Switch & Relay & Computer ([12.2011 - 10.2015] ｴﾝｼﾞﾝ & ﾄﾗﾝｽﾐｯｼｮﾝ (1112-1510)GRL1# ; (1510- )GRL11) Diagram Toyota LEXUS GS
- Year
- 2013 - 2015
- Sales region
- Japan
- Frame
- GRL10
- ENGINE
- 2GRFSE
- TRANSMISSION
- ATM
- Model
- GS350
- From
- 09.2013
- To
- 10.2015
- Gear Shift Type
- 8FC
- Vehicle Model
- GS350
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
83530
|
83530
83530-28020 Switch Assy, Oil Pressure (For Engine)[12.2011 - 10.2015] GRL10..8FC;AWL10,GRL11,15,GWL10 |
83530-28020 |
from US $29.33 |
||
| replacements | |||||
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [12.2011 - 10.2015] GRL10..8FC;AWL10,GRL11,15,GWL10 |
83530-60020 |
from US $25.21 |
||
|
83530
|
83530
83530-0E010 Switch Assy, Oil Pressure (For Engine)[12.2011 - 10.2015] GRL10..8FC;AWL10,GRL11,15,GWL10 |
83530-0E010 |
from US $51.25 |
||
|
83531A
|
83531A
83531-50010 Switch, Oil Pressure[09.2013 - 10.2015] GRL10 |
83531-50010 |
US $10.92 |
||
|
84540
|
84540
84540-71010 Switch Assy, Neutral Start[12.2011 - 10.2015] GRL10 |
84540-71010 |
from US $112.48 |
||
|
89465
|
89465
89465-53270 Sensor, Oxygen[09.2013 - 10.2015] GRL10,11 |
89465-53270 |
US $131.17 |
||
|
89465A
|
89465A
89465-53280 Sensor, Oxygen No.2[09.2013 - 10.2015] GRL1# |
89465-53280 |
US $131.17 |
||
|
89467B
|
89467B
89467-22030 Sensor, Air Fuel RatioAIR FUEL RATIO [12.2011 - 10.2015] GRL11;GRL10..8FC |
89467-22030 |
from US $146.52 |
||
|
89467C
|
89467C
89467-22050 Sensor, Air Fuel RatioAIR FUEL RATIO [12.2011 - 10.2015] GRL11,15;GRL10..8FC |
89467-22050 |
US $188.64 |
||
|
89491
|
89491
89491-30061 Sensor, Engine Oil Level[12.2011 - 10.2015] GRL10..8FC;GRL11,GWL10 |
89491-30061 |
from US $140.60 |
||
|
89491A
|
89491A
89493-60010 Gasket, Engine Oil Level Sensor[12.2011 - 10.2015] GRL10..8FC;AWL10,GRL11,15,GWL10 |
89493-60010 |
from US $2.24 |
||
|
89615
|
89615
89615-20090 Sensor, Knock Control[12.2011 - 10.2015] GRL10..8FC;GRL11,15,GWL10 |
89615-20090 |
from US $36.02 |
||
|
91621B0616
|
91621B0616
91621-B0616 Bolt |
91621-B0616 |
from US $0.94 |
||
|
9011908C62
|
9011908C62
90119-08C62 New Genuine Part |
90119-08C62 |
US $1.28 |
||
|
8271522850
|
8271522850
82715-22850 Bracket,wiring Harness Clamp |
82715-22850 |
US $2.62 |
||
|
9155180830
|
9155180830
91551-80830 Bolt, Compressor, No.2 |
91551-80830 |
from US $0.88 |
||
|
9167380612
|
9167380612
91673-80612 BOLT FLANGE |
91673-80612 |
from US $0.66 |
||
