Air Cleaner ([08.1987 - ] (8708- )12HT) Diagram Toyota LAND CRUISER
- Year
- 1987 - 1990
- Sales region
- Europe
- Frame
- HJ61
- grade
- VX
- Roof
- SRF
- ENGINE
- 12HT
- TRANSMISSION
- MTM
- Model
- LAND CRUISER 60
- From
- 08.1987
- To
- 01.1990
- Vehicle Model
- Land Cruiser
- Back Door
- LUB
- Driver's Position
- LHD
- Fuel Induction
- TD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
17138
|
17138
17138-68010
Stay, Intake Pipe Or Hose
[08.1987 - 01.1990] 12HT..HJ61 |
17138-68010 |
— | ||
|
17875
|
17875
17113-68010
Pipe, Intake Air Connector
[08.1987 - 01.1990] 12HT..HJ61 |
17113-68010 |
— | ||
|
17875A
|
17875A
17115-68010
Gasket, Intake Pipe
[08.1987 - 01.1990] 12HT..HJ61 |
17115-68010 |
— | ||
| replacement | |||||
|
17875A
|
17875A
17115-68020 Gasket, Intake Pipe[08.1987 - 01.1990] 12HT..HJ61 |
17115-68020 |
US $6.63 |
||
|
17881
|
17881
17881-68060 Hose, Air Cleaner, No.1[08.1987 - 01.1990] 12HT..HJ61 |
17881-68060 |
US $76.61 |
||
|
17881A
|
17881A
96111-10830 Clamp, Hose(For Air Connector)[08.1987 - 01.1990] 12HT,2H..HJ6# AIR CLEANER SIDE |
96111-10830 |
from US $3.23 |
||
|
17881A
|
17881A
96111-10900 Clamp, Hose[08.1987 - 01.1990] 12HT..HJ61 PIPE SIDE |
96111-10900 |
from US $1.16 |
||
|
17882
|
17882
17342-68010
Hose, Air Cleaner, No.2
[08.1987 - 01.1990] 12HT..HJ61 |
17342-68010 |
— | ||
|
17882A
|
17882A
90460-80001
Clamp, Hose
[12.1987 - 01.1990] 12HT..HJ61 TURBO SIDE |
90460-80001 |
— | ||
| replacement | |||||
|
17882A
|
17882A
90460-80006 Clamp, Hose[12.1987 - 01.1990] 12HT..HJ61 TURBO SIDE |
90460-80006 |
from US $8.11 |
||
|
17882A
|
17882A
90460-90001 Clamp(For Intake Air Connector)[12.1987 - 01.1990] 12HT..HJ61 PIPE SIDE |
90460-90001 |
US $9.26 |
||
|
17882A
|
17882A
96111-10800 Clamp, Hose(For Air Cleaner Duct)[08.1987 - 12.1987] 12HT..HJ61 TURBO SIDE |
96111-10800 |
from US $2.87 |
||
|
17882A
|
17882A
96111-10900 Clamp, Hose[08.1987 - 12.1987] 12HT..HJ61 PIPE SIDE |
96111-10900 |
from US $1.16 |
||
|
17883
|
17883
17341-68010
Hose, Air Cleaner, No.3
[08.1987 - 01.1990] 12HT..HJ61 |
17341-68010 |
— | ||
|
17883A
|
17883A
90460-65004
Clamp Or Clip(For Air Hose, No.1)
[08.1987 - 01.1990] 12HT..HJ61 |
90460-65004 |
— | ||
| replacement | |||||
|
17883A
|
17883A
90460-65002 Clamp Or Clip(For Air Hose, No.1)[08.1987 - 01.1990] 12HT..HJ61 |
90460-65002 |
from US $3.69 |
||
|
17885
|
17885
17875-68010
Pipe, Air Cleaner
[08.1987 - 01.1990] 12HT..HJ61 |
17875-68010 |
— | ||
|
53299B
|
53299B
53207-90A01 Duct, Air Cleaner[08.1987 - 01.1990] HJ6# |
53207-90A01 |
US $96.10 |
||
|
9161160855
|
9161160855
91611-60855 Bolt(For Rocker Support Set) |
91611-60855 |
US $1.79 |
||
|
9162160825
|
9162160825
91621-60825
BOLT
|
91621-60825 |
— | ||
| replacement | |||||
|
9162160825
|
9162160825
91651-B0825 Bolt, Hexagon(For Steering Column Bracket) |
91651-B0825 |
from US $0.82 |
||
|
9165140612
|
9165140612
91651-40612 BOLT |
91651-40612 |
from US $0.95 |
||
| replacement | |||||
|
9165140612
|
9165140612
90080-11225 New Genuine Part |
90080-11225 |
US $2.97 |
||
|
9165160814
|
9165160814
91651-60814
Clamp Or Clip, Hose(for Radiator Outlet No.1)
|
91651-60814 |
— | ||
| replacement | |||||
|
9165160814
|
9165160814
91651-B0814 Bolt with washer |
91651-B0814 |
from US $0.84 |
||
|
9611110800
|
9611110800
96111-10800 Clamp, Hose(For Air Cleaner Duct) |
96111-10800 |
from US $2.87 |
||
