Front Axle Housing & Differential ([01.1998 - ] (9801- )) Diagram Toyota LAND CRUISER
- Year
- 1998 - 2002
- Sales region
- Japan
- Frame
- HDJ101
- grade
- VX
- ENGINE
- 1HDFTE
- TRANSMISSION
- MTM
- Model
- LAND CRUISER 100
- From
- 01.1998
- To
- 08.2002
- Gear Shift Type
- 5F
- Vehicle Model
- Land Cruiser
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
41110R
|
41110R
90930-03097 Plug, Breather (For Differential)[01.1998 - 08.2002] HDJ101,UZJ100 |
90930-03097 |
from US $6.63 |
||
|
91651B0814
|
91651B0814
91651-B0814 Bolt with washer |
91651-B0814 |
from US $0.84 |
||
|
4153360020
|
4153360020
41533-60020
Tube, Front Differential Breather
|
41533-60020 |
— | ||
|
9044510083
|
9044510083
90445-10083 HOSE |
90445-10083 |
US $4.02 |
||
|
9044706010
|
9044706010
90447-06010 HOSE |
90447-06010 |
US $10.83 |
||
|
9046912008
|
9046912008
90469-12008 Clamp |
90469-12008 |
US $1.97 |
||
|
9613551100
|
9613551100
96135-51100 Clamp Or Clip(For Turbo Oil Outlet Hose) |
96135-51100 |
from US $1.79 |
