Front Spring & Shock Absorber ([08.1987 - ] (8708- )FJ62) Diagram Toyota LAND CRUISER
- Year
- 1988 - 1990
- Sales region
- Japan
- Frame
- FJ62G
- grade
- VX
- Roof
- HRF
- ENGINE
- 3FE
- TRANSMISSION
- ATM
- Model
- LAND CRUISER 60
- From
- 08.1988
- To
- 01.1990
- Vehicle Model
- Land Cruiser VAN
- Fuel Induction
- EFI
- Building Condition
- CBU
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
48110
|
48110
48110-60223 Spring Assy, Front, Rh[08.1988 - 01.1990] FJ62..EFI ｱﾘ(ｳｲﾝﾁ) |
48110-60223 |
US $492.13 |
||
|
48110
|
48110
48110-60411 Spring Assy, Front, Rh[03.1988 - 01.1990] FJ62..CBU |
48110-60411 |
US $492.13 |
||
|
48111
|
48111
48111-60222 Leaf, Front Spring, No.1[08.1987 - 01.1990] FJ62..EFI ｱﾘ(ｳｲﾝﾁ); FJ62..CBU..CBR ｱﾘ(ｳｲﾝﾁ) |
48111-60222 |
US $160.16 |
||
|
48111
|
48111
48111-60410 Leaf, Front Spring, No.1[08.1987 - 01.1990] FJ62..CBU |
48111-60410 |
US $160.16 |
||
|
48112
|
48112
48112-60222 Leaf, Front Spring, No.2[08.1987 - 01.1990] FJ62..EFI ｱﾘ(ｳｲﾝﾁ); FJ62..CBU..CBR ｱﾘ(ｳｲﾝﾁ) |
48112-60222 |
US $136.86 |
||
|
48112
|
48112
48112-60410 Leaf, Front Spring, No.2[08.1987 - 01.1990] FJ62..CBU |
48112-60410 |
US $136.86 |
||
|
48113
|
48113
48102-60222 Leaf, Front Spring, No.3[08.1987 - 01.1990] FJ62..EFI ｱﾘ(ｳｲﾝﾁ); FJ62..CBU..CBR ｱﾘ(ｳｲﾝﾁ) |
48102-60222 |
US $99.01 |
||
|
48113
|
48113
48102-60410 Leaf, Front Spring, No.3[08.1987 - 01.1990] FJ62..CBU |
48102-60410 |
US $99.01 |
||
|
48114
|
48114
48114-60223 Leaf, Front Spring, No.4[08.1988 - 01.1990] FJ62..EFI ｱﾘ(ｳｲﾝﾁ) |
48114-60223 |
US $58.39 |
||
|
48114
|
48114
48114-60411 Leaf, Front Spring, No.4[03.1988 - 01.1990] FJ62..CBU |
48114-60411 |
US $58.39 |
||
|
48115
|
48115
48103-60223 Leaf, Front Spring, No.5[08.1988 - 01.1990] FJ62..EFI ｱﾘ(ｳｲﾝﾁ) |
48103-60223 |
US $41.79 |
||
|
48115
|
48115
48103-60411 Leaf, Front Spring, No.5[03.1988 - 01.1990] FJ62..CBU |
48103-60411 |
US $41.79 |
||
|
48120
|
48120
48110-60223 Spring Assy, Front, Rh[08.1988 - 01.1990] FJ62..EFI ｱﾘ(ｳｲﾝﾁ) |
48110-60223 |
US $492.13 |
||
|
48120
|
48120
48110-60411 Spring Assy, Front, Rh[03.1988 - 01.1990] FJ62..CBU |
48110-60411 |
US $492.13 |
||
|
48147
|
48147
48147-60223 Bolt, Front Spring, Center[03.1988 - 01.1990] FJ62..CBU |
48147-60223 |
US $4.95 |
||
|
48252D
|
48252D
48252-26070 Silencer, Front Spring[08.1987 - 01.1990] FJ62..IV4; FJ62..CBU |
48252-26070 |
from US $2.07 |
||
|
9411051000
|
9411051000
94110-51000 Nut(For Steering Center Arm) |
94110-51000 |
from US $0.74 |
