Front Spring & Shock Absorber ([11.1984 - ] (8411- )BJ7#..HT) Diagram Toyota LAND CRUISER
- Year
- 1986 - 1990
- Sales region
- Europe
- Frame
- BJ71
- grade
- LX
- body
- HT
- ENGINE
- 13BT
- Model
- LAND CRUISER 70
- From
- 08.1986
- To
- 01.1990
- Vehicle Model
- Land Cruiser
- Driver's Position
- LHD
- Fuel Induction
- TD
- Building Condition
- CBU
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
48811
|
48811
48811-60020
Bar, Stabilizer, Front
[11.1984 - 08.1986] BJ7#..HT |
48811-60020 |
— | ||
|
48811
|
48811
48811-60050
Bar, Stabilizer, Front
[08.1986 - 01.1990] BJ7#..HT |
48811-60050 |
— | ||
|
48811A
|
48811A
90387-09006 Bush(For Front Stabilizer Bar)[11.1984 - 01.1990] BJ7#..HT |
90387-09006 |
US $10.57 |
||
|
48815
|
48815
48815-26040 Bush, Front Stabilizer Bar, No.1[08.1986 - 01.1990] BJ7#..HT |
48815-26040 |
from US $11.59 |
||
|
48815
|
48815
48815-30050 Bush, Front Stabilizer Bar, No.1[11.1984 - 08.1986] BJ7#..HT |
48815-30050 |
from US $4.35 |
||
|
48817
|
48817
48817-30010 Cushion, Front Stabilizer[10.1985 - 01.1990] BJ7#,LJ7#,RJ7#..HT,SOT |
48817-30010 |
from US $2.17 |
||
|
48817A
|
48817A
90948-02015 Retainer, Cushion, No.1(For Front Stabilizer Bar)[10.1985 - 01.1990] BJ7#,LJ7#,RJ7#..HT,SOT |
90948-02015 |
from US $0.87 |
||
|
48817B
|
48817B
90948-02032 Retainer, Cushion, No.1(For Front Stabilizer Bar)[10.1985 - 01.1990] BJ7#,LJ7#,RJ7#..HT,SOT |
90948-02032 |
from US $2.13 |
||
|
48817D
|
48817D
90101-08055 Bolt(For Front Stabilizer)[11.1984 - 01.1990] BJ7#..HT |
90101-08055 |
from US $7.70 |
||
|
48817F
|
48817F
94183-60800 Nut(For Front Stabilizer Bar)[11.1984 - 01.1990] BJ7#,LJ7#,RJ7#..HT,SOT |
94183-60800 |
US $1.43 |
||
|
48823B
|
48823B
48823-27010 Cover, Stabilizer Link(For Front)[11.1984 - 08.1986] BJ7#..HT |
48823-27010 |
from US $5.47 |
||
|
48823B
|
48823B
48823-60030 Cover, Front Stabilizer Bracket[08.1986 - 01.1990] BJ7#..HT |
48823-60030 |
from US $4.48 |
||
|
48824
|
48824
48825-60020 Bracket, Stabilizer, Front[11.1984 - 01.1990] BJ7#..HT |
48825-60020 |
US $28.39 |
||
|
9011908703
|
9011908703
90119-08703 New Genuine Part |
90119-08703 |
US $1.79 |
||
|
9165140825
|
9165140825
91651-40825 Bolt(For Clutch Release Cylinder Setting) |
91651-40825 |
from US $1.67 |
