Roof Panel & Back Panel ([08.2002 - ] (0208- )CYG,VXL) Diagram Toyota LAND CRUISER
- Year
- 2002 - 2007
- Sales region
- Japan
- Frame
- HDJ101
- grade
- VXL
- ENGINE
- 1HDFTE
- TRANSMISSION
- ATM
- Model
- LAND CRUISER 100
- From
- 08.2002
- To
- 08.2007
- Gear Shift Type
- 5FC
- Vehicle Model
- Land Cruiser
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
63201G
|
63201G
63201-60061
Glass Sub-Assy, Sliding Roof
[08.2002 - 12.2002] HDJ101,UZJ100..CYG,VXL ＊ＴＥＭ，厚さ＝４．０，グレー |
63201-60061 |
— | ||
| replacement | |||||
|
63201G
|
63201G
63201-60063 Glass Sub-Assy, Sliding Roof[08.2002 - 12.2002] HDJ101,UZJ100..CYG,VXL ＊ＴＥＭ，厚さ＝４．０，グレー |
63201-60063 |
US $801.96 |
||
|
63201G
|
63201G
63201-60062
Glass Sub-Assy, Sliding Roof
[12.2002 - 08.2003] HDJ101,UZJ100..CYG,VXL ＊ＴＥＭ，厚さ＝４．０，グレー |
63201-60062 |
— | ||
| replacement | |||||
|
63201G
|
63201G
63201-60063 Glass Sub-Assy, Sliding Roof[12.2002 - 08.2003] HDJ101,UZJ100..CYG,VXL ＊ＴＥＭ，厚さ＝４．０，グレー |
63201-60063 |
US $801.96 |
||
|
63201G
|
63201G
63201-60063 Glass Sub-Assy, Sliding Roof[08.2003 - 05.2005] HDJ101,UZJ100..CYG,VXL ＊ＴＥＭ，厚さ＝４．０，グレー |
63201-60063 |
US $801.96 |
||
|
63203F
|
63203F
63200-60150 Housing Sub-Assy, Sliding Roof[08.2002 - 07.2004] HDJ101,UZJ100..VXL |
63200-60150 |
US $2,431.52 |
||
| replacement | |||||
|
63203F
|
63203F
63200-60151 Housing Sub-Assy, Sliding Roof[08.2002 - 07.2004] HDJ101,UZJ100..VXL |
63200-60151 |
US $2,431.52 |
||
|
63203F
|
63203F
63200-60151 Housing Sub-Assy, Sliding Roof[07.2004 - 05.2005] HDJ101,UZJ100..VXL |
63200-60151 |
US $2,431.52 |
||
|
63206G
|
63206G
63260-60110 Gear Sub-Assy, Sliding Roof Drive[08.2002 - 05.2005] HDJ101,UZJ100..VXL |
63260-60110 |
US $634.82 |
||
|
63217G
|
63217G
63217-60040 Garnish, Sliding Roof Side, Rh[08.2002 - 05.2005] HDJ101,UZJ100..CYG,VXL |
63217-60040 |
US $37.46 |
||
|
63218G
|
63218G
63218-60040 Garnish, Sliding Roof Side, Lh[08.2002 - 05.2005] HDJ101,UZJ100..CYG,VXL |
63218-60040 |
US $29.18 |
||
|
63239
|
63239
63239-60010 Stopper, Sliding Roof Panel[08.2002 - 05.2005] HDJ101,UZJ100..CYG,VXL |
63239-60010 |
US $6.29 |
||
|
63249E
|
63249E
63249-60120
Hose, Sliding Roof Drain
[08.2002 - 05.2005] HDJ101,UZJ100..CYG,VXL 右側 |
63249-60120 |
— | ||
| replacement | |||||
|
63249E
|
63249E
63249-60122 Hose, Sliding Roof Drain[08.2002 - 05.2005] HDJ101,UZJ100..CYG,VXL 右側 |
63249-60122 |
US $20.97 |
||
|
63249E
|
63249E
63249-60122 Hose, Sliding Roof Drain[06.2005 -] HDJ101,UZJ100..CYG,VXL 右側 |
63249-60122 |
US $20.97 |
||
|
63249E
|
63249E
