Radiator & Water Outlet ([08.1987 - ] (8708- )3F..IV4) Diagram Toyota LAND CRUISER
- Year
- 1987 - 1990
- Sales region
- Japan
- Frame
- FJ62V
- grade
- STD
- Roof
- SRF
- ENGINE
- 3F
- TRANSMISSION
- MTM
- Model
- LAND CRUISER 60
- From
- 08.1987
- To
- 01.1990
- Vehicle Model
- Land Cruiser VAN
- Fuel Induction
- CBR
- Building Condition
- IV4
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
16403B
|
16403B
16511-58010
Bracket, Sub Radiator
[08.1987 - 01.1990] 3F..FJ62..IV4 |
16511-58010 |
— | ||
|
16403E
|
16403E
90407-14051
Elbow(For Sub Radiator)
[08.1987 - 01.1990] 3F..FJ62..IV4 |
90407-14051 |
— | ||
| replacement | |||||
|
16403E
|
16403E
90407-53007 Union(For Water By-Pass Hose)[08.1987 - 01.1990] 3F..FJ62..IV4 |
90407-53007 |
US $9.32 |
||
|
16420
|
16420
16510-61010 Radiator Assy, Sub[08.1987 - 01.1990] 3F..FJ62..IV4 |
16510-61010 |
US $701.79 |
||
|
16420A
|
16420A
16551-61010 Hose, Sub Radiator, Inlet[08.1987 - 01.1990] 3F..FJ62..IV4 |
16551-61010 |
US $32.47 |
||
|
16420B
|
16420B
96111-10500 Clamp, Sub Radiator Inlet Hose[08.1987 - 01.1990] 3F..FJ62..IV4 |
96111-10500 |
from US $2.15 |
||
|
16510C
|
16510C
96112-10220 Clamp Or Clip, Hose(For Water By-Pass Hose)[08.1987 - 01.1990] 3F..FJ62..IV4 |
96112-10220 |
US $0.61 |
||
|
16510D
|
16510D
99552-20500 Hose, Sub Radiator, No.2[08.1987 - 01.1990] 3F..FJ62..IV4 長さ＝５００ |
99552-20500 |
US $10.05 |
||
| replacement | |||||
|
16510D
|
16510D
99556-20500
Hose, Rear Heater Water Inlet, B
[08.1987 - 01.1990] 3F..FJ62..IV4 長さ＝５００ |
99556-20500 |
— | ||
|
16523
|
16523
16523-58010
Seat(For Sub Radiator)
[08.1987 - 01.1990] 3F..FJ62..IV4 |
16523-58010 |
— | ||
|
16533A
|
16533A
16533-61010
Support, Sub Radiator Bracket
[08.1987 - 01.1990] 3F..FJ62..IV4 |
16533-61010 |
— | ||
|
16572
|
16572
16552-61010 Hose, Radiator, Outlet[08.1987 - 01.1990] 3F..FJ62..IV4 |
16552-61010 |
US $26.21 |
||
|
16572A
|
16572A
96111-10500 Clamp, Sub Radiator Inlet Hose[08.1987 - 01.1990] 3F..FJ62..IV4 |
96111-10500 |
from US $2.15 |
||
|
9161160825
|
9161160825
91611-60825
Bolt(For Head To Camshaft Bearing Cap)
|
91611-60825 |
— | ||
| replacement | |||||
|
9161160825
|
9161160825
91611-B0825 Bolt(For Clutch Release Cylinder Setting) |
91611-B0825 |
from US $1.08 |
||
|
9165140825
|
9165140825
91651-40825 Bolt(For Clutch Release Cylinder Setting) |
91651-40825 |
from US $1.67 |
||
