Heating & Air Conditioning - Cooler Piping ([01.1998 - ] ｺﾝﾃﾞﾝｻ (9801- )HDJ101 ; (0208- )VX) Diagram Toyota LAND CRUISER
- Year
- 1998 - 2002
- Sales region
- Japan
- Frame
- HDJ101
- grade
- VX
- ENGINE
- 1HDFTE
- TRANSMISSION
- MTM
- Model
- LAND CRUISER 100
- From
- 01.1998
- To
- 08.2002
- Gear Shift Type
- 5F
- Vehicle Model
- Land Cruiser
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
88460
|
88460
88460-60260 Condenser Assy, Cooler[01.1998 - 10.1998] HDJ101 |
88460-60260 |
US $799.34 |
||
| replacement | |||||
|
88460
|
88460
88840-60040
Condenser Assy, Cooler
[01.1998 - 10.1998] HDJ101 |
88840-60040 |
— | ||
|
88460
|
88460
88460-60261 Condenser Assy, Cooler[10.1998 - 08.2002] HDJ101 |
88460-60261 |
US $747.80 |
||
|
88460B
|
88460B
88688-60770
Bracket, Cooler Condenser, No.1
[01.1998 - 10.1998] HDJ101,UZJ100 |
88688-60770 |
— | ||
| replacements | |||||
|
88460B
|
88460B
88469-16040
Insulator, Cooler Condenser Mounting
[01.1998 - 10.1998] HDJ101,UZJ100 |
88469-16040 |
— | ||
|
88460B
|
88460B
88688-6A220
Bracket, Cooler Diaphragm
[01.1998 - 10.1998] HDJ101,UZJ100 |
88688-6A220 |
— | ||
|
88460B
|
88460B
88897-60070
Valve, Cooler Magnet
[01.1998 - 10.1998] HDJ101,UZJ100 |
88897-60070 |
— | ||
|
88460C
|
88460C
88688-60780
Bracket, Cooler Condenser, No.2
[01.1998 - 08.2002] HDJ101 |
88688-60780 |
— | ||
| replacements | |||||
|
88460C
|
88460C
88469-16040
Insulator, Cooler Condenser Mounting
[01.1998 - 08.2002] HDJ101 |
88469-16040 |
— | ||
|
88460C
|
88460C
88688-6A210
Bracket, Cooler Diaphragm
[01.1998 - 08.2002] HDJ101 |
88688-6A210 |
— | ||
|
88460C
|
88460C
88897-60070
Valve, Cooler Magnet
[01.1998 - 08.2002] HDJ101 |
88897-60070 |
— | ||
|
88460D
|
88460D
88688-60790
Bracket, Cooler Condenser, No.3
[01.1998 - 08.2002] HDJ101,UZJ100 |
88688-60790 |
— | ||
| replacements | |||||
|
88460D
|
88460D
88688-6A230
Bracket, Cooler Diaphragm
[01.1998 - 08.2002] HDJ101,UZJ100 |
88688-6A230 |
— | ||
|
88460D
|
88460D
88897-60060
Valve, Cooler Magnet
[01.1998 - 08.2002] HDJ101,UZJ100 |
88897-60060 |
— | ||
|
88460F
|
88460F
88688-60800
Bracket, Cooler Condenser, No.4
[01.1998 - 08.2002] HDJ101 |
88688-60800 |
— | ||
| replacements | |||||
|
88460F
|
88460F
88688-6A200
Bracket, Cooler Diaphragm
[01.1998 - 08.2002] HDJ101 |
88688-6A200 |
— | ||
|
88460F
|
88460F
88897-60060
Valve, Cooler Magnet
[01.1998 - 08.2002] HDJ101 |
88897-60060 |
— | ||
|
88474
|
88474
88474-47010 Dryer, Cooler[01.1998 - 09.1999] HDJ101 |
88474-47010 |
from US $33.95 |
||
|
88716A
|
88716A
88716-6A850 Pipe, Cooler Refrigerant Liquid, A[01.1998 - 08.2002] HDJ101 ＮＯ．１ |
88716-6A850 |
from US $34.83 |
||
|
88716A
|
88716A
88726-60420 Pipe, Cooler Refrigerant Liquid, A[01.1998 - 09.1998] HDJ101 ＮＯ．２ |
88726-60420 |
US $68.43 |
||
| replacement | |||||
|
88716A
|
88716A
88726-60421 Pipe, Cooler Refrigerant Liquid, A[01.1998 - 09.1998] HDJ101 ＮＯ．２ |
88726-60421 |
US $83.64 |
||
|
88716A
|
88716A
88726-60421 Pipe, Cooler Refrigerant Liquid, A[09.1998 - 08.2002] HDJ101 ＮＯ．２ |
88726-60421 |
US $83.64 |
||
|
88716A
|
88716A
88726-60430
Pipe, Cooler Refrigerant Liquid, A
[01.1998 - 08.2002] HDJ101 ｱﾘ(ｸ-ﾙ ﾎﾞﾂｸｽ),ＮＯ．２ |
88726-60430 |
— | ||
|
88891A
|
88891A
88578-60100
Packing A (For Cooler)
[01.1998 - 08.2002] HDJ101,UZJ100 |
88578-60100 |
— | ||
|
91631G0830
|
91631G0830
91631-G0830 BOLT WWASHER |
91631-G0830 |
US $2.87 |
||
|
886886A240
|
886886A240
88688-6A240
Bracket, Cooler Diaphragm
|
88688-6A240 |
— | ||
|
886886A340
|
886886A340
88688-6A340
Bracket, Cooler Diaphragm
|
88688-6A340 |
— | ||
|
9009120609
|
9009120609
90091-20609 BOLT |
90091-20609 |
US $0.41 |
||
|
9009904500
|
9009904500
90099-04500 New Genuine Part |
90099-04500 |
US $1.46 |
||
|
9009914119
|
9009914119
90099-14119 Ring, O(For Cooler Refrigerant Liquid Pipe) |
90099-14119 |
from US $1.62 |
||
| replacement | |||||
|
9009914119
|
9009914119
90099-14119-TH O RING |
90099-14119-TH |
US $0.67 |
||