63249-60150 Hose, Sliding Roof Drain[08.2002 - 05.2005] HDJ101,UZJ100..CYG,VXL 左側 |
63249-60150 |
US $21.55 |
||
| replacement | |||||
|
63249E
|
63249E
63249-60152 Hose, Sliding Roof Drain[08.2002 - 05.2005] HDJ101,UZJ100..CYG,VXL 左側 |
63249-60152 |
US $21.55 |
||
|
63249E
|
63249E
63249-60152 Hose, Sliding Roof Drain[06.2005 -] HDJ101,UZJ100..CYG,VXL 左側 |
63249-60152 |
US $21.55 |
||
|
63249F
|
63249F
63249-60170 Hose, Sliding Roof Drain[08.2002 - 05.2005] HDJ101,UZJ100..CYG,VXL 長さ＝１４１５ |
63249-60170 |
US $24.02 |
||
| replacement | |||||
|
63249F
|
63249F
63249-60172 Hose, Sliding Roof Drain[08.2002 - 05.2005] HDJ101,UZJ100..CYG,VXL 長さ＝１４１５ |
63249-60172 |
US $24.02 |
||
|
63249F
|
63249F
63249-60172 Hose, Sliding Roof Drain[06.2005 -] HDJ101,UZJ100..CYG,VXL 長さ＝１４１５ |
63249-60172 |
US $24.02 |
||
|
63249G
|
63249G
63249-60180 Hose, Sliding Roof Drain[08.2002 - 05.2005] HDJ101,UZJ100..CYG,VXL 長さ＝１５２５ |
63249-60180 |
US $26.79 |
||
| replacement | |||||
|
63249G
|
63249G
63249-60182 Hose, Sliding Roof Drain[08.2002 - 05.2005] HDJ101,UZJ100..CYG,VXL 長さ＝１５２５ |
63249-60182 |
US $26.79 |
||
|
63249G
|
63249G
63249-60182 Hose, Sliding Roof Drain[06.2005 -] HDJ101,UZJ100..CYG,VXL 長さ＝１５２５ |
63249-60182 |
US $26.79 |
||
|
63251H
|
63251H
63251-60061
Weatherstrip, Sliding Roof
[08.2002 - 05.2004] HDJ101,UZJ100..CYG,VXL |
63251-60061 |
— | ||
| replacement | |||||
|
63251H
|
63251H
63251-60062 Weatherstrip, Sliding Roof[08.2002 - 05.2004] HDJ101,UZJ100..CYG,VXL |
63251-60062 |
from US $86.89 |
||
|
63251H
|
63251H
63251-60062 Weatherstrip, Sliding Roof[05.2004 - 05.2005] HDJ101,UZJ100..CYG,VXL |
63251-60062 |
from US $86.89 |
||
|
63257B
|
63257B
63257-60020 Seal, Sliding Roof[08.2002 - 05.2005] HDJ101,UZJ100..CYG,VXL |
63257-60020 |
US $4.19 |
||
|
9017906161
|
9017906161
90179-06161 Bolt, Union(For Clutch Accumulator) |
90179-06161 |
from US $0.78 |
||
|
9017906274
|
9017906274
90179-06274 Nut |
90179-06274 |
from US $0.68 |
||
|
9046716038
|
9046716038
90467-16038
Clip Or Clamp(For Ventilation Hose)
|
90467-16038 |
— | ||
|
9046915003
|
9046915003
90469-15003 Clamp Or Clip, Hose(For Water By-Pass Hose) |
90469-15003 |
from US $0.70 |
||
|
9048026014
|
9048026014
90480-26014 GROMMET |
90480-26014 |
US $3.86 |
||
|
9095901553
|
9095901553
90959-01553 CLAMP |
90959-01553 |
US $0.61 |
||
|
9095901566
|
9095901566
90959-01566 New Genuine Part |
90959-01566 |
US $1.46 |
||
|
9162140614
|
9162140614
91621-40614 BOLT |
91621-40614 |
from US $0.74 |
||
|
9321913014
|
9321913014
93219-13014 SCREW |
93219-13014 |
from US $0.70 |
||
