Carburetor Assembly ([11.1980 - 11.1984] (8011-8411)2F..IV4) Diagram Toyota LAND CRUISER
- Year
- 1980 - 1982
- Sales region
- Japan
- Frame
- FJ60
- body
- WGV
- Roof
- SRF
- ENGINE
- 2F
- TRANSMISSION
- MTM
- Model
- LAND CRUISER 60
- From
- 11.1980
- To
- 10.1982
- Gear Shift Type
- 4F
- Vehicle Model
- Land Cruiser VAN
- Back Door
- VKC
- Fuel Induction
- CBR
- Building Condition
- IV4
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
21911
|
21911
07042-43610
Gasket, Carburetor
[11.1980 - 11.1984] 2F..FJ6#..IV4 |
07042-43610 |
— | ||
|
21912
|
21912
07042-88611
Insulator, Carburetor Heat
[11.1980 - 11.1984] 2F..FJ6#..IV4 |
07042-88611 |
— | ||
|
26300
|
26300
26300-61010 Governor Assy[11.1980 - 11.1984] 2F..FJ6#..IV4 |
26300-61010 |
US $3,960.32 |
||
|
26300B
|
26300B
07042-10611
Governor Assy, W/no.1 Pulley Bracket
[11.1980 - 11.1984] 2F..FJ6#..IV4 |
07042-10611 |
— | ||
|
26300C
|
26300C
07042-11611
Bracket, Governor, No.2
[11.1980 - 11.1984] 2F..FJ6#..IV4 |
07042-11611 |
— | ||
|
26300D
|
26300D
99521-11250 Belt, Governor[11.1980 - 11.1984] 2F..FJ6#..IV4 |
99521-11250 |
US $13.69 |
||
| replacement | |||||
|
26300D
|
26300D
99321-01250
Belt, Governor
[11.1980 - 11.1984] 2F..FJ6#..IV4 |
99321-01250 |
— | ||
|
26300E
|
26300E
07042-40626
Valve Assy, Butterfly
[11.1980 - 11.1984] 2F..FJ6#..IV4 |
07042-40626 |
— | ||
|
26300F
|
26300F
07042-30612
Rod Assy, Connecting
[11.1980 - 11.1984] 2F..FJ6#..IV4 |
07042-30612 |
— | ||
|
26400
|
26400
07047-32610
Solenoid Assy, Governor Control
[11.1980 - 11.1984] 2F..FJ6#..IV4 |
07047-32610 |
— | ||
|
26400A
|
26400A
07047-30610
Cable Assy, Governor Control
[11.1980 - 11.1984] 2F..FJ6#..IV4 |
07047-30610 |
— | ||
|
26400B
|
26400B
07047-38610
Bracket, Solenoid
[11.1980 - 11.1984] 2F..FJ6#..IV4 |
07047-38610 |
— | ||
|
26400C
|
26400C
07047-33620
Support, Governor Control Cable, No.1
[11.1980 - 11.1984] 2F..FJ6#..IV4 |
07047-33620 |
— | ||
|
26400D
|
26400D
07047-34630
Support, Governor Control Cable, No.2
[11.1980 - 11.1984] 2F..FJ6#..IV4 |
07047-34630 |
— | ||
|
26400E
|
26400E
07047-36610
Support, Governor Spring
[11.1980 - 11.1984] 2F..FJ6#..IV4 |
07047-36610 |
— | ||
|
26400F
|
26400F
78152-55020 End, Governor Control CableACCELERATOR BALL JOINT, NO.1 [11.1980 - 08.1987] 2F,3F..FJ6#..IV4 |
78152-55020 |
US $10.92 |
||
|
26400G
|
26400G
78157-55020 Ball, Governor Control CableACCELERATOR JOINT [11.1980 - 08.1987] 2F,3F..FJ6#..IV4 |
78157-55020 |
US $5.10 |
||
|
0704253512
|
0704253512
07042-53512
New Genuine Part
|
07042-53512 |
— | ||
|
7819755010
|
7819755010
78197-55010 Clip, Accelerator Joint BallACCELERATOR JOINT BALL |
78197-55010 |
US $2.48 |
||
|
9020113175
|
9020113175
90201-13175
Washer, Plate(For Cylinder Head Set)
|
90201-13175 |
— | ||
|
9050609042
|
9050609042
90506-09042 Spring (For Accelerator Rod Return) |
90506-09042 |
US $2.18 |
||
|
9052009057
|
9052009057
90520-09057 Ring, Accelerator Joint Ball Clip SnapACCELERATOR JOINT BALL CLIP SNAP |
90520-09057 |
US $1.75 |
||
|
9093003031
|
9093003031
90930-03031 Plug, Breather(For Parking Cover) |
90930-03031 |
from US $6.18 |
||
|
9111140816
|
9111140816
91111-40816
New Genuine Part
|
91111-40816 |
— | ||
| replacement | |||||
|
9111140816
|
9111140816
91111-50816 Bolt |
91111-50816 |
US $2.15 |
||
|
9111141025
|
9111141025
91111-41025
Bolt(For Crankshaft Pulley Set)
|
91111-41025 |
— | ||
| replacement | |||||
|
9111141025
|
9111141025
91112-61025 Bolt(For Clutch Pedal Stopper) |
91112-61025 |
from US $0.84 |
||
|
9161160816
|
9161160816
91611-60816
Screw Or Bolt(For Valve Rocker Shaft Lock)
|
91611-60816 |
— | ||
| replacement | |||||
|
9161160816
|
9161160816
91611-B0816 Bolt |
91611-B0816 |
from US $0.99 |
||
|
9165140816
|
9165140816
91651-40816 BOLT |
91651-40816 |
from US $0.95 |
||
|
9321915016
|
9321915016
93219-15016
Screw, Cover Set, No.1
|
93219-15016 |
— | ||
|
9411040800
|
9411040800
94110-40800
Nut(For Steering Damper)
|
94110-40800 |
— | ||
| replacement | |||||
|
9411040800
|
9411040800
94130-00802 Nut, No.1 (For Center Support Bearing) |
94130-00802 |
from US $0.87 |
||
|
9411540500
|
9411540500
94115-40500 Nut(For Lpg Filter Stud Bolt Set) |
94115-40500 |
US $1.97 |
||
|
9412040600
|
9412040600
94120-40600 Nut, Wire Adjusting, No.1 |
94120-40600 |
US $3.05 |
||
|
9451200600
|
9451200600
94512-00600 Washer, Seal(For Head Cover Set) |
94512-00600 |
US $2.33 |
||
|
9451200800
|
9451200800
94512-00800 Washer, No.1 (For Propeller Shaft & Differential Setting) |
94512-00800 |
from US $0.68 |
||
|
9451201000
|
9451201000
94512-01000 Washer, No.1 (For Propeller Shaft & Differential Setting) |
94512-01000 |
from US $0.78 |
||
|
9461311001
|
9461311001
94613-11001 WASHER |
94613-11001 |
US $2.15 |
||
|
9616000600
|
9616000600
96160-00600 Ring, E(For Clutch Pedal Pawl) |
96160-00600 |
from US $0.82 |
||
