Manifold ([10.1985 - ] (8510- )12HT) Diagram Toyota LAND CRUISER
- Year
- 1985 - 1987
- Sales region
- General
- Frame
- HJ61
- body
- WGG
- Roof
- SRF
- ENGINE
- 12HT
- TRANSMISSION
- ATM
- DESTINATION
- ARL
- Model
- LAND CRUISER 60
- From
- 10.1985
- To
- 08.1987
- Gear Shift Type
- 4FC
- Vehicle Model
- Land Cruiser
- Back Door
- LUB
- Driver's Position
- RHD
- Fuel Induction
- TD
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
04175
|
04175
04175-68010
Gasket Kit, Turbocharger
[10.1985 - 08.1987] 12HT..HJ61 |
04175-68010 |
— | ||
| replacement | |||||
|
04175
|
04175
04175-68012
Gasket Kit, Turbocharger
[10.1985 - 08.1987] 12HT..HJ61 |
04175-68012 |
— | ||
|
17021A
|
17021A
90116-08158 Bolt, Stud(For Bearing Housing)[10.1985 - 08.1987] 12HT..HJ61 |
90116-08158 |
US $5.56 |
||
|
17025A
|
17025A
90116-10125 Bolt, Stud(For Turbine Housing)[10.1985 - 08.1987] 12HT..HJ61 |
90116-10125 |
from US $1.25 |
||
|
17201
|
17201
17201-68010
Turbocharger Sub-Assy
[10.1985 - 08.1987] 12HT..HJ61 |
17201-68010 |
— | ||
|
17294
|
17294
17294-28010 Hose, Actuator[10.1985 - 08.1987] 12HT..HJ61 |
17294-28010 |
US $16.07 |
||
|
17294A
|
17294A
96132-30600
Clip(For Actuator Hose)
[10.1985 - 08.1987] 12HT..HJ61 |
96132-30600 |
— | ||
| replacement | |||||
|
17294A
|
17294A
96132-51100 Clip (For Hose)[10.1985 - 08.1987] 12HT..HJ61 |
96132-51100 |
from US $1.39 |
||
|
9052304002
|
9052304002
90523-04002 RING |
90523-04002 |
US $1.43 |
||
