Manifold ([08.1987 - ] (8708- )12HT) Diagram Toyota LAND CRUISER
- Year
- 1987 - 1990
- Sales region
- Japan
- Frame
- HJ61
- grade
- VX
- Roof
- HRF
- ENGINE
- 12HT
- TRANSMISSION
- MTM
- Model
- LAND CRUISER 60
- From
- 08.1987
- To
- 01.1990
- Vehicle Model
- Land Cruiser VAN
- Fuel Induction
- TD
- Building Condition
- CBU
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
04175
|
04175
04175-68010
Gasket Kit, Turbocharger
[08.1987 - 01.1990] 12HT..HJ61 |
04175-68010 |
— | ||
| replacement | |||||
|
04175
|
04175
04175-68012
Gasket Kit, Turbocharger
[08.1987 - 01.1990] 12HT..HJ61 |
04175-68012 |
— | ||
|
04176
|
04176
04176-58010 Seal Kit, Turbocharger[08.1987 - 10.1989] 12HT..HJ61 |
04176-58010 |
US $13.54 |
||
| replacement | |||||
|
04176
|
04176
04176-58011 Seal Kit, Turbocharger[08.1987 - 10.1989] 12HT..HJ61 |
04176-58011 |
US $8.56 |
||
|
04176
|
04176
04176-58011 Seal Kit, Turbocharger[10.1989 - 01.1990] 12HT..HJ61 |
04176-58011 |
US $8.56 |
||
|
17021
|
17021
17021-58010 Housing Sub-Assy, Bearing[08.1987 - 04.1989] 12HT..HJ61 |
17021-58010 |
US $1,761.76 |
||
|
17021
|
17021
17021-74030 Housing Sub-Assy, Bearing[04.1989 - 10.1989] 12HT..HJ61 |
17021-74030 |
US $1,630.72 |
||
| replacement | |||||
|
17021
|
17021
17021-58010 Housing Sub-Assy, Bearing[04.1989 - 10.1989] 12HT..HJ61 |
17021-58010 |
US $1,761.76 |
||
|
17021A
|
17021A
90116-08158 Bolt, Stud(For Bearing Housing)[08.1987 - 01.1990] 12HT..HJ61 |
90116-08158 |
US $5.56 |
||
|
17021B
|
17021B
90116-06048 Bolt, Stud(For Oil Pan)[08.1987 - 01.1990] 12HT..HJ61 |
90116-06048 |
from US $0.65 |
||
|
17021C
|
17021C
90521-99023 Ring, Hole Snap(For Bearing Housing)[08.1987 - 01.1990] 12HT..HJ61 |
90521-99023 |
US $5.53 |
||
|
17025A
|
17025A
90116-10125 Bolt, Stud(For Turbine Housing)[08.1987 - 01.1990] 12HT..HJ61 |
90116-10125 |
from US $1.25 |
||
|
17201
|
17201
17201-68010
Turbocharger Sub-Assy
[08.1987 - 01.1990] 12HT..HJ61 |
17201-68010 |
— | ||
|
17224
|
17224
17224-58010 Housing, Compressor[08.1987 - 01.1990] 12HT..HJ61 |
17224-58010 |
US $368.37 |
||
| replacements | |||||
|
17224
|
17224
17224-58011 Housing, Compressor[08.1987 - 01.1990] 12HT..HJ61 |
17224-58011 |
US $368.37 |
||
|
17224
|
17224
17224-58020 Housing, Compressor[08.1987 - 01.1990] 12HT..HJ61 |
17224-58020 |
US $368.37 |
||
|
17224A
|
17224A
90404-53058 Union(For Compressor Housing)[08.1987 - 01.1990] 12HT..HJ61 |
90404-53058 |
US $8.15 |
||
|
17224B
|
17224B
90344-51014 Plug, W/head Taper Screw, No.2[08.1987 - 01.1990] 12HT..HJ61 |
90344-51014 |
US $2.62 |
||
|
17229
|
17229
17229-58010 Band, V[08.1987 - 01.1990] 12HT..HJ61 |
17229-58010 |
US $35.12 |
||
|
17239
|
17239
17239-58010 Clamp, V, No.2[08.1987 - 01.1990] 12HT..HJ61 |
17239-58010 |
US $30.93 |
||
|
17294
|
17294
17294-28010 Hose, Actuator[08.1987 - 01.1990] 12HT..HJ61 |
17294-28010 |
US $16.07 |
||
|
17294A
|
17294A
96132-30600
Clip(For Actuator Hose)
[08.1987 - 12.1988] 12HT..HJ61 |
96132-30600 |
— | ||
| replacement | |||||
|
17294A
|
17294A
96132-51100 Clip (For Hose)[08.1987 - 12.1988] 12HT..HJ61 |
96132-51100 |
from US $1.39 |
||
|
17294A
|
17294A
96132-41100
Clamp Or Clip(For Radiator Reserve Tank Hose)
[12.1988 - 01.1990] 12HT..HJ61 |
96132-41100 |
— | ||
| replacement | |||||
|
17294A
|
17294A
96132-51100 Clip (For Hose)[12.1988 - 01.1990] 12HT..HJ61 |
96132-51100 |
from US $1.39 |
||
|
91651B0820
|
91651B0820
91651-B0820 Bolt, Radiator Side Support Plate |
91651-B0820 |
from US $0.97 |
||
| replacement | |||||
|
91651B0820
|
91651B0820
90080-11347 New Genuine Part |
90080-11347 |
US $3.11 |
||
|
9017908012
|
9017908012
90179-08012 NUT |
90179-08012 |
from US $1.98 |
||
|
9025403013
|
9025403013
90254-03013 New Genuine Part |
90254-03013 |
US $0.70 |
||
|
9052304002
|
9052304002
90523-04002 RING |
90523-04002 |
US $1.43 |
||
