Switch & Relay & Computer ([01.2005 - ] ENGINE & TRANSMISSION (0501- )GRS19#) Diagram Toyota LEXUS GS
- Year
- 2005 - 2011
- Sales region
- General
- Frame
- GRS190
- ENGINE
- 3GRFE
- DESTINATION
- GCC
- Model
- GS300
- From
- 01.2005
- To
- 12.2011
- Vehicle Model
- GS300
- Driver's Position
- LHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
83530
|
83530
83530-28020 Switch Assy, Oil Pressure (For Engine)[01.2005 - 09.2007] GRS190,UZS190 |
83530-28020 |
from US $29.33 |
||
| replacements | |||||
|
83530
|
83530
83530-60020 Switch Assy, Oil Pressure (For Engine)ＹＡＺＡＫＩ→ＤＥＮＳＯ [01.2005 - 09.2007] GRS190,UZS190 |
83530-60020 |
from US $25.21 |
||
|
83530
|
83530
83530-0E010 Switch Assy, Oil Pressure (For Engine)[01.2005 - 09.2007] GRS190,UZS190 |
83530-0E010 |
from US $51.25 |
||
|
84540
|
84540
84540-30320 Switch Assy, Neutral Start[01.2005 - 09.2007] UZS190;GRS190..GCC,GEN |
84540-30320 |
US $174.24 |
||
|
89465
|
89465
89465-30810
Sensor, Oxygen
[01.2005 - 09.2005] GRS190..GCC,GEN MARK=89465-30810 |
89465-30810 |
— | ||
|
89465
|
89465
89465-30850
Sensor, Oxygen
[09.2005 - 09.2007] GRS190..GCC,GEN MARK=89465-30850 |
89465-30850 |
— | ||
|
89465A
|
89465A
89465-30810
Sensor, Oxygen
[01.2005 - 09.2005] GRS190..GCC,GEN MARK=89465-30810 |
89465-30810 |
— | ||
|
89465A
|
89465A
89465-30850
Sensor, Oxygen
[09.2005 - 09.2007] GRS190..GCC,GEN MARK=89465-30850 |
89465-30850 |
— | ||
|
89467B
|
89467B
89467-30010 Sensor, Air Fuel Ratio[01.2005 - 09.2007] GRS190 RH & LH |
89467-30010 |
from US $218.61 |
||
|
89467B
|
89467B
89467-30030 Sensor, Air Fuel Ratio[09.2007 -] URS190..EUR RH; GRS196;GRS190..GCC,GEN LH |
89467-30030 |
from US $207.89 |
||
|
89467B
|
89467B
89467-30040 Sensor, Air Fuel Ratio[09.2007 -] URS190..EUR LH; GRS196;GRS190..GCC,GEN RH |
89467-30040 |
from US $210.89 |
||
|
89491
|
89491
89491-30060
Sensor, Engine Oil Level
[01.2005 - 09.2007] GRS190 |
89491-30060 |
— | ||
| replacement | |||||
|
89491
|
89491
89491-30061 Sensor, Engine Oil Level[01.2005 - 09.2007] GRS190 |
89491-30061 |
from US $140.60 |
||
|
89491
|
89491
89491-30061 Sensor, Engine Oil Level[09.2011 - 12.2011] GRS190 |
89491-30061 |
from US $140.60 |
||
|
89491A
|
89491A
89493-60010 Gasket, Engine Oil Level Sensor[01.2005 - 09.2007] GRS190 |
89493-60010 |
from US $2.24 |
||
|
89615
|
89615
89615-20090 Sensor, Knock Control[01.2005 - 09.2007] GRS190,UZS190 |
89615-20090 |
from US $36.02 |
||
|
91621B0616
|
91621B0616
91621-B0616 Bolt |
91621-B0616 |
from US $0.94 |
||
|
9155180830
|
9155180830
91551-80830 Bolt, Compressor, No.2 |
91551-80830 |
from US $0.88 |
||
|
9165140830
|
9165140830
91651-40830 Bolt, Radiator Side Support Plate |
91651-40830 |
US $1.31 |
||
