Side Member ([04.1990 - ] (9004- )KZJ77,LJ77,79,RJ77) Diagram Toyota LAND CRUISER
- Year
- 1990 - 1996
- Sales region
- General
- Frame
- LJ79
- grade
- LX
- body
- HT
- ENGINE
- 3L
- TRANSMISSION
- MTM
- DESTINATION
- GEN
- Model
- LAND CRUISER 70
- From
- 04.1990
- To
- 04.1996
- Gear Shift Type
- 5F
- Vehicle Model
- Land Cruiser
- Driver's Position
- RHD
- Fuel Induction
- DSL
- Building Condition
- CBU
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
53865A
|
53865A
53865-90K00 Bracket, Front Wheel Opening, No.3[01.1990 - 01.1992] FJ70,73,HZJ70,73,LJ7#,PZJ70,73,RJ7# |
53865-90K00 |
from US $3.58 |
||
|
53872C
|
53872C
53872-90K00 Bracket, Front Wheel Opening, No.8[01.1990 - 01.1992] FJ70,73,HZJ70,73,LJ7#,PZJ70,73,RJ7# |
53872-90K00 |
from US $4.12 |
||
|
61063A
|
61063A
61063-60902 Extension Sub-Assy, Rear Wheel Opening, No.2 Rh[04.1990 - 05.1993] LJ77,79,RJ77 |
61063-60902 |
from US $156.70 |
||
|
61064A
|
61064A
61064-60902 Extension Sub-Assy, Rear Wheel Opening, No.2 Lh[04.1990 - 05.1993] LJ77,79,RJ77 |
61064-60902 |
from US $163.04 |
||
|
61607B
|
61607B
61607-60901
Extension Sub-Assy, Rear Wheel Opening, Rh
[04.1990 - 05.1993] LJ77,79,RJ77 |
61607-60901 |
— | ||
| replacement | |||||
|
61607B
|
61607B
61607-60905 Extension Sub-Assy, Rear Wheel Opening, Rh[04.1990 - 05.1993] LJ77,79,RJ77 |
61607-60905 |
from US $48.28 |
||
|
61608B
|
61608B
61608-60901
Extension Sub-Assy, Rear Wheel Opening, Lh
[04.1990 - 05.1993] LJ77,79,RJ77 |
61608-60901 |
— | ||
| replacement | |||||
|
61608B
|
61608B
61608-60904 Extension Sub-Assy, Rear Wheel Opening, Lh[04.1990 - 05.1993] LJ77,79,RJ77 |
61608-60904 |
from US $50 |
||
|
61693D
|
61693D
61693-90K01 Bracket, Rear Wheel Opening, No.1[04.1990 - 05.1993] LJ77,79,RJ77 |
61693-90K01 |
from US $4.66 |
||
|
61694D
|
61694D
61694-60020
Bracket, Rear Wheel Opening, No.2
[04.1990 - 05.1993] LJ77,79,RJ77 |
61694-60020 |
— | ||
| replacement | |||||
|
61694D
|
61694D
61694-60050 Bracket, Rear Wheel Opening, No.2[04.1990 - 05.1993] LJ77,79,RJ77 |
61694-60050 |
from US $6.45 |
||
|
61695D
|
61695D
61695-60020 Bracket, Rear Wheel Opening, No.3[04.1990 - 05.1993] LJ77,79,RJ77 |
61695-60020 |
from US $6.47 |
||
|
61696F
|
61696F
61696-60020
Bracket, Rear Wheel Opening, No.2 Lh
[04.1990 - 05.1993] LJ77,79,RJ77 |
61696-60020 |
— | ||
| replacement | |||||
|
61696F
|
61696F
61696-60040 Bracket, Rear Wheel Opening, No.2 Lh[04.1990 - 05.1993] LJ77,79,RJ77 |
61696-60040 |
from US $6.38 |
||
|
61698F
|
61698F
61698-60040 Bracket, Rear Wheel Opening, No.4[04.1990 - 05.1993] LJ77,79,RJ77 |
61698-60040 |
from US $4.17 |
||
|
61699D
|
61699D
61699-60020 Bracket, Rear Wheel[04.1990 - 05.1993] LJ77,79,RJ77 |
61699-60020 |
from US $3.72 |
||
|
61783D
|
61783D
61783-60020 Pad, Rear Wheel Opening Extension, No.1[04.1990 - 05.1993] LJ77,79,RJ77 |
61783-60020 |
from US $14.25 |
||
|
61784
|
61784
61784-60020
Pad, Rear Wheel Opening Extension, No.2
