Switch & Relay & Computer ([08.1987 - ] (8708- )) Diagram Toyota LAND CRUISER
- Year
- 1987 - 1990
- Sales region
- U.S.A.
- Frame
- FJ62
- body
- WGG
- ENGINE
- 3FE
- DESTINATION
- USA
- Model
- LAND CRUISER 60
- From
- 08.1987
- To
- 01.1990
- Vehicle Model
- Land Cruiser
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
83420
|
83420
83420-20020 Gage Assy, Water Temperature Sender[08.1987 - 01.1990] FJ62 |
83420-20020 |
from US $28.46 |
||
|
83520
|
83520
83520-60010
Gage Assy,oil Pressure Sender
[08.1987 - 01.1990] FJ62 |
83520-60010 |
— | ||
| replacement | |||||
|
83520
|
83520
83520-60011 Gage Assy,oil Pressure Sender[08.1987 - 01.1990] FJ62 |
83520-60011 |
from US $62.50 |
||
|
84222
|
84222
84222-60021 Switch, Transfer Indicator, No.1[08.1987 - 01.1990] FJ62 NO.1 |
84222-60021 |
from US $68.32 |
||
|
84222
|
84222
84222-60030 Switch, Transfer Indicator, No.1[08.1987 - 01.1990] FJ62 NO.2 |
84222-60030 |
US $73.92 |
||
|
84222
|
84222
84222-60040
Switch, Transfer Indicator, No.1
[08.1987 - 01.1990] FJ62 NO.3 |
84222-60040 |
— | ||
| replacement | |||||
|
84222
|
84222
84222-60041 Switch, Transfer Indicator, No.3[08.1987 - 01.1990] FJ62 NO.3 |
84222-60041 |
from US $43.51 |
||
|
84222
|
84222
84222-60071 Switch, Transfer Indicator, No.1[08.1987 - 01.1990] FJ62 NO.4 |
84222-60071 |
US $58.82 |
||
|
84540
|
84540
84540-60020
Switch Assy, Neutral Start
[08.1987 - 01.1990] FJ62 |
84540-60020 |
— | ||
|
85440A
|
85440A
85440-60120
Solenoid Assy, Front Drive
[08.1987 - 01.1990] FJ62 |
85440-60120 |
— | ||
|
89412
|
89412
89412-12010 Sensor, E.g.r Gas TemperatureE.G.R GAS TEMPERATURE [08.1987 - 01.1990] FJ62..USA CARIFORNIA SPEC |
89412-12010 |
US $168 |
||
|
89423A
|
89423A
89423-60020
Sensor, Manifold Temperature
[08.1987 - 01.1990] FJ62 |
89423-60020 |
— | ||
|
89428
|
89428
89428-36010
Switch, Temperature Detect, No.2
[08.1987 - 01.1990] FJ62 |
89428-36010 |
— | ||
|
89437
|
89437
89437-60010 Cover, Sensor[08.1987 - 01.1990] FJ62 |
89437-60010 |
US $19.36 |
||
|
89465
|
89465
89465-69015 Sensor, Oxygen[08.1987 - 01.1990] FJ62 |
89465-69015 |
US $145.60 |
||
|
89466
|
89466
89466-20020 Gasket(For Exhaust Manifold Plate)[10.1988 - 01.1990] FJ62 |
89466-20020 |
from US $12.45 |
||
|
89466
|
89466
89466-30010
Gasket(For Exhaust Manifold Plate)
[08.1987 - 10.1988] FJ62 |
89466-30010 |
— | ||
| replacement | |||||
|
89466
|
89466
89466-20020 Gasket(For Exhaust Manifold Plate)[08.1987 - 10.1988] FJ62 |
89466-20020 |
from US $12.45 |
||
|
89620
|
89620
89620-14410 Igniter Assy[08.1987 - 01.1990] FJ62 |
89620-14410 |
US $441.17 |
||
| replacement | |||||
|
89620
|
89620
89620-22420
Igniter Assy
[08.1987 - 01.1990] FJ62 |
89620-22420 |
— | ||
|
8271112200
|
8271112200
82711-12200 Clamp (For Fuel Lid Lock Control Cable) |
82711-12200 |
US $2.15 |
||
|
8271136070
|
8271136070
82711-36070 Wire, Fuse To Fuse(for Combustion Heater) |
82711-36070 |
US $8.30 |
||
|
8271160010
|
8271160010
82711-60010
Wire, Fuse To Fuse(for Combustion Heater)
|
82711-60010 |
— | ||
|
8271160020
|
8271160020
82711-60020
Wire, Fuse To Fuse(for Combustion Heater)
|
82711-60020 |
— | ||
|
8271160060
|
8271160060
82711-60060 Wire, Fuse To Fuse(for Combustion Heater) |
82711-60060 |
US $9.61 |
||
|
8271160070
|
8271160070
82711-60070 Wire, Fuse To Fuse(for Combustion Heater) |
82711-60070 |
US $9.90 |
||
|
8271160080
|
8271160080
82711-60080 Wire, Fuse To Fuse(for Combustion Heater) |
82711-60080 |
US $9.90 |
||
|
8271160110
|
8271160110
82711-60110 Wire, Fuse To Fuse(for Combustion Heater) |
82711-60110 |
US $4.08 |
||
|
9011908443
|
9011908443
90119-08443
New Genuine Part
|
90119-08443 |
— | ||
|
9017908059
|
9017908059
90179-08059
Nut
|
90179-08059 |
— | ||
| replacement | |||||
|
9017908059
|
9017908059
90179-08101 NUT |
90179-08101 |
from US $0.78 |
||
|
9046108312
|
9046108312
90461-08312 New Genuine Part |
90461-08312 |
US $4.89 |
||
|
9161160816
|
9161160816
91611-60816
Screw Or Bolt(For Valve Rocker Shaft Lock)
|
91611-60816 |
— | ||
| replacement | |||||
|
9161160816
|
9161160816
91611-B0816 Bolt |
91611-B0816 |
from US $0.99 |
||
|
9161161014
|
9161161014
91611-61014
New Genuine Part
|
91611-61014 |
— | ||
| replacement | |||||
|
9161161014
|
9161161014
91612-B1014 BOLT WWASHER |
91612-B1014 |
US $0.61 |
||
|
9165140825
|
9165140825
91651-40825 Bolt(For Clutch Release Cylinder Setting) |
91651-40825 |
from US $1.67 |
||
