Rear Wiper ([01.1990 - ] (9001- )SOB) Diagram Toyota LAND CRUISER
- Year
- 1993 - 1998
- Sales region
- Japan
- Frame
- HZJ81
- grade
- GX
- ENGINE
- 1HZ
- TRANSMISSION
- MTM
- Model
- LAND CRUISER 80
- From
- 05.1993
- To
- 01.1998
- Vehicle Model
- Land Cruiser VAN
- Back Door
- SOB
- Fuel Induction
- DSL
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
85120R
|
85120R
85080-60141
Motor And Bracket Assy, Rear Wiper
[08.1992 - 01.1998] FZJ80,HDJ81,HZJ81..SOB 左側 |
85080-60141 |
— | ||
|
85120R
|
85120R
85080-60161
Motor And Bracket Assy, Rear Wiper
[08.1992 - 01.1998] FZJ80,HDJ81,HZJ81..SOB 右側 |
85080-60161 |
— | ||
|
85160R
|
85160R
85170-60060
Link Assy, Rear Wiper
[01.1990 - 01.1998] FZJ80,HDJ81,HZJ81..SOB 左側 |
85170-60060 |
— | ||
|
85160R
|
85160R
85170-60080
Link Assy, Rear Wiper
[01.1990 - 01.1998] FZJ80,HDJ81,HZJ81..SOB 右側 |
85170-60080 |
— | ||
|
85169R
|
85169R
85134-60100 Washer, Rear Wiper Link Pivot, No.1[01.1990 - 01.1998] FZJ80,HDJ81,HZJ81..SOB 左側 |
85134-60100 |
US $2.62 |
||
|
85169R
|
85169R
85179-90P80
Washer, Rear Wiper Link Pivot, No.1
[01.1990 - 01.1998] FZJ80,HDJ81,HZJ81..SOB 右側 |
85179-90P80 |
— | ||
|
85178R
|
85178R
90179-06070
Nut(For Steering Inter Shaft Dust Seal Cover)
[01.1990 - 01.1998] FZJ80,HDJ81,HZJ81..SOB |
90179-06070 |
— | ||
| replacement | |||||
|
85178R
|
85178R
90179-06159 Nut, Rear Wiper Link Pivot, No.1[01.1990 - 01.1998] FZJ80,HDJ81,HZJ81..SOB |
90179-06159 |
from US $0.57 |
||
|
85190R
|
85190R
85241-60021
Arm Assy, Rear Wiper
[08.1992 - 01.1998] FZJ80,HDJ81,HZJ81..SOB 左側 |
85241-60021 |
— | ||
|
85190R
|
85190R
85241-60040
Arm Assy, Rear Wiper
[08.1992 - 01.1998] FZJ80,HDJ81,HZJ81..SOB 右側 |
85241-60040 |
— | ||
|
85192R
|
85192R
85192-14010 Cover, Rear Wiper Arm[08.1992 - 01.1998] FZJ80,HDJ81,HZJ81..SOB 左側 |
85192-14010 |
from US $4.05 |
||
|
85192R
|
85192R
85195-95J01 Cover, Rear Wiper Arm[08.1992 - 01.1998] FZJ80,HDJ81,HZJ81..SOB 右側; FZJ80,HDJ81,HZJ81..LUB |
85195-95J01 |
from US $4.60 |
||
|
85214R
|
85214R
85214-60050 Rubber, Rear Wiper[02.1995 - 01.1998] FZJ80,HDJ81,HZJ81..GX |
85214-60050 |
US $8.21 |
||
|
85220R
|
85220R
85242-60011
Blade Assy, Rear Wiper
[05.1993 - 01.1998] FZJ80,HDJ81,HZJ81..GX 右側 |
85242-60011 |
— | ||
| replacement | |||||
|
85220R
|
85220R
85242-33040 Blade Assy, Rear Wiper[05.1993 - 01.1998] FZJ80,HDJ81,HZJ81..GX 右側 |
85242-33040 |
from US $18.07 |
||
|
85220R
|
85220R
85242-60021 Blade Assy, Rear Wiper[05.1993 - 01.1998] FZJ80,HDJ81,HZJ81..GX 左側 |
85242-60021 |
US $17.12 |
||
|
85220R
|
85220R
85291-60030 Blade Assy, Windshield Wiper[08.1992 - 01.1998] FZJ80,HDJ81,HZJ81..SOB ｳｲﾝﾀ ﾌﾞﾚ-ﾄﾞ |
85291-60030 |
US $55.33 |
||
| replacement | |||||
|
85220R
|
85220R
85291-28120 Blade Assy, Rear Wiper[08.1992 - 01.1998] FZJ80,HDJ81,HZJ81..SOB ｳｲﾝﾀ ﾌﾞﾚ-ﾄﾞ |
85291-28120 |
US $50.40 |
||
|
85221R
|
85221R
85243-60020 Blade, Rear Wiper[08.1992 - 02.1995] FZJ80,HZJ81..SOB |
85243-60020 |
US $9.32 |
||
| replacement | |||||
|
85221R
|
85221R
85214-60050 Rubber, Rear Wiper[08.1992 - 02.1995] FZJ80,HZJ81..SOB |
85214-60050 |
US $8.21 |
||
|
85224E
|
85224E
85224-60080 Plate, Rear Wiper Rubber Backing, No.1[02.1995 - 01.1998] FZJ80,HDJ81,HZJ81..GX |
85224-60080 |
US $4.22 |
||
|
85224F
|
85224F
85224-60080 Plate, Rear Wiper Rubber Backing, No.1[02.1995 - 01.1998] FZJ80,HDJ81,HZJ81..GX |
85224-60080 |
US $4.22 |
||
|
85292A
|
85292A
85292-60010 Cap, Rear Wiper Arm Head[01.1990 - 01.1998] FZJ80,HDJ81,HZJ81..SOB |
85292-60010 |
US $2.36 |
||
|
8517890D00
|
8517890D00
85178-90D00 Cap, Wiper Link |
85178-90D00 |
US $4.89 |
||
|
8513260100
|
8513260100
85132-60100
Cover, Rear Wiper Shaft
|
85132-60100 |
— | ||
|
9009900913
|
9009900913
90099-00913 SCREW |
90099-00913 |
US $3.05 |
||
|
9009905132
|
9009905132
90099-05132
Nut, Rear Wiper Link Pivot, No.1
|
90099-05132 |
— | ||
|
9017906070
|
9017906070
90179-06070
Nut(For Steering Inter Shaft Dust Seal Cover)
|
90179-06070 |
— | ||
| replacement | |||||
|
9017906070
|
9017906070
90179-06159 Nut, Rear Wiper Link Pivot, No.1 |
90179-06159 |
from US $0.57 |
||
