Brake Booster & Vacuum Tube ([08.1980 - 08.1986] (8008-8608)BJ6#) Diagram Toyota LAND CRUISER
- Year
- 1980 - 1982
- Sales region
- Japan
- Frame
- BJ60
- body
- WGV
- Roof
- SRF
- ENGINE
- 3B
- TRANSMISSION
- MTM
- Model
- LAND CRUISER 60
- From
- 08.1980
- To
- 10.1982
- Gear Shift Type
- 4F
- Vehicle Model
- Land Cruiser VAN
- Back Door
- VKC
- Fuel Induction
- DSL
- Building Condition
- CBU
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
44704
|
44704
44704-60050
Reservoir Sub-Assy, Vacuum
[08.1980 - 08.1986] BJ6# |
44704-60050 |
— | ||
|
44730
|
44730
44730-60040 Booster Kit, Brake[08.1980 - 08.1987] BJ6#,HJ6# |
44730-60040 |
US $77.93 |
||
|
44730C
|
44730C
90467-16141
Clip(For Clutch Reservoir Tube)
[08.1980 - 11.1984] BJ6#,FJ6#,HJ60 |
90467-16141 |
— | ||
|
44730J
|
44730J
90412-09006
Way(For Booster Vacuum)
[08.1980 - 10.1982] BJ60 |
90412-09006 |
— | ||
|
44743
|
44743
90405-09026 Union(For Vacuum Pump)[08.1980 - 11.1984] BJ6# |
90405-09026 |
US $10.92 |
||
|
44767C
|
44767C
90445-17034 Hose(For Vacuum Reservoir To Brake Booster)NO.1(FOR CLUTCH BOOSTER VACUUM) [07.1982 - 11.1984] BJ6# |
90445-17034 |
US $17.33 |
||
| replacement | |||||
|
44767C
|
44767C
95446-09270 Hose, No.1(For Clutch Booster Vacuum)VACUUM, NO.1 [07.1982 - 11.1984] BJ6# |
95446-09270 |
US $3.67 |
||
|
44767C
|
44767C
90445-17927 Hose, Vacuum Pump[08.1980 - 07.1982] BJ60 |
90445-17927 |
US $12.52 |
||
| replacement | |||||
|
44767C
|
44767C
95446-09300 Hose, Solenoid To Vacuum Tube[08.1980 - 07.1982] BJ60 |
95446-09300 |
US $11.65 |
||
|
44774D
|
44774D
90445-17908
Hose, Vacuum Pump
[08.1980 - 10.1982] BJ60 |
90445-17908 |
— | ||
| replacement | |||||
|
44774D
|
44774D
31438-60050
Hose, No.2(For Clutch Booster Vacuum)
[08.1980 - 10.1982] BJ60 |
31438-60050 |
— | ||
|
44778B
|
44778B
90445-17908
Hose, Vacuum Pump
[08.1980 - 10.1982] BJ60 |
90445-17908 |
— | ||
| replacement | |||||
|
44778B
|
44778B
31438-60050
Hose, No.2(For Clutch Booster Vacuum)
[08.1980 - 10.1982] BJ60 |
31438-60050 |
— | ||
|
9017908038
|
9017908038
90179-08038 Nut (For Transmission Control Cable) |
90179-08038 |
from US $0.78 |
||
|
9161140616
|
9161140616
91611-40616
Bolt, Hexagon(For Steering Column Bracket)
|
91611-40616 |
— | ||
| replacement | |||||
|
9161140616
|
9161140616
91611-B0616 Bolt(For Transaxle Case Receiver) |
91611-B0616 |
from US $0.84 |
||
|
9161140812
|
9161140812
91611-40812
Bolt(for Drive Plate & Torque Converter Setting)
|
91611-40812 |
— | ||
| replacement | |||||
|
9161140812
|
9161140812
91611-B0812 Bolt |
91611-B0812 |
from US $0.76 |
||
