Switch & Relay & Computer ([08.1980 - ] (8008- )) Diagram Toyota LAND CRUISER
- Year
- 1980 - 1982
- Sales region
- Japan
- Frame
- BJ60
- body
- WGV
- Roof
- SRF
- ENGINE
- 3B
- TRANSMISSION
- MTM
- Model
- LAND CRUISER 60
- From
- 08.1980
- To
- 10.1982
- Gear Shift Type
- 4F
- Vehicle Model
- Land Cruiser VAN
- Back Door
- VKC
- Fuel Induction
- DSL
- Building Condition
- CBU
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
28621
|
28621
28621-57010
Resistor, Glow Plug
[10.1981 - 01.1982] 3B..BJ60 |
28621-57010 |
— | ||
| replacements | |||||
|
28621
|
28621
19877-66010 Insulator Sub-Assy, Glow Plug, No.1[10.1981 - 01.1982] 3B..BJ60 |
19877-66010 |
US $5.10 |
||
|
28621
|
28621
28621-57011
Resistor, Glow Plug
[10.1981 - 01.1982] 3B..BJ60 |
28621-57011 |
— | ||
|
28621
|
28621
90179-05015 New Genuine Part[10.1981 - 01.1982] 3B..BJ60 |
90179-05015 |
US $1.12 |
||
|
28621
|
28621
28621-57011
Resistor, Glow Plug
[01.1982 - 08.1986] 3B..BJ6# |
28621-57011 |
— | ||
|
28624
|
28624
28624-57010
Plate, Current Sensor
[10.1981 - 08.1986] 3B..BJ6# |
28624-57010 |
— | ||
|
28631
|
28631
28631-57010
Sensor, Glow Plug Current
[10.1981 - 08.1986] 3B..BJ6# |
28631-57010 |
— | ||
|
89429
|
89429
89422-30020
Sensor, Water Temperature (For E.f.i.)
[10.1981 - 08.1986] BJ6# |
89422-30020 |
— | ||
| replacement | |||||
|
89429
|
89429
89422-12010 Sensor, Water Temperature (For E.f.i.)[10.1981 - 08.1986] BJ6# |
89422-12010 |
US $67.54 |
||
|
1987766010
|
1987766010
19877-66010 Insulator Sub-Assy, Glow Plug, No.1 |
19877-66010 |
US $5.10 |
||
|
2860268010
|
2860268010
28602-68010
New Genuine Part
|
28602-68010 |
— | ||
|
2862257010
|
2862257010
28622-57010 Insulator, Glow Plug Resistor, No.1 |
28622-57010 |
from US $1.40 |
||
|
2862354010
|
2862354010
28623-54010 Insulator, Glow Plug Resistor, No.2 |
28623-54010 |
from US $1.40 |
||
|
2862568040
|
2862568040
28625-68040
Plate, Glow Plug Resistor
|
28625-68040 |
— | ||
|
9011606275
|
9011606275
90116-06275
Bolt, Stud(For Injection Pipe Clamp)
|
90116-06275 |
— | ||
| replacement | |||||
|
9011606275
|
9011606275
90116-06095 Bolt, Stud(For Head To Cylinder Head Cover) |
90116-06095 |
US $1.61 |
||
|
9017004002
|
9017004002
90170-04002 Nut, Connecting(For Glow Plug) |
90170-04002 |
US $1.25 |
||
|
9017905015
|
9017905015
90179-05015 New Genuine Part |
90179-05015 |
US $1.12 |
||
|
9017906070
|
9017906070
90179-06070
Nut(For Steering Inter Shaft Dust Seal Cover)
|
90179-06070 |
— | ||
| replacement | |||||
|
9017906070
|
9017906070
90179-06159 Nut, Rear Wiper Link Pivot, No.1 |
90179-06159 |
from US $0.57 |
||
|
9017906158
|
9017906158
90179-06158 Nut, Rear Wiper Link Pivot, No.2 |
90179-06158 |
from US $0.95 |
||
|
9018904024
|
9018904024
90189-04024 Grommet, Screw(For Glow Plug) |
90189-04024 |
from US $0.68 |
||
|
9018905006
|
9018905006
90189-05006 GROMMET |
90189-05006 |
US $6.99 |
||
|
9020110042
|
9020110042
90201-10042 Washer, Plate (For Transfer Control Cable) |
90201-10042 |
US $1.61 |
||
|
9040454025
|
9040454025
90404-54025 New Genuine Part |
90404-54025 |
US $7.72 |
||
|
9043012221
|
9043012221
90430-12221 Gasket |
90430-12221 |
from US $1.05 |
||
|
9211260625
|
9211260625
92112-60625
New Genuine Part
|
92112-60625 |
— | ||
|
9461310601
|
9461310601
94613-10601 Washer (For Primary Regulator Valve) |
94613-10601 |
US $1.25 |
||
