Rear Disc Brake Caliper & Dust Cover ([08.1999 - ] (9908- )HZJ71,74) Diagram Toyota LAND CRUISER
- Year
- 1999 - 2001
- Sales region
- Europe
- Frame
- HZJ74
- grade
- LX
- body
- HT
- ENGINE
- 1HZ
- Model
- LAND CRUISER 70
- From
- 08.1999
- To
- 08.2001
- Vehicle Model
- Land Cruiser
- Driver's Position
- LHD
- Fuel Induction
- DSL
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
04466
|
04466
04466-60010 Pad Kit, Disc Brake, Rear[01.1990 - 06.2000] PZJ70,73;HZJ70,71,73,74,LJ70,73,RJ7#..LX,VX |
04466-60010 |
from US $108.40 |
||
|
04466
|
04466
04466-60080 Pad Kit, Disc Brake, Rear[06.2000 - 08.2001] HZJ71,74 MARK NBK PN524-EE |
04466-60080 |
from US $73.49 |
||
|
04479A
|
04479A
04479-60030 Cylinder Kit, Disc Brake, Rear[01.1990 - 08.2001] PZJ70,73;HZJ70,71,73,74,LJ70,73,RJ7#..LX,VX |
04479-60030 |
from US $20.14 |
||
|
04946
|
04946
04946-30100 Shim Kit, Anti Squeal(For Rear Disc Brake)[01.2000 - 06.2000] HZJ71,74 |
04946-30100 |
from US $13.44 |
||
|
04946
|
04946
04946-60010 Shim Kit, Anti Squeal(For Rear Disc Brake)[01.1990 - 01.2000] PZJ70,73;HZJ70,71,73,74,LJ70,73,RJ7#..LX,VX |
04946-60010 |
from US $23.28 |
||
|
04948
|
04948
04947-22050 Fitting Kit, Disc Brake, Front[01.1990 - 08.2001] PZJ70,73;HZJ70,71,73,74,LJ70,73,RJ7#..LX,VX |
04947-22050 |
from US $23.45 |
||
|
31478C
|
31478C
31478-30010 Bleeder Plug Cap[01.1990 - 08.2001] PZJ70,73;HZJ70,71,73,74,LJ70,73,RJ7#..LX,VX |
31478-30010 |
from US $1.43 |
||
|
47547C
|
47547C
47547-12030 Plug, Air Vent[01.1990 - 08.2001] PZJ70,73;HZJ70,71,73,74,LJ70,73,RJ7#..LX,VX |
47547-12030 |
from US $4.60 |
||
|
47713A
|
47713A
90950-01301 Plug, Hole(For Rear Disc Brake Cylinder)[01.1990 - 08.2001] PZJ70,73;HZJ70,71,73,74,LJ70,73,RJ7#..LX,VX |
90950-01301 |
from US $1.06 |
||
|
47715C
|
47715C
47715-22010 Pin, Main(For Front Disc Brake Cylinder Slide)[01.1990 - 01.2000] PZJ70,73;HZJ70,71,73,74,LJ70,73,RJ7#..LX,VX |
47715-22010 |
from US $8.93 |
||
|
47715C
|
47715C
47715-43010 Pin, Front Disc Brake Cylinder Slide[01.2000 - 08.2001] HZJ71,74 |
47715-43010 |
from US $7.41 |
||
|
47716A
|
47716A
47716-22010 Plate, Pad Support, No.1(For Front Disc Brake)[01.1990 - 08.2001] PZJ70,73;HZJ70,71,73,74,LJ70,73,RJ7#..LX,VX |
47716-22010 |
from US $2.79 |
||
|
47717A
|
47717A
47717-22010 Plate, Pad Support, No.2(For Front Disc Brake)[01.1990 - 08.2001] PZJ70,73;HZJ70,71,73,74,LJ70,73,RJ7#..LX,VX |
47717-22010 |
from US $2.83 |
||
|
47721C
|
47721C
47721-60020 Mounting, Rear Disc Brake Cylinder, Rh[10.1992 - 08.2001] HZJ70,71,73,74,LJ70,73,RJ7#..LX,VX |
47721-60020 |
from US $61.31 |
||
|
47722A
|
47722A
47722-60020 Mounting, Rear Disc Brake Cylinder, Lh[10.1992 - 08.2001] HZJ70,71,73,74,LJ70,73,RJ7#..LX,VX |
47722-60020 |
from US $60.61 |
||
|
47730B
|
47730B
47730-60110 Cylinder Assy, Rear Disc Brake, Rh[08.1999 - 08.2001] HZJ71,74 |
47730-60110 |
from US $252.93 |
||
|
47731B
|
47731B
47731-60020 Piston, Rear Disc Brake[01.1990 - 08.2001] PZJ70,73;HZJ70,71,73,74,LJ70,73,RJ7#..LX,VX |
47731-60020 |
from US $18.16 |
||
|
47750A
|
47750A
47750-60110 Cylinder Assy, Disc Brake, Rear Lh[08.1999 - 08.2001] HZJ71,74 |
47750-60110 |
from US $248.50 |
||
|
47769A
|
47769A
47769-22010 Bush, Cylinder Slide, No.1(For Front Disc Brake)[08.1999 - 08.2001] HZJ71,74 |
47769-22010 |
from US $2.20 |
||
|
47771A
|
47771A
47771-22030 Plate, Pad Wear Indicator, No.1[01.1990 - 01.2000] PZJ70,73;HZJ70,71,73,74,LJ70,73,RJ7#..LX,VX |
47771-22030 |
from US $2.51 |
||
|
47775D
|
47775D
47775-22010 Boot, Bush Dust(For Front Disc Brake)[08.1999 - 08.2001] HZJ71,74 |
47775-22010 |
from US $1.96 |
||
|
47777
|
47777
47777-60010 Protector, Dust Boot, Rh[01.1990 - 08.2001] PZJ70,73;HZJ70,71,73,74,LJ70,73,RJ7#..LX,VX |
47777-60010 |
from US $7.52 |
||
|
47787A
|
47787A
47777-60010 Protector, Dust Boot, Rh[01.1990 - 08.2001] PZJ70,73;HZJ70,71,73,74,LJ70,73,RJ7#..LX,VX |
47777-60010 |
from US $7.52 |
||
|
47810A
|
47810A
90101-12167 Bolt, Hexagon(For Rear Caliper)[01.1990 - 08.2001] PZJ70,73;HZJ70,71,73,74,LJ70,73,RJ7#..LX,VX |
90101-12167 |
from US $1.10 |
||
|
9010506282
|
9010506282
90105-06282 Bolt(For Rear Disc Brake Dust Cover) |
90105-06282 |
from US $1.01 |
||
|
9020112452
|
9020112452
90201-12452 Nut(For Backing Plate To Steering Knuckle Setting) |
90201-12452 |
from US $1.08 |
||
|
9451100600
|
9451100600
94511-00600 Washer, Lock, No.2 |
94511-00600 |
US $2.15 |
