Windshield Wiper ([03.1969 - 09.1971] (6903-7109)FJ55) Diagram Toyota LAND CRUISER
- Year
- 1969 - 1975
- Sales region
- Europe
- Frame
- FJ55
- ENGINE
- F
- DESTINATION
- GEN
- Model
- LAND CRUISER 50
- From
- 03.1969
- To
- 01.1975
- Vehicle Model
- Land Cruiser
- Driver's Position
- RHD
- Roll Bar
- WORB
- Top,back Door
- VKC
- Building Condition
- CBU
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
85011
|
85011
85011-60050
Stator Sub-Assy, Windshield Wiper Motor
[03.1969 - 09.1971] FJ55 |
85011-60050 |
— | ||
|
85012
|
85012
85012-60050
Holder Sub-Assy, Windshield Wiper Motor Brush
[03.1969 - 09.1971] FJ55 |
85012-60050 |
— | ||
| replacement | |||||
|
85012
|
85012
85012-26010
Holder Sub-Assy, Windshield Wiper Motor Brush
[03.1969 - 09.1971] FJ55 |
85012-26010 |
— | ||
|
85018
|
85018
85013-60050
Switch Sub-Assy, Windshield Wiper Auto Stop
[03.1969 - 09.1971] FJ55 |
85013-60050 |
— | ||
|
85019
|
85019
85146-55020
Cover, Windshield Wiper Motor Auto Stop Switch
[03.1969 - 09.1971] FJ55 |
85146-55020 |
— | ||
|
85110
|
85110
85110-60050
Motor Assy, Windshield Wiper
[03.1969 - 09.1971] FJ55..RHD |
85110-60050 |
— | ||
|
85110
|
85110
85110-90350
Motor Assy, Windshield Wiper
[09.1971 - 09.1977] FJ55..RHD |
85110-90350 |
— | ||
|
85111
|
85111
85111-60050
Armature, Windshield Wiper Motor
[03.1969 - 09.1971] FJ55 |
85111-60050 |
— | ||
|
85112
|
85112
85112-55022
Spring, Windshield Wiper Motor Brush
[03.1969 - 09.1971] FJ55 |
85112-55022 |
— | ||
|
85113
|
85113
85113-60050
Frame, Windshield Wiper Motor End
[03.1969 - 09.1971] FJ55 |
85113-60050 |
— | ||
| replacement | |||||
|
85113
|
85113
85147-26020
Frame, Windshield Wiper Motor End
[03.1969 - 09.1971] FJ55 |
85147-26020 |
— | ||
|
85114
|
85114
85114-55022
Brush, Windshield Wiper Motor
[03.1969 - 09.1971] FJ55 |
85114-55022 |
— | ||
|
85115
|
85115
85115-60051
Housing, Windshield Wiper Motor Gear
[03.1969 - 09.1971] FJ55 |
85115-60051 |
— | ||
|
85116
|
85116
85116-60050
Gear, Windshield Wiper Motor
[03.1969 - 09.1971] FJ55..RHD |
85116-60050 |
— | ||
|
85125
|
85125
85125-55021
Pin, Windshield Wiper Motor Auto Stop Switch
[03.1969 - 09.1971] FJ55 |
85125-55021 |
— | ||
|
85127
|
85127
85127-55021
Core, Windshield Wiper Motor Pole
[03.1969 - 09.1971] FJ55 |
85127-55021 |
— | ||
| replacement | |||||
|
85127
|
85127
85011-60050
Stator Sub-Assy, Windshield Wiper Motor
[03.1969 - 09.1971] FJ55 |
85011-60050 |
— | ||
|
85129
|
85129
85129-60050
Coil, Windshield Wiper Motor Field
[03.1969 - 09.1971] FJ55 |
85129-60050 |
— | ||
|
85133
|
85133
85133-55022
Plate, Windshield Wiper Motor Gear Housing Cover
[03.1969 - 09.1971] FJ55 |
85133-55022 |
— | ||
|
85134
|
85134
85134-55021
Gasket, Windshield Wiper Motor Gear Housing Cover
[03.1969 - 09.1971] FJ55 |
85134-55021 |
— | ||
|
85143
|
85143
85143-60050
Wiring, Windshield Wiper Motor Lead
[03.1969 - 09.1971] FJ55 |
85143-60050 |
— | ||
|
85156
|
85156
85156-55022
Plate, Windshield Wiper Motor Brush
[03.1969 - 09.1971] FJ55 |
85156-55022 |
— | ||
|
85230
|
85230
55746-90351
Bracket Assy, Windshield Wiper
[03.1969 - 09.1977] FJ55 |
55746-90351 |
— | ||
|
8511755020
|
8511755020
85117-55020
New Genuine Part
|
85117-55020 |
— | ||
|
8511855021
|
8511855021
85118-55021
New Genuine Part
|
85118-55021 |
— | ||
|
8511925040
|
8511925040
85119-25040
Crank, Windshield Wiper Motor
|
85119-25040 |
— | ||
|
8513155020
|
8513155020
85131-55020
Cover, Rr Wiper Motor
|
85131-55020 |
— | ||
|
8513755021
|
8513755021
85137-55021
New Genuine Part
|
85137-55021 |
— | ||
|
8514555021
|
8514555021
85145-55021
New Genuine Part
|
85145-55021 |
— | ||
|
8515255020
|
8515255020
85152-55020
New Genuine Part
|
85152-55020 |
— | ||
|
8515355021
|
8515355021
85153-55021
Motor, Full Area Wiper
|
85153-55021 |
— | ||
|
9111140616
|
9111140616
91111-40616 New Genuine Part |
91111-40616 |
US $2.18 |
||
| replacement | |||||
|
9111140616
|
9111140616
91111-50616 New Genuine Part |
91111-50616 |
US $0.93 |
||
|
9338115008
|
9338115008
93381-15008 SCREWWWASHER |
93381-15008 |
US $1.44 |
||
|
9412040600
|
9412040600
94120-40600 Nut, Wire Adjusting, No.1 |
94120-40600 |
US $2.72 |
||
|
9451100500
|
9451100500
94511-00500 Washer, Cover Set, No.2 |
94511-00500 |
from US $0.24 |
||
|
9451100600
|
9451100600
94511-00600 Washer, Lock, No.2 |
94511-00600 |
US $1.92 |
||
|
9461110600
|
9461110600
94611-10600 WASHERPLATE |
94611-10600 |
US $1.44 |
||
