GEN;FJ62..STD..(GEN,ME);BJ60,HJ60..SOB..(GEN,ME);FJ62..5F..SRF..SOB ..GX..ME W(*AFT),LH |
67006-90A22 |
— | ||
|
67005
|
67005
67006-90A24
Panel Sub-Assy, Back Door
[08.1987 - 02.1989] FJ62..STD..GEN;BJ60,HJ60..SOB..(GEN,ME) W(*AFT),LH |
67006-90A24 |
— | ||
| replacement | |||||
|
67005
|
67005
67006-90A22
Panel Sub-Assy, Back Door
[08.1987 - 02.1989] FJ62..STD..GEN;BJ60,HJ60..SOB..(GEN,ME) W(*AFT),LH |
67006-90A22 |
— | ||
|
67819
|
67819
67819-90A00 Pad, Back Door Outside Panel[08.1987 - 01.1990] BJ60,FJ62,HJ60..SOB |
67819-90A00 |
US $13.40 |
||
|
67847
|
67847
67847-90A00
Cover, Back Door Service Hole, Rh
[08.1987 - 08.1989] BJ60,FJ62,HJ60..SOB..(ARL,GEN) |
67847-90A00 |
— | ||
|
67848
|
67848
67848-90A00
Cover, Back Door Service Hole, Lh
[08.1987 - 08.1989] BJ60,FJ62,HJ60..SOB..(ARL,GEN) |
67848-90A00 |
— | ||
|
67881A
|
67881A
67881-90A08
Weatherstrip Sub-Assy, Back Door
[08.1987 - 01.1990] BJ60,FJ62,HJ60..SOB |
67881-90A08 |
— | ||
|
67881B
|
67881B
67881-90A04
Weatherstrip, Back Door, Upper Rh
[08.1987 - 01.1990] BJ60,FJ62,HJ60..SOB |
67881-90A04 |
— | ||
|
67882B
|
67882B
67882-90A00
Weatherstrip, Back Door, Upper Lh
[08.1987 - 01.1990] BJ60,FJ62,HJ60..SOB |
67882-90A00 |
— | ||
|
67884A
|
67884A
67884-90A00 Weatherstrip, Back Door, Center[08.1987 - 01.1990] BJ60,FJ62,HJ60..SOB |
67884-90A00 |
from US $69.03 |
||
|
67891A
|
67891A
67891-90A01 Seal, Back Door[08.1987 - 12.1987] HJ6#..HRF;HJ60..STD,VX;FJ62..4FC..ME;FJ62..5F..LUB..VX;FJ62..HRF..LUB..GX;FJ62..VX ..(ARL,GEN);BJ60,FJ62..MTM..SOB |
67891-90A01 |
US $3.49 |
||
|
68131
|
68131
68131-90A23 Glass, Back Door[08.1987 - 01.1990] BJ60,FJ62,HJ60..STD..(ARL,GEN) *TEM,T=3.5,RH |
68131-90A23 |
US $128.13 |
||
| replacement | |||||
|
68131
|
68131
68131-90A28 Glass, Back Door[08.1987 - 01.1990] BJ60,FJ62,HJ60..STD..(ARL,GEN) *TEM,T=3.5,RH |
68131-90A28 |
US $595.50 |
||
|
68131
|
68131
68131-90A24 Glass, Back DoorBACK DOOR [08.1987 - 01.1990] BJ60,FJ62,HJ60..STD..GEN *TT,T=3.5,RH; FJ62..SOB..GX..GEN;BJ60,FJ62,HJ60..5F..SRF..SOB..(GX,STD)..ME *TT,T=3.5,RH |
68131-90A24 |
US $253.34 |
||
| replacement | |||||
|
68131
|
68131
68131-90A28 Glass, Back Door[08.1987 - 01.1990] BJ60,FJ62,HJ60..STD..GEN *TT,T=3.5,RH; FJ62..SOB..GX..GEN;BJ60,FJ62,HJ60..5F..SRF..SOB..(GX,STD)..ME *TT,T=3.5,RH |
68131-90A28 |
US $595.50 |
||
|
68131
|
68131
68131-90A27 Glass, Back DoorBACK DOOR [08.1987 - 01.1990] BJ60,FJ62,HJ60..STD..(ARL,GEN) *EHT,T=3.5,RH |
68131-90A27 |
US $592.59 |
||
| replacement | |||||
|
68131
|
68131
68131-90A28 Glass, Back Door[08.1987 - 01.1990] BJ60,FJ62,HJ60..STD..(ARL,GEN) *EHT,T=3.5,RH |
68131-90A28 |
US $595.50 |
||
|
68131
|
68131
68131-90A28 Glass, Back Door[08.1987 - 01.1990] BJ60,FJ62,HJ60..STD..GEN *EHTT,T=3.5,RH; FJ62..4FC..SOB;FJ62..5F..SOB..VX;FJ62..HRF..GX..ME *EHTT,T=3.5,RH; FJ62..SOB..GX..GEN;BJ60,FJ62,HJ60..5F..SRF..SOB..(GX,STD)..ME *EHTT,T=3.5,RH |
68131-90A28 |
US $595.50 |
||
|
68131
|
68131
68132-90A09 Glass, Back Door[08.1987 - 01.1990] BJ60,FJ62,HJ60..STD..(ARL,GEN) *TEM,T=3.5,LH |
68132-90A09 |
US $128.13 |
||
| replacement | |||||
|
68131
|
68131
68132-90A12 Glass, Back Door[08.1987 - 01.1990] BJ60,FJ62,HJ60..STD..(ARL,GEN) *TEM,T=3.5,LH |
68132-90A12 |
US $595.50 |
||
|
68131
|
68131
68132-90A10 Glass, Back DoorBACK DOOR [08.1987 - 01.1990] BJ60,FJ62,HJ60..STD..GEN *TT,T=3.5,LH; FJ62..SOB..GX..GEN;BJ60,FJ62,HJ60..5F..SRF..SOB..(GX,STD)..ME *TT,T=3.5,LH |
