Clutch Pedal & Flexible Hose ([01.1998 - 08.2002] (9801-0208)MTM) Diagram Toyota LAND CRUISER
- Year
- 1998 - 2002
- Sales region
- Japan
- Frame
- HDJ101
- grade
- VX
- ENGINE
- 1HDFTE
- TRANSMISSION
- MTM
- Model
- LAND CRUISER 100
- From
- 01.1998
- To
- 08.2002
- Gear Shift Type
- 5F
- Vehicle Model
- Land Cruiser
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
31301
|
31301
31301-60210
Pedal Sub-Assy, Clutch
[01.1998 - 08.2002] HDJ101..MTM |
31301-60210 |
— | ||
|
31301A
|
31301A
90507-26008 Spring(For Clutch Pedal)[01.1998 - 08.2002] HDJ101..MTM |
90507-26008 |
US $5.07 |
||
|
31301C
|
31301C
90386-13020 Bush(For Clutch Pedal)[01.1998 - 08.2002] HDJ101..MTM |
90386-13020 |
from US $1.90 |
||
|
31301F
|
31301F
90101-10369 Bolt(For Clutch Pedal Stopper)[01.1998 - 08.2002] HDJ101..MTM |
90101-10369 |
from US $1.27 |
||
|
31301J
|
31301J
94130-61000 Nut(For Clutch Pedal Stopper)[01.1998 - 08.2002] HDJ101..MTM |
94130-61000 |
from US $0.76 |
||
|
31321
|
31321
31321-14020 Pad, Clutch Pedal[01.1998 - 08.2002] HDJ101..MTM |
31321-14020 |
from US $3.29 |
||
| replacement | |||||
|
31321
|
31321
31321YE010
PAD PEDAL
[01.1998 - 08.2002] HDJ101..MTM |
31321YE010 |
— | ||
|
31324
|
31324
91121-51060 Shaft, Clutch Pedal[01.1998 - 08.2002] HDJ101..MTM |
91121-51060 |
from US $2.34 |
||
|
31324A
|
31324A
90387-10003 Collar, Clutch Pedal Shaft[01.1998 - 08.2002] HDJ101..MTM |
90387-10003 |
from US $3.84 |
||
|
31354A
|
31354A
90386-10019 Bush(For Clutch Pedal Spring Seat Upper)[01.1998 - 08.2002] HDJ101..MTM |
90386-10019 |
from US $1.88 |
||
|
31354B
|
31354B
90249-10127 Pin, W/hole(For Clutch Pedal Spring Seat Upper)[01.1998 - 08.2002] HDJ101..MTM |
90249-10127 |
US $4.66 |
||
|
31356F
|
31356F
31356-60010 Plate, Clutch Pedal Over Center, No.1[01.1998 - 08.2002] HDJ101..MTM |
31356-60010 |
US $30.58 |
||
|
31356G
|
31356G
90249-09019 Pin(For Clutch Pedal Support Over Center Plate)[01.1998 - 08.2002] HDJ101..MTM |
90249-09019 |
US $4.37 |
||
|
31356H
|
31356H
90245-12005 Pin, No.2(For Clutch Pedal Support Over Center Plate)[01.1998 - 08.2002] HDJ101..MTM |
90245-12005 |
US $4.37 |
||
|
31357D
|
31357D
90506-32005 Spring, Compression(For Over Center Adjusting Rod)[01.1998 - 08.2002] HDJ101..MTM |
90506-32005 |
US $5.77 |
||
|
31453A
|
31453A
90249-08018 Pin, W/hole(For Clutch Master Cylinder Push Rod Clevis)[01.1998 - 08.2002] HDJ101..MTM 長さ＝２９．５ |
90249-08018 |
from US $2.15 |
||
|
31453B
|
31453B
90386-08033 Bush(For Clutch Master Cylinder Push Rod Clevis)[01.1998 - 08.2002] HDJ101..MTM |
90386-08033 |
from US $1.25 |
||
|
55107A
|
55107A
55107-60100
Support Sub-Assy, Clutch Pedal
[01.1998 - 08.2002] HDJ101..MTM |
55107-60100 |
— | ||
|
9011908786
|
9011908786
90119-08786
New Genuine Part
|
90119-08786 |
— | ||
| replacement | |||||
|
9011908786
|
9011908786
90119-08856 BOLT WWASHER |
90119-08856 |
US $2.51 |
||
|
9046816142
|
9046816142
90468-16142 Clip(For Push Rod Clevis Pin) |
90468-16142 |
from US $0.80 |
||
|
9056109017
|
9056109017
90561-09017 SPACER |
90561-09017 |
US $1.65 |
||
|
9056109018
|
9056109018
90561-09018 SPACER |
90561-09018 |
US $0.70 |
||
|
9413061000
|
9413061000
94130-61000 Nut(For Clutch Pedal Stopper) |
94130-61000 |
from US $0.76 |
||
|
9451201000
|
9451201000
94512-01000 Washer, No.1 (For Propeller Shaft & Differential Setting) |
94512-01000 |
from US $0.78 |
||
|
9616000600
|
9616000600
96160-00600 Ring, E(For Clutch Pedal Pawl) |
96160-00600 |
from US $0.82 |
||
|
9616000800
|
9616000800
96160-00800 Ring, E(For Counter Weight) |
96160-00800 |
from US $0.86 |
||
