Heating & Air Conditioning - Heater Unit & Blower ([01.1998 - ] VISCOUS HEATER (9801- )HDJ100) Diagram Toyota LAND CRUISER
- Year
- 2003 - 2007
- Sales region
- Europe
- Frame
- HDJ100
- grade
- VX
- ENGINE
- 1HDFTE
- TRANSMISSION
- ATM
- Model
- LAND CRUISER 100
- From
- 07.2003
- To
- 08.2007
- Gear Shift Type
- 5FC
- Vehicle Model
- Land Cruiser
- Driver's Position
- LHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
87101
|
87101
87101-60012
Bracket Sub-Assy, Viscous Heater No.1
[08.2002 - 05.2005] HDJ100 |
87101-60012 |
— | ||
|
87120G
|
87120G
87120-60010 Heater Assy, Viscous W/magnet Clutch[08.2002 - 05.2005] HDJ100 |
87120-60010 |
US $974.06 |
||
|
87121A
|
87121A
87121-60052
Bracket, Heater
[08.2002 - 05.2005] HDJ100 |
87121-60052 |
— | ||
|
87452P
|
87452P
87452-60010
Bracket, Viscous Heater, No.2
[08.2002 - 05.2005] HDJ100 |
87452-60010 |
— | ||
|
88440F
|
88440F
88440-26070 Pulley Assy, Idle[08.2002 - 05.2005] HDJ100 |
88440-26070 |
from US $64.18 |
||
|
88444B
|
88444B
88444-60130
Bracket, Idle Pulley
[08.2002 - 05.2005] HDJ100 |
88444-60130 |
— | ||
|
9009907053
|
9009907053
90099-07053
Ring, Snap (For Cooler Idle Pulley)
|
90099-07053 |
— | ||
|
9009910015
|
9009910015
90099-10015 Bearing(For Alternator Rotor) |
90099-10015 |
US $13.40 |
||
|
9010508383
|
9010508383
90105-08383 New Genuine Part |
90105-08383 |
US $2.89 |
||
|
9010510438
|
9010510438
90105-10438 New Genuine Part |
90105-10438 |
US $2.69 |
||
|
9017910132
|
9017910132
90179-10132 Nut |
90179-10132 |
from US $0.91 |
||
|
9151180860
|
9151180860
91511-80860 Bolt(For Transaxle Case & Transmission Case Setting) |
91511-80860 |
US $2.06 |
||
|
9151261045
|
9151261045
91512-61045 Bolt |
91512-61045 |
US $2.51 |
||
|
9165160816
|
9165160816
91651-60816 BOLT |
91651-60816 |
from US $0.99 |
||
| replacement | |||||
|
9165160816
|
9165160816
90080-11396 BOLT |
90080-11396 |
US $3.32 |
||