68132-90A10 |
US $253.34 |
||
| replacement | |||||
|
68131
|
68131
68132-90A12 Glass, Back Door[08.1987 - 01.1990] BJ60,FJ62,HJ60..STD..GEN *TT,T=3.5,LH; FJ62..SOB..GX..GEN;BJ60,FJ62,HJ60..5F..SRF..SOB..(GX,STD)..ME *TT,T=3.5,LH |
68132-90A12 |
US $595.50 |
||
|
68131
|
68131
68132-90A11 Glass, Back DoorBACK DOOR [08.1987 - 01.1990] BJ60,FJ62,HJ60..STD..(ARL,GEN) *EHT,T=3.5,LH |
68132-90A11 |
US $592.59 |
||
| replacement | |||||
|
68131
|
68131
68132-90A12 Glass, Back Door[08.1987 - 01.1990] BJ60,FJ62,HJ60..STD..(ARL,GEN) *EHT,T=3.5,LH |
68132-90A12 |
US $595.50 |
||
|
68131
|
68131
68132-90A12 Glass, Back Door[08.1987 - 01.1990] BJ60,FJ62,HJ60..STD..GEN *EHTT,T=3.5,LH; FJ62..4FC..SOB;FJ62..5F..SOB..VX;FJ62..HRF..GX..ME *EHTT,T=3.5,LH; FJ62..SOB..GX..GEN;BJ60,FJ62,HJ60..5F..SRF..SOB..(GX,STD)..ME *EHTT,T=3.5,LH |
68132-90A12 |
US $595.50 |
||
|
68291
|
68291
68291-90A02
Weatherstrip, Back Door Glass
[08.1987 - 01.1990] BJ60,FJ62,HJ60..SOB RH |
68291-90A02 |
— | ||
|
68291
|
68291
68292-90A00 Weatherstrip, Back Door Glass[08.1987 - 01.1990] BJ60,FJ62,HJ60..SOB LH |
68292-90A00 |
US $135.41 |
||
|
68611
|
68611
68611-90A00
Base, Back Door Check, Rh
[08.1987 - 01.1990] BJ60,FJ62,HJ60..SOB |
68611-90A00 |
— | ||
|
68612
|
68612
68612-90A00
Base, Back Door Check, Lh
[08.1987 - 01.1990] BJ60,FJ62,HJ60..SOB |
68612-90A00 |
— | ||
|
68617B
|
68617B
68617-90A01 Pin(For Front Door Check)[08.1987 - 01.1990] BJ60,FJ62,HJ60..SOB |
68617-90A01 |
from US $3.38 |
||
|
68650
|
68650
68650-90A01 Check Assy, Back Door[08.1987 - 01.1990] FJ62..STD;BJ60,HJ60..SOB;FJ62..SOB..GX..GEN;FJ62..5F..SRF..SOB..GX..ME |
68650-90A01 |
US $57.66 |
||
|
68650
|
68650
68650-90A02 Check Assy, Back Door[08.1987 - 01.1990] FJ62..4FC..SOB;FJ62..5F..SOB..VX;FJ62..HRF..GX..ME; FJ62..SOB..GX..GEN;FJ62..5F..SRF..SOB..GX..ME W(*DEF); BJ60,HJ60..SOB;FJ62..STD..(ARL,GEN) W(*DEF) |
68650-90A02 |
US $57.51 |
||
|
68660
|
68660
68660-90A01 Check Assy, Back Door[08.1987 - 01.1990] BJ60,FJ62,HJ60..SOB |
68660-90A01 |
US $71.34 |
||
|
68660
|
68660
68660-90A02 Check Assy, Back DoorBACK DOOR [08.1987 - 01.1990] FJ62..SOB..GX..GEN;FJ62..STD..(GEN,ME);BJ60,HJ60..SOB..(GEN,ME);FJ62..5F..SRF..SOB ..GX..ME W(*AFT) |
68660-90A02 |
US $71.34 |
||
|
68660
|
68660
68660-90A03
Check Assy, Back Door
[08.1987 - 02.1989] FJ62..STD..GEN;BJ60,HJ60..SOB..(GEN,ME) W(*AFT & *DEF) |
68660-90A03 |
— | ||
|
6777112010
|
6777112010
67771-12010 Retainer, Door Trim |
67771-12010 |
from US $1.77 |
||
|
6777112050
|
6777112050
67771-12050 Clip, Radiator Grille |
67771-12050 |
from US $1.44 |
||
|
6786830030
|
6786830030
67868-30030 Clip, Roof Side Rail Weatherstrip |
67868-30030 |
from US $1.50 |
||
|
6786830040
|
6786830040
67868-30040 Retainer, Roof Side Rail, Rh |
67868-30040 |
from US $1.05 |
||
|
9011906310
|
9011906310
90119-06310 New Genuine Part |
90119-06310 |
US $1.60 |
||
| replacement | |||||
|
9011906310
|
9011906310
90119-06428 New Genuine Part |
90119-06428 |
US $1.43 |
||
|
9011906312
|
9011906312
90119-06312 Bolt |
90119-06312 |
US $1.25 |
||
|
9095001130
|
9095001130
90950-01130 Plug, Hole(For Rear Door Panel) |
90950-01130 |
US $5.24 |
||
| replacement | |||||
|
9095001130
|
9095001130
90950-01038 Plug, Hole(For Instrument Lower Panel) |
90950-01038 |
US $4.84 |
||