[04.1990 - 05.1993] LJ77,79,RJ77 |
61784-60020 |
— | ||
| replacement | |||||
|
61784
|
61784
61783-60020 Pad, Rear Wheel Opening Extension, No.1[04.1990 - 05.1993] LJ77,79,RJ77 |
61783-60020 |
from US $14.25 |
||
|
61785C
|
61785C
61785-60020 Pad, Rear Wheel Opening Extension, No.3[04.1990 - 05.1993] LJ77,79,RJ77 |
61785-60020 |
US $4.48 |
||
|
76607
|
76607
76607-60030
Mudguard Sub-Assy, Quarter Panel, Rear Rh
[04.1990 - 05.1993] LJ77,79,RJ77 |
76607-60030 |
— | ||
| replacement | |||||
|
76607
|
76607
76607-60120 Mudguard Sub-Assy, Quarter Panel, Rear Rh (without Overfender)[04.1990 - 05.1993] LJ77,79,RJ77 |
76607-60120 |
US $78.46 |
||
|
76607
|
76607
76607-60040
Mudguard Sub-Assy, Quarter Panel, Rear Rh
[04.1990 - 05.1993] LJ77,79,RJ77 W(OVER FENDER) |
76607-60040 |
— | ||
| replacement | |||||
|
76607
|
76607
76607-60130 Mudguard Sub-Assy, Quarter Panel, Rear Rh (for Overfender)[04.1990 - 05.1993] LJ77,79,RJ77 W(OVER FENDER) |
76607-60130 |
from US $67.14 |
||
|
76607
|
76607
76607-60120 Mudguard Sub-Assy, Quarter Panel, Rear Rh (without Overfender)[05.1993 - 08.1993] KZJ77,LJ79,RJ77..GEN |
76607-60120 |
US $78.46 |
||
|
76607B
|
76607B
76645-90K01 Bracket, Quarter Panel Rear Mudguard, Rh[01.1990 - 01.1992] FJ70,73,HZJ70,73,LJ7#,PZJ70,73,RJ7# |
76645-90K01 |
from US $10.20 |
||
|
76608
|
76608
76608-60030
Mudguard Sub-Assy, Quarter Panel, Rear Lh
[04.1990 - 05.1993] LJ77,79,RJ77 |
76608-60030 |
— | ||
| replacement | |||||
|
76608
|
76608
76608-60120 Mudguard Sub-Assy, Quarter Panel, Rear Lh[04.1990 - 05.1993] LJ77,79,RJ77 |
76608-60120 |
US $78.46 |
||
|
76608
|
76608
76608-60040
Mudguard Sub-Assy, Quarter Panel, Rear Lh
[04.1990 - 05.1993] LJ77,79,RJ77 W(OVER FENDER) |
76608-60040 |
— | ||
| replacement | |||||
|
76608
|
76608
76608-60130 Mudguard Sub-Assy, Quarter Panel, Rear Lh[04.1990 - 05.1993] LJ77,79,RJ77 W(OVER FENDER) |
76608-60130 |
from US $69.42 |
||
|
76608
|
76608
76608-60120 Mudguard Sub-Assy, Quarter Panel, Rear Lh[05.1993 - 08.1993] KZJ77,LJ79,RJ77..GEN |
76608-60120 |
US $78.46 |
||
|
76608B
|
76608B
76646-90K01 Bracket, Quarter Panel Rear Mudguard, Lh[01.1990 - 05.1991] FJ70,73,HZJ70,73,LJ7#,PZJ70,73,RJ7# |
76646-90K01 |
from US $9.87 |
||
|
9011906278
|
9011906278
90119-06278 BOLT |
90119-06278 |
from US $0.92 |
||
|
9011906548
|
9011906548
90119-06548 BOLT WWASHER |
90119-06548 |
from US $0.70 |
||
|
9015960266
|
9015960266
90159-60266 SCREW |
90159-60266 |
from US $1.41 |
||
|
9015960509
|
9015960509
90159-60509 SCREW W-WASHER |
90159-60509 |
from US $0.80 |
||
|
9015960510
|
9015960510
90159-60510 Screw with washer |
90159-60510 |
from US $0.76 |
||
|
9017906214
|
9017906214
90179-06214 NUT |
90179-06214 |
from US $0.92 |
||
|
9018906134
|
9018906134
90189-06134 GROMMET |
90189-06134 |
from US $0.98 |
||
|
9026905020
|
9026905020
90269-05020 PIN |
90269-05020 |
from US $1.11 |
||
|
9026905024
|
9026905024
90269-05024 RIVET |
90269-05024 |
US $5.56 |
||
