Cowl Panel & Windshield Glass ([03.1969 - 07.1980] (6903-8007)BJ4#,FJ4#) Diagram Toyota LAND CRUISER
- Year
- 1969 - 1975
- Sales region
- Japan
- Frame
- FJ43
- body
- TP
- ENGINE
- F
- Model
- LAND CRUISER 40
- From
- 03.1969
- To
- 01.1975
- Vehicle Model
- Land Cruiser VAN
- Back Door
- TPC
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
55701
|
55701
55701-60012
Panel Sub-Assy, Cowl
[09.1971 - 09.1973] FJ4# |
55701-60012 |
— | ||
|
55701
|
55701
55701-90340
Panel Sub-Assy, Cowl
[09.1973 - 08.1976] BJ4#,FJ4# |
55701-90340 |
— | ||
|
55781
|
55781
55768-60010
Louver, Cowl Ventilator
[03.1969 - 07.1980] BJ4#,FJ4# |
55768-60010 |
— | ||
|
55955
|
55955
55955-90300
Guide, Defroster Nozzle
[03.1969 - 01.1975] BJ4#,FJ4# |
55955-90300 |
— | ||
|
55955
|
55955
55956-90300
Guide, Defroster Nozzle
[01.1975 - 07.1980] BJ4#,FJ4# RH. |
55956-90300 |
— | ||
|
55955
|
55955
55957-90300
Guide, Defroster Nozzle
[01.1975 - 07.1980] BJ4#,FJ4# LH. |
55957-90300 |
— | ||
|
56111
|
56111
56111-60013
Glass, Windshield
[05.1970 - 01.1975] BJ4#,FJ4# ZN.TP.T=5.0 |
56111-60013 |
— | ||
| replacement | |||||
|
56111
|
56111
56111-90800
Glass, Windshield
[05.1970 - 01.1975] BJ4#,FJ4# ZN.TP.T=5.0 |
56111-90800 |
— | ||
|
56111
|
56111
56111-60040
Glass, Windshield
[03.1969 - 01.1975] BJ4#,FJ4# LM.T=6.7 |
56111-60040 |
— | ||
| replacement | |||||
|
56111
|
56111
56111-90800
Glass, Windshield
[03.1969 - 01.1975] BJ4#,FJ4# LM.T=6.7 |
56111-90800 |
— | ||
|
56111
|
56111
56111-90300
Glass, Windshield
[01.1975 - 07.1980] BJ4#,FJ4# ZN.TP.T=5.0 |
56111-90300 |
— | ||
| replacement | |||||
|
56111
|
56111
56111-90303
Glass, Windshield
[01.1975 - 07.1980] BJ4#,FJ4# ZN.TP.T=5.0 |
56111-90303 |
— | ||
|
56111
|
56111
56111-90301
Glass, Windshield
[01.1975 - 02.1979] BJ4#,FJ4# LM.T=6.7 |
56111-90301 |
— | ||
| replacement | |||||
|
56111
|
56111
56111-90303
Glass, Windshield
[01.1975 - 02.1979] BJ4#,FJ4# LM.T=6.7 |
56111-90303 |
— | ||
|
56121
|
56121
56121-60011 Weatherstrip, WindshieldWINDSHIELD [03.1969 - 01.1975] BJ4#,FJ4# FOR GLASS T=6.7&6.3 |
56121-60011 |
US $109.52 |
||
|
56121
|
56121
56121-60030
Weatherstrip, Windshield
[05.1970 - 01.1975] BJ4#,FJ4# FOR GLASS T=5.0 |
56121-60030 |
— | ||
|
56121
|
56121
56121-90300
Weatherstrip, Windshield
[01.1975 - 07.1980] BJ4#,FJ4# FOR GLASS T=5.0 |
56121-90300 |
— | ||
|
56121
|
56121
56121-90301 Weatherstrip, WindshieldWINDSHIELD [01.1975 - 02.1979] BJ4#,FJ4# FOR GLASS T=6.7 |
56121-90301 |
US $140.60 |
||
|
56122
|
56122
56122-60011 Weatherstrip, Windshield, No.2WINDSHIELD, NO.2 [03.1969 - 07.1980] BJ4#,FJ4# |
56122-60011 |
US $22.19 |
||
|
56211
|
56211
56211-90300
Spacer, Windshield
[03.1969 - 07.1980] BJ4#,FJ4# |
56211-90300 |
— | ||
| replacement | |||||
|
56211
|
56211
56211-90801 Spacer, Windshield[03.1969 - 07.1980] BJ4#,FJ4# |
56211-90801 |
from US $151.20 |
||
|
56211A
|
56211A
56389-90302
Plate, Windshield Set
[03.1969 - 02.1974] FJ4# |
56389-90302 |
— | ||
|
56214
|
56214
56214-90301
Weatherstrip, Front Windshield
[03.1969 - 03.1972] FJ4# |
