Front Spring & Shock Absorber ([08.1987 - ] (8708- )) Diagram Toyota LAND CRUISER
- Year
- 1987 - 1990
- Sales region
- Europe
- Frame
- HJ61
- grade
- VX
- Roof
- SRF
- ENGINE
- 12HT
- TRANSMISSION
- MTM
- Model
- LAND CRUISER 60
- From
- 08.1987
- To
- 01.1990
- Vehicle Model
- Land Cruiser
- Back Door
- LUB
- Driver's Position
- LHD
- Fuel Induction
- TD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
48110
|
48110
48110-60361 Spring Assy, Front, Rh[08.1987 - 03.1988] HJ6# |
48110-60361 |
US $722.18 |
||
| replacement | |||||
|
48110
|
48110
48110-60362 Spring Assy, Front, Rh[08.1987 - 03.1988] HJ6# |
48110-60362 |
US $725.09 |
||
|
48110
|
48110
48110-60362 Spring Assy, Front, Rh[03.1988 - 01.1990] HJ6# |
48110-60362 |
US $725.09 |
||
|
48111
|
48111
48111-60361 Leaf, Front Spring, No.1[08.1987 - 01.1990] HJ6# |
48111-60361 |
US $177.63 |
||
| replacement | |||||
|
48111
|
48111
48111-60222 Leaf, Front Spring, No.1[08.1987 - 01.1990] HJ6# |
48111-60222 |
US $160.16 |
||
|
48112
|
48112
48112-60361 Leaf, Front Spring, No.2[08.1987 - 01.1990] HJ6# |
48112-60361 |
US $136.86 |
||
| replacement | |||||
|
48112
|
48112
48112-60222 Leaf, Front Spring, No.2[08.1987 - 01.1990] HJ6# |
48112-60222 |
US $136.86 |
||
|
48113
|
48113
48102-60361 Leaf, Front Spring, No.3[08.1987 - 01.1990] HJ6# |
48102-60361 |
US $116.48 |
||
|
48114
|
48114
48114-60361 Leaf, Front Spring, No.4[08.1987 - 03.1988] HJ6# |
48114-60361 |
US $61.44 |
||
| replacement | |||||
|
48114
|
48114
48114-60460 Leaf, Front Spring, No.4[08.1987 - 03.1988] HJ6# |
48114-60460 |
US $61.44 |
||
|
48114
|
48114
48114-60362 Leaf, Front Spring, No.4[03.1988 - 01.1990] HJ6# |
48114-60362 |
US $61.44 |
||
| replacement | |||||
|
48114
|
48114
48114-60461 Leaf, Front Spring, No.4[03.1988 - 01.1990] HJ6# |
48114-60461 |
US $61.88 |
||
|
48115
|
48115
48115-60361 Leaf, Front Spring, No.5[08.1987 - 03.1988] HJ6# |
48115-60361 |
US $53.29 |
||
| replacement | |||||
|
48115
|
48115
48115-60460 Leaf, Front Spring, No.5[08.1987 - 03.1988] HJ6# |
48115-60460 |
US $53.14 |
||
|
48115
|
48115
48115-60362 Leaf, Front Spring, No.5[03.1988 - 01.1990] HJ6# |
48115-60362 |
US $53.14 |
||
| replacement | |||||
|
48115
|
48115
48115-60461 Leaf, Front Spring, No.5[03.1988 - 01.1990] HJ6# |
48115-60461 |
US $53.44 |
||
|
48116
|
48116
48103-60361 Leaf, Front Spring, No.6[08.1987 - 03.1988] HJ6# |
48103-60361 |
US $64.06 |
||
|
48116
|
48116
48103-60362 Leaf, Front Spring, No.6[03.1988 - 01.1990] HJ61;HJ60..STD;HJ60..LUB;HJ60..HRF..SOB |
48103-60362 |
US $64.06 |
||
| replacement | |||||
|
48116
|
48116
48103-60461 Leaf, Front Spring, No.6[03.1988 - 01.1990] HJ61;HJ60..STD;HJ60..LUB;HJ60..HRF..SOB |
48103-60461 |
US $64.36 |
||
|
48117
|
48117
48104-60310 Leaf, Front Spring, No.7[08.1987 - 01.1990] HJ6# |
48104-60310 |
US $128.13 |
||
|
48120
|
48120
48110-60361 Spring Assy, Front, Rh[08.1987 - 03.1988] HJ6# |
48110-60361 |
US $722.18 |
||
| replacement | |||||
|
48120
|
48120
48110-60362 Spring Assy, Front, Rh[08.1987 - 03.1988] HJ6# |
48110-60362 |
US $725.09 |
||
|
48120
|
48120
48110-60362 Spring Assy, Front, Rh[03.1988 - 01.1990] HJ6# |
48110-60362 |
US $725.09 |
||
|
48147
|
48147
48147-60310 Bolt, Front Spring, Center[08.1987 - 03.1988] HJ6# |
48147-60310 |
US $4.95 |
||
|
48147
|
48147
48147-60311 Bolt, Front Spring, Center[03.1988 - 01.1990] HJ6# |
48147-60311 |
US $4.95 |
||
|
48152
|
48152
48152-60310 Seat, Front Spring[08.1987 - 01.1990] HJ6# |
48152-60310 |
US $15.87 |
||
|
48252D
|
48252D
48252-26070 Silencer, Front Spring[03.1988 - 01.1990] HJ6# |
48252-26070 |
from US $2.07 |
||
|
9411051000
|
9411051000
94110-51000 Nut(For Steering Center Arm) |
94110-51000 |
from US $0.74 |
||
