Power Take-Off Lever & Link ([11.1984 - ] (8411- )BJ7#) Diagram Toyota LAND CRUISER
- Year
- 1985 - 1990
- Sales region
- Japan
- Frame
- BJ71
- grade
- LX
- body
- HT
- ENGINE
- 13BT
- TRANSMISSION
- MTM
- Model
- LAND CRUISER 70
- From
- 10.1985
- To
- 01.1990
- Vehicle Model
- Land Cruiser S/T,H/T
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
36303A
|
36303A
36303-60140
Knob Sub-Assy, Shift Lever (For Power Take-Off)
[11.1984 - 01.1990] BJ7# |
36303-60140 |
— | ||
|
36303B
|
36303B
33623-60030
Button, Shift Lever Knob (For Power Take-Off)
[11.1984 - 01.1990] BJ7# |
33623-60030 |
— | ||
|
36303C
|
36303C
90501-10073
Spring, Compression (For Shift Lever Knob Button)
[11.1984 - 01.1990] BJ7# |
90501-10073 |
— | ||
|
36303D
|
36303D
90149-40004 Bolt Or Pin (For Shift Lever Knob Setting)[11.1984 - 01.1990] BJ7# |
90149-40004 |
US $1.49 |
||
|
36830
|
36830
36830-60060
Lever Assy, Power Take-Off Shift
[11.1984 - 01.1990] BJ7#..MTM |
36830-60060 |
— | ||
|
36847
|
36847
36847-60020
Lever, Power Take-Off Lock
[11.1984 - 01.1990] BJ7# |
36847-60020 |
— | ||
|
36847A
|
36847A
90501-05011
Spring, Compression (For Power Take-Off Lock Lever)
[11.1984 - 01.1990] BJ7# |
90501-05011 |
— | ||
|
36850
|
36850
36850-60040
Rod Assy, Power Take-Off Shift
[11.1984 - 01.1990] BJ7#..MTM |
36850-60040 |
— | ||
|
36850C
|
36850C
33740-26010 End Assy, Connecting Rod, No.1(For Column Shift)[11.1984 - 01.1990] BJ7# |
33740-26010 |
from US $13.05 |
||
|
36850E
|
36850E
90389-08005 Bushing(For Gear Selecting Rod)[11.1984 - 01.1990] BJ7# |
90389-08005 |
from US $1.73 |
||
|
36850F
|
36850F
90480-17177 Grommet (For Transmission Control Rod)[11.1984 - 01.1990] BJ7# |
90480-17177 |
from US $2.01 |
||
|
36850G
|
36850G
90240-08034 Pin, W/hole (For Gear Shifting Rod No.3)[11.1984 - 01.1990] BJ7# |
90240-08034 |
from US $1.48 |
||
|
9046814004
|
9046814004
90468-14004 Union, Auxiliary Fuel Band |
90468-14004 |
from US $0.65 |
||
|
9161161020
|
9161161020
91611-61020 Bolt(For Transaxle & Engine Setting) |
91611-61020 |
US $0.68 |
||
| replacement | |||||
|
9161161020
|
9161161020
91612-B1020 Bolt (For Transfer Case)Cover No.2 |
91612-B1020 |
from US $1.05 |
||
|
9411040800
|
9411040800
94110-40800
Nut(For Steering Damper)
|
94110-40800 |
— | ||
| replacement | |||||
|
9411040800
|
9411040800
94130-00802 Nut, No.1 (For Center Support Bearing) |
94130-00802 |
from US $0.87 |
||
|
9412040800
|
9412040800
94120-40800 Nut(For Clutch Pedal Stopper) |
94120-40800 |
US $1.61 |
||
|
9451200800
|
9451200800
94512-00800 Washer, No.1 (For Propeller Shaft & Differential Setting) |
94512-00800 |
from US $0.68 |
||
|
9461310500
|
9461310500
94613-10500 New Genuine Part |
94613-10500 |
US $3.05 |
||