56214-90301 |
— | ||
|
56301
|
56301
56301-60013
Frame Sub-Assy, Windshield
[03.1969 - 09.1973] FJ4# |
56301-60013 |
— | ||
|
56301
|
56301
56301-90305
Frame Sub-Assy, Windshield
[09.1973 - 01.1975] BJ4#,FJ4# |
56301-90305 |
— | ||
|
56301
|
56301
56301-90318
Frame Sub-Assy, Windshield
[01.1975 - 09.1977] BJ4#,FJ4# |
56301-90318 |
— | ||
|
56306
|
56306
56306-90300
Hinge Sub-Assy, Windshield Support, Rh
[03.1969 - 01.1975] BJ4#,FJ4# |
56306-90300 |
— | ||
|
56306
|
56306
56306-90301
Hinge Sub-Assy, Windshield Support, Rh
[01.1975 - 09.1978] BJ4#,FJ4# |
56306-90301 |
— | ||
| replacements | |||||
|
56306
|
56306
56306-90302
Hinge Sub-Assy, Windshield Support, Rh
[01.1975 - 09.1978] BJ4#,FJ4# |
56306-90302 |
— | ||
|
56306
|
56306
90159-80010 SCREW[01.1975 - 09.1978] BJ4#,FJ4# |
90159-80010 |
US $2.88 |
||
|
56307
|
56307
56307-90300
Hinge Sub-Assy, Windshield Support, Lh
[03.1969 - 01.1975] BJ4#,FJ4# |
56307-90300 |
— | ||
|
56307
|
56307
56307-90301
Hinge Sub-Assy, Windshield Support, Lh
[01.1975 - 09.1978] BJ4#,FJ4# |
56307-90301 |
— | ||
| replacements | |||||
|
56307
|
56307
56307-90302
Hinge Sub-Assy, Windshield Support, Lh
[01.1975 - 09.1978] BJ4#,FJ4# |
56307-90302 |
— | ||
|
56307
|
56307
90159-80010 SCREW[01.1975 - 09.1978] BJ4#,FJ4# |
90159-80010 |
US $2.88 |
||
|
56313
|
56313
56313-90300
Rail, Windshield Frame, Upper
[03.1969 - 07.1980] BJ4#,FJ4# |
56313-90300 |
— | ||
|
56457
|
56457
56457-60010
Bracket, Windshield Catch, Upper
[03.1969 - 07.1980] BJ4#,FJ4# |
56457-60010 |
— | ||
|
56469
|
56469
56469-60010
Cover, Windshield Catch
[03.1969 - 09.1975] FJ4# |
56469-60010 |
— | ||
|
5529830010
|
5529830010
55298-30010 Cap(For Roll Bar)TEE NUT(FOR 8MM) |
55298-30010 |
US $3.06 |
||
|
5529930010
|
5529930010
55299-30010 Cap, Tee Nut(For 6Mm) |
55299-30010 |
US $3.20 |
||
|
9015980010
|
9015980010
90159-80010 SCREW |
90159-80010 |
US $2.88 |
||
|
9018304037
|
9018304037
90183-04037 New Genuine Part |
90183-04037 |
US $2.33 |
||
|
9046707003
|
9046707003
90467-07003 Clip(For Defroster Guide) |
90467-07003 |
US $3.68 |
||
|
9095001003
|
9095001003
90950-01003 Plug, Hole, No.1(For Dash Panel) |
90950-01003 |
US $3.84 |
||
|
9095001006
|
9095001006
90950-01006 Plug, Hole(For Front Fender) |
90950-01006 |
from US $2.16 |
||
|
9161140612
|
9161140612
91611-40612
Bolt(for Dust Cover To Steering Knuckle Arm Setting)
|
91611-40612 |
— | ||
| replacement | |||||
|
9161140612
|
9161140612
91611-G0612 Bolt |
91611-G0612 |
from US $0.82 |
||
|
9165140620
|
9165140620
91651-40620 BOLT |
91651-40620 |
US $1.12 |
||
|
9322018016
|
9322018016
93220-18016 New Genuine Part |
93220-18016 |
US $1.89 |
||
|
9331516014
|
9331516014
93315-16014 Screw |
93315-16014 |
from US $1.16 |
||
|
9352014012
|
9352014012
93520-14012
New Genuine Part
|
93520-14012 |
— | ||
|
9354054012
|
9354054012
93540-54012 Screw, Headlamp |
93540-54012 |
US $1.44 |
||
|
9354054014
|
9354054014
93540-54014 SCREW |
93540-54014 |
from US $1.05 |
||
|
9452400800
|
9452400800
94524-00800
New Genuine Part
|
94524-00800 |
— | ||
