Valve Body & Oil Strainer (Atm) ([08.2009 - ] U250E (0908- )ACV40) Diagram Toyota LEXUS ES
- Year
- 2009 - 2012
- Sales region
- General
- Frame
- ACV40
- ENGINE
- 2AZFE
- DESTINATION
- CHI
- Model
- ES240
- From
- 08.2009
- To
- 06.2012
- Vehicle Model
- ES240
- Driver's Position
- LHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
35195A
|
35195A
35195-21010 Clamp, Transaxle Apply Tube, No.1[08.2009 -] ACV40 |
35195-21010 |
US $4.89 |
||
|
35196
|
35196
35196-21010 Clamp, Transaxle Apply Tube, No.2[08.2009 -] ACV40 |
35196-21010 |
US $3.06 |
||
|
35409
|
35409
35409-21010 Spring Sub-Assy, Manual Detent[08.2009 -] ACV40 |
35409-21010 |
US $5.39 |
||
|
35599
|
35599
35599-21010 Cover, Manual Detent Spring[08.2009 -] ACV40 |
35599-21010 |
US $3.06 |
||
|
35666D
|
35666D
35666-33030
Tube, Brake Apply
[08.2009 -] ACV40 |
35666-33030 |
— | ||
|
35882A
|
35882A
35882-28020 Tube, Differential Gear Lube Apply[08.2009 -] ACV40 |
35882-28020 |
US $8.30 |
||
|
35895
|
35895
35895-28010
Tube, Front Clutch Apply
[08.2009 -] ACV40 |
35895-28010 |
— | ||
|
82125J
|
82125J
82125-48010 Wire, Transmission[08.2009 - 06.2012] ACV40 |
82125-48010 |
from US $26.50 |
||
|
82125L
|
82125L
90301-21009 Ring, O(For Transmission Wire)[08.2009 -] ACV40 |
90301-21009 |
from US $2.17 |
||
|
91611B0616
|
91611B0616
91611-B0616 Bolt(For Transaxle Case Receiver) |
91611-B0616 |
from US $0.84 |
||
|
3548221020
|
3548221020
35482-21020 Clamp, Temperature Sensor |
35482-21020 |
US $1.75 |
||
|
9010505005
|
9010505005
90105-05005 Bolt (For Transfer Relief Valve Plate) |
90105-05005 |
US $1.25 |
||
|
9010506053
|
9010506053
90105-06053 Bolt(For Sensor Rotor Adapter) |
90105-06053 |
US $1.25 |
||
|
9151180614
|
9151180614
91511-80614 BOLT FLANGE |
91511-80614 |
US $1.25 |
||
|
9161160620
|
9161160620
91611-60620 Screw Or Bolt(For Valve Rocker Shaft Lock) |
91611-60620 |
US $1.61 |
