Radiator & Water Outlet ([08.2009 - ] (0908- )2AZFE) Diagram Toyota LEXUS ES
- Year
- 2009 - 2012
- Sales region
- General
- Frame
- ACV40
- ENGINE
- 2AZFE
- DESTINATION
- CHI
- Model
- ES240
- From
- 08.2009
- To
- 06.2012
- Vehicle Model
- ES240
- Driver's Position
- LHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
16258A
|
16258A
16258-28030 Gasket(For Heater Return)[08.2009 -] 2AZFE..ACV40 |
16258-28030 |
from US $2.47 |
||
|
16261
|
16261
16261-28050 Hose, Water By-Pass[08.2009 -] 2AZFE..ACV40 |
16261-28050 |
from US $12.45 |
||
|
16261A
|
16261A
96135-51300 Clamp, Hose[08.2009 -] 2AZFE..ACV40 TYPE A:REFER ILLUST. |
96135-51300 |
from US $1.86 |
||
|
16261A
|
16261A
96137-41501 Clamp Or Clip, Hose(For Water By-Pass Hose)[08.2009 -] 2AZFE..ACV40 TYPE B:REFER ILLUST. |
96137-41501 |
from US $2.09 |
||
|
16264
|
16264
16264-28060 Hose, Water By-Pass, No.2[08.2009 -] 2AZFE..ACV40 |
16264-28060 |
from US $12.14 |
||
|
16264A
|
16264A
96135-51300 Clamp, Hose[08.2009 -] 2AZFE..ACV40 TYPE A:REFER ILLUST. |
96135-51300 |
from US $1.86 |
||
|
16264A
|
16264A
96137-41501 Clamp Or Clip, Hose(For Water By-Pass Hose)[08.2009 -] 2AZFE..ACV40 TYPE B:REFER ILLUST. |
96137-41501 |
from US $2.09 |
||
|
16268
|
16268
16268-28010 Pipe, Water By-Pass, No.1[08.2009 -] 2AZFE..ACV40 |
16268-28010 |
from US $30.42 |
||
|
16321
|
16321
16321-28020 Inlet, Water[08.2009 -] 2AZFE..ACV40 |
16321-28020 |
from US $27.34 |
||
|
16325
|
16325
16325-28010 Gasket, Water Inlet Housing, No.1[08.2009 -] 2AZFE..ACV40 |
16325-28010 |
from US $3.76 |
||
|
16331A
|
16331A
90916-03136 Thermostat[08.2009 -] 2AZFE..ACV40 *WAX 82-95 |
90916-03136 |
from US $19.32 |
||
|
91631G0614
|
91631G0614
91631-G0614 BOT WWASHER |
91631-G0614 |
from US $0.65 |
||
|
9011606127
|
9011606127
90116-06127 Bolt, Stud(For Oil Pan) |
90116-06127 |
from US $0.91 |
||
|
9012606024
|
9012606024
90126-06024 STUD HEX LOBULAR |
90126-06024 |
US $1.79 |
||
|
9415080640
|
9415080640
94150-80640 NUT FLANGE |
94150-80640 |
from US $0.72 |
