Manifold ([01.1998 - ] W/O(EGR COOLOR) (9801- )1HDFTE) Diagram Toyota LAND CRUISER
- Year
- 2003 - 2007
- Sales region
- Europe
- Frame
- HDJ100
- grade
- VX
- ENGINE
- 1HDFTE
- TRANSMISSION
- ATM
- Model
- LAND CRUISER 100
- From
- 07.2003
- To
- 08.2007
- Gear Shift Type
- 5FC
- Vehicle Model
- Land Cruiser
- Driver's Position
- LHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
04175
|
04175
04175-17070
Gasket Kit, Turbocharger
[05.2005 -] 1HDFTE..HDJ100 ARGENTINA OR NEW ZEALAND OR RUSSIA OR SOUTH AFRICA SPEC |
04175-17070 |
— | ||
|
04175
|
04175
04175-17090 Gasket Kit, TurbochargerTURBOCHARGER [05.2004 - 05.2005] 1HDFTE..HDJ100 ARGENTINA OR NEW ZEALAND OR RUSSIA OR SOUTH AFRICA SPEC |
04175-17090 |
US $112.11 |
||
|
04175
|
04175
04175-17100
Gasket Kit, Turbocharger
[05.2004 - 05.2005] 1HDFTE..HDJ100..5FC |
04175-17100 |
— | ||
|
04175
|
04175
04175-17110
Gasket Kit, Turbocharger
[05.2005 -] 1HDFTE..HDJ100..LHD..5FC SOUTH AFRICA SPEC |
04175-17110 |
— | ||
|
04175
|
04175
04175-17120 Gasket Kit, Turbocharger[05.2005 -] 1HDFTE..HDJ100 |
04175-17120 |
US $222.77 |
||
|
04176
|
04176
04176-17030 Seal Kit, TurbochargerTURBOCHARGER [05.2004 - 05.2005] 1HDFTE..HDJ100 |
04176-17030 |
US $27.08 |
||
|
16347C
|
16347C
16347-42020 Gasket, Water By-Pass[08.2002 - 05.2005] 1HDFTE..HDJ100 |
16347-42020 |
from US $2.64 |
||
|
17021A
|
17021A
90116-08158 Bolt, Stud(For Bearing Housing)[08.2002 - 05.2005] 1HDFTE..HDJ100 |
90116-08158 |
US $5.56 |
||
|
17021B
|
17021B
90116-06048 Bolt, Stud(For Oil Pan)[08.2002 - 05.2005] 1HDFTE..HDJ100 W/O(EGR COOLER) |
90116-06048 |
from US $0.65 |
||
|
17025A
|
17025A
90116-10125 Bolt, Stud(For Turbine Housing)[08.2002 - 05.2005] 1HDFTE..HDJ100 W/O(EGR COOLER) |
90116-10125 |
from US $1.25 |
||
|
17201
|
17201
17201-17040 Turbocharger Sub-Assy[08.2002 - 05.2005] 1HDFTE..HDJ100..STD; 1HDFTE..HDJ100..VX W/O(EGR COOLER) |
17201-17040 |
from US $2,779.50 |
||
|
17201
|
17201
17201-17070
Turbocharger Sub-Assy
[07.2003 - 05.2005] 1HDFTE..HDJ100..5FC W(EGR COOLER) |
17201-17070 |
— | ||
|
17229
|
17229
17229-46010 Band, V[08.2002 - 05.2005] 1HDFTE..HDJ100 |
17229-46010 |
from US $20.60 |
||
|
17230A
|
17230A
17230-19035 Repair Actuaor Assy, W/bracket[08.2002 - 05.2005] 1HDFTE..HDJ100..4FC,5F; 1HDFTE..HDJ100..5FC |
17230-19035 |
US $518.34 |
||
|
17230B
|
17230B
90201-08081 Washer, Plate(For Repair Actuator Set)[08.2002 - 05.2005] 1HDFTE..HDJ100 T=0.5 |
90201-08081 |
US $2.51 |
||
|
17230B
|
17230B
90201-08082 Washer, Plate(For Repair Actuator Set)[08.2002 - 05.2005] 1HDFTE..HDJ100 T=1.0 |
90201-08082 |
US $1.79 |
||
|
17230B
|
17230B
90201-08086 Washer, Plate(For Repair Actuator Set)[08.2002 - 05.2005] 1HDFTE..HDJ100 T=2.0 |
90201-08086 |
US $1.46 |
||
|
17230B
|
17230B
90201-08087 Washer, Plate(For Repair Actuator Set)[08.2002 - 05.2005] 1HDFTE..HDJ100 T=3.0 |
90201-08087 |
US $1.89 |
||
|
17294
|
17294
90445-12265 Hose, Actuator[08.2002 - 05.2005] 1HDFTE..HDJ100 |
90445-12265 |
US $3.99 |
||
|
17294A
|
17294A
96132-51100 Clip (For Hose)[08.2002 - 05.2005] 1HDFTE..HDJ100 |
96132-51100 |
from US $1.39 |
||
|
17296
|
17296
17296-28010 Plate, Bearing Housing, Side[08.2002 - 05.2005] 1HDFTE..HDJ100 |
17296-28010 |
US $10.57 |
||
|
91631B0614
|
91631B0614
91631-B0614 BOLT WWASHER |
91631-B0614 |
from US $0.84 |
||
|
91651B0820
|
91651B0820
91651-B0820 Bolt, Radiator Side Support Plate |
91651-B0820 |
from US $0.97 |
||
| replacement | |||||
|
91651B0820
|
91651B0820
90080-11347 New Genuine Part |
90080-11347 |
US $3.11 |
||
|
9017906018
|
9017906018
90179-06018 New Genuine Part |
90179-06018 |
US $0.83 |
||
|
9052304002
|
9052304002
90523-04002 RING |
90523-04002 |
US $1.43 |
||
|
9162160822
|
9162160822
91621-60822 Bolt, W/washer(For Repair Actuator Set) |
91621-60822 |
US $1.61 |
||
